Parts List and Diagram

PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN
THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS
TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE
MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES
ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT
PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Part
Description
1
Motor
2
Crank
3
Screw
4
Bearing (608-2RS)
5
Connecting Rod
6
Silica Gel Ring (21.2 x 2.5)
7
Piston Ring
8
Paper Pad
9
Hoop
10
Cylinder
11
Cylinder Washer
12
Silica Gel Ring (31 x 2)
13
Cylinder Head
14
Connector
15
Silica Gel Ring (31.5 x 1.8)
16
Screw (M4 x 40)
17
Flat Washer
18
Spring Washer
19
Fan
20
Screw (M4 x 10)
23
Tube
24
Pressure Regulator
25
Safety Valve
26
Tank Pressure Gauge
27
Coupler
28
Four Way Block
29
Muffler Board
30
Screw (M3 x 6)
31
Copper Connector Rod
32
Copper Hoop
33
Screw (M6 x 25)
34
Damping Pad
Record Product's Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Page 14
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
4
5
5
1
1
1
1
1
1
1
1
1
4
2
2
4
1
For technical questions, please call 1-888-866-5797.
Part
Description
35
Power Cord
36
Motor Cover
37
Circuit Board
38
Screw (M4 x 8)
39
Washer
40
Wire Clip
41
Screw (M4 x 15)
42
Nut
43
Fuse (3 Amp)
44
Fuse Box
45
ON/OFF Power Switch
46
Screw (M5 x 16)
47
Handle
48
Handle Soft Grip
49
Wire
50
Flat Washer
51
Zip Tie
52
Rubber Sheath
53
Air Tank
54
Drain Valve
55
Rubber Foot
56
Pressure switch
57
Ball
58
Spring
59
Screw (M6 x 15)
60
Flat Washer
61
Copper Tube
62
Screw (M6 x 20)
70
Regulated Pressure Gauge
71
Air Flow Valve (not shown)
72
1/4" Connector (not shown)
Qty
1
1
1
2
1
1
2
4
1
1
1
2
1
1
1
1
1
1
1
1
4
1
1
1
4
6
1
4
1
1
1
Item 69269
