Icom iF110 Service Manual page 13

I REQUIRED TEST EQUIPMENT
EQUIPMENT
Output voltage
DC power supply
Current capacity
Measuring range
RF power meter Frequency range
(terminated type) Impedance
SWR
Frequency range
Frequency counter Frequency accuracy : ±1 ppm or better
Sensitivity
Frequency range
FM deviation meter
Measuring range
DC voltmeter Input impedance
• CONNECTIONS
CAUTION:
DO NOT transmit while
the SSG is connected to
the antenna connector.
to an RS-232C port
DB9 female plug
RS-232C cable
(straight)
GRADE AND RANGE
: 13.2 V DC
: 15 A or more
: 1–100 W
: 100–300 MHz
: 50 Ω
: Less than 1.2 : 1
: 0.1–300 MHz
: 100 mV or better
: DC–300 MHz
: 0 to ±10 kHz
: 50 kΩ/V DC or better
Standard signal generator
127 to 17 dBm
(0.1 V to 32 mV)
Personal
computer
*OPC-1122
(JIG CABLE)
EQUIPMENT
Frequency range
Audio generator
Measuring range
Frequency range
Standard signal
Output level
generator (SSG)
Frequency range
Oscilloscope
Measuring range
AC millivoltmeter Measuring range
Input impedance
External speaker
Capacity
Power attenuation
Attenuator
Capacity
FM deviation meter
(DC measurable)
Attenuator
40 dB or 50 dB
to the antenna connector
DC power supply
13.2 V / 15 A
to the MIC
connector
5 - 2
GRADE AND RANGE
: 300–3000 Hz
: 1–500 mV
: 0.1–300 MHz
: 0.1 µV–32 mV
(–127 to –17 dBm)
: DC–20 MHz
: 0.01–20 V
: 10 mV–10 V
: 4 Ω
: 7 W or more
: 40 or 50 dB
: 50 W or more
RF power meter
50 / 1 50 W
Frequency
counter
to DC cable
Audio generator
AC millivoltmeter
