Operating and installation instructions
Gas hobs
KM 2014
KM 2034 / 2035
KM 2052
KM 2054
en - GB
To avoid the risk of accidents
or damage to the appliance it is
essential to read these
instructions before it is installed
and used for the first time.
M.-Nr. 07 181 160

Advertisement

Table of Contents
loading

Related Manuals for Miele KM 2014

Summary of Contents for Miele KM 2014

  • Page 1 Operating and installation instructions Gas hobs KM 2014 KM 2034 / 2035 KM 2052 KM 2054 en - GB To avoid the risk of accidents or damage to the appliance it is essential to read these instructions before it is installed and used for the first time.
  • Page 2 Per questo se si vuole usare l’apparecchio in un paese diverso rivolgersi al servizio di assistenza tecnica Miele del paese in cui si intende usarlo.
  • Page 3 Gas-heated appliances Safety precautions to take if you smell gas ß Turn off the gas emergency control valve immediately. This is usually located near the gas meter. ß Eliminate all sources of ignition in a safe manner. Do not smoke, light cigarette lighters or matches. ß...

  • Page 4: Table Of Contents

    Contents Guide to the appliance ..........6 Models .
  • Page 5 Contents Installation ............38 General installation tips .

  • Page 6: Guide To The Appliance

    Guide to the appliance Models KM 2014 Wok burner Controls: e Front right Small burner cd Medium burners f Rear right g Rear left h Front left...
  • Page 7 Guide to the appliance KM 2034 / KM 2035 Large burner Controls: f Front right Small burner cd Medium burners g Rear right h Middle Wok burner i Rear left j Front left...
  • Page 8 Guide to the appliance KM 2052 Wok burner Controls: f Front right Small burner g Rear right Large burner de Medium burners h Middle i Rear left j Front left...
  • Page 9 Guide to the appliance KM 2054 ad Wok burners Controls: f Front right Small burner g Rear right Large burner h Middle Medium burner i Rear left j Front left...

  • Page 10: Burner

    Guide to the appliance Burner Wok burner Small, medium and large burners a Burner ring b Burner cap c Burner head d Burner base e Ignition safety device f Ignitor...

  • Page 11: Accessories Supplied

    Guide to the appliance Accessories supplied The accessories supplied with your appliance as well as a range of optional ones are available to order from Miele (see "Optional accessories"). Wok ring The wok ring supplied gives additional stability to the wok, especially those...

  • Page 12: Warning And Safety Instructions

    Warning and Safety instructions Correct application This appliance complies with all This appliance is intended for relevant local and national safety domestic use only and must be used as requirements. Improper use of the described in these instructions. appliance can, however, present a Any other usage is at the owner's risk risk of both personal injury and and could be dangerous.
  • Page 13 Warning and Safety instructions Safety with children Packaging, e.g. cling film, polystyrene and plastic wrappings, This appliance is only intended for must be kept out of the reach of babies use by adults who have read these and young children. Danger of instructions.
  • Page 14 It is most important connection cable of type H 05 VV-F that this basic safety requirement is (pvc insulated), available from the Miele present and tested regularly, and Spare Parts Department. where there is any doubt the household wiring system should be inspected by a qualified electrician.
  • Page 15 Warning and Safety instructions Correct use Faulty components must only be replaced by genuine Miele original The appliance is hot when in use, parts. The manufacturer can only and remains hot for quite a while after guarantee the safety of the appliance being switched off.
  • Page 16 Warning and Safety instructions Pans must be the correct size for the Do not cover the appliance, e.g. burner they are used on (see "Suitable with a cloth, kitchen foil, etc. This could Pans"). A pan which is too small will be be a fire hazard if the appliance is unstable on the pan support.
  • Page 17 Warning and Safety instructions Replace the pan supports carefully Spray canisters, aerosols and other to avoid scratching the surface of the inflammable substances must not be hob. stored in a drawer under the hob. Cutlery inserts must be heat-resistant. Using the gas hob will cause a build-up of heat and moisture in the Do not use a steam cleaner to clean room in which it is installed.

  • Page 18: Caring For The Environment

    Caring for the environment Disposal of the packing Disposal of your old appliance material Electrical and electronic appliances often contain materials which, if The transport and protective packing handled or disposed of incorrectly, has been selected from materials which could be potentially hazardous to are environmentally friendly for human health and to the environment.

  • Page 19: Before Using For The First Time

    Before using for the first time Please stick the extra data plate for the appliance supplied with this documentation in the space provided in the "After sales service" section of this booklet. Cleaning for the first time ^ Remove any protective foil and adhesive labels.

  • Page 20: Operation

    Operation The control is used to ignite the burner Small, medium and large burners and to regulate the strength of the flame. The burners can only be switched on by pressing in the appropriate control and turning it anti-clockwise, and switched off by turning the control clockwise.

  • Page 21: Switching On

    Operation Switching on In the event of a power cut ^ The control for the burner required If there is an interruption to the must be pressed in and turned electricity supply the gas can be anti-clockwise to the largest flame ignited with a match.

  • Page 22: Regulating The Flame

    Operation Regulating the flame Switching off ^ Turn the control clockwise to position Regulate the flame so that it does not spread out beyond the sides of the "ß" . pan. As the outer part of the flame is This stops the flow of gas and the flame much hotter than the centre, the tips of goes out.

  • Page 23: Suitable Pans

    Suitable pans – Pans with thick bases are preferable as these distribute heat more evenly. Burner Min. pan base With thin bases, there is a danger of diameter in cm food overheating in places. Stir the Small burner food frequently. Medium burner –...
  • Page 24 Suitable pans Wok ring Woks are a special type of pan. They Use the wok ring supplied to give have a small base diameter and large additional stability, especially to woks top diameter, generally between 35 - 40 with a rounded base. cm.

  • Page 25: Safety Cut-Out

    Safety cut-out This appliance is fitted with a thermoelectric ignition safety device which cuts off the supply of gas to a burner if the flame goes out, for example if food has boiled over, or if there was a sudden draught. ^ To use the burner again, turn the control clockwise to the "ß"...

  • Page 26: Cleaning And Care

    Cleaning and care General notes To avoid damaging the surface of your appliance, do not use: A range of Miele branded cleaning and conditioning products are available to – cleaning agents containing soda, order from your Miele Dealer, the Spare...

  • Page 27: Stainless Steel Surfaces

    Cleaning and care Stainless steel surfaces Pan supports, control knobs Clean stainless steel surfaces using an Remove the pan supports. Clean the E-Cloth or with a solution of warm water pan supports and the control knobs and a little washing-up liquid applied with a solution of warm water and a little with a soft sponge.

  • Page 28: The Burners

    Cleaning and care The burners To assemble the small, medium and large burners Do not clean any parts of the burner in a dishwasher. The burners should be dismantled and then cleaned by hand using a solution of warm water and a little washing-up liquid applied with a soft sponge.
  • Page 29 Cleaning and care To assemble the wok burner ^ Place the burner head c onto the burner base d so that the holes fit over the jets in the burner base and the locating bar in the notch. If the burner head is correctly in position, it does not move about.

  • Page 30: Problem Solving Guide

    – check whether the mains fuse has Check whether tripped. If it has, contact a qualified electrician or the Miele Service – the burner is assembled correctly. Department. – the gas supply tap is turned on. – Check whether food deposits have –...

  • Page 31: Optional Accessories

    Miele branded cleaning and conditioning products are available for your appliance. These can be ordered via the internet at www.miele-shop.com, or from Miele (see back cover for contact details) or from your Miele dealer. Ceramic and stainless steel hob cleaner 250 ml...

  • Page 32: Safety Instructions For Installation

    Safety instructions for installation A gas hob may not be built in over a Fit the wall units and extractor hood fridge, fridge freezer, freezer, before fitting the hob to avoid dishwasher, washing machine or damaging the surface. tumble dryer. Ensure that the gas pipe and The room in which the gas hob is electrical cable are installed in such a...
  • Page 33 Safety instructions for installation Safety distance above the hob When two or more appliances are installed together below a cooker hood, e.g. a gas hob and an induction hob combiset, which have different safety distances given in the installation instructions, you should select the greater distance of the two.
  • Page 34 Safety instructions for installation Ideally the hob should be installed with plenty of space on either side. There may be a wall at the rear and a tall unit or wall at one side. On the other side, however, no unit or divider should stand higher than the hob (see illustrations).

  • Page 35: Appliance And Building-In Dimensions

    Appliance and building-in dimensions KM 2014 5 2 0 6 5 0 ß R 4 8 0 - 4 9 2 1 7 1 9 6 a Front b Building-in depth c Gas connection R 1/2" ISO 7-1 (DIN 2999)
  • Page 36 Appliance and building-in dimensions KM 2034 / KM 2035 5 2 0 7 5 0 ß R 0 5 0 4 8 0 - 4 9 2 1 7 1 9 6 a Front b Building-in depth c Gas connection R 1/2" ISO 7-1 (DIN 2999) d Mains connection box with mains connection cable, L = 2,000 mm...
  • Page 37 Appliance and building-in dimensions KM 2052 / KM 2054 5 2 0 9 0 0 ß R 0 5 0 4 8 0 - 4 9 2 1 7 1 9 6 a Front b Building-in depth c Gas connection R 1/2" ISO 7-1 (DIN 2999) d Mains connection box with mains connection cable, L = 2,000 mm...

  • Page 38: Installation

    Installation Preparing the worktop Installing the hob ^ Make the worktop cut-out following the dimensions applicable. Remember to maintain a minimum safety distance from the back wall, as well as from any tall unit or side wall to the right or left of the hob. See "Safety instructions for installation".

  • Page 39: General Installation Tips

    General installation tips Tiled worktop Do not use any sealant unless Grout lines and the hatched area expressly instructed to do so. The underneath the hob frame must be sealing strip under the edge of the top smooth and even. If they are not the part of the appliance provides a hob will not sit flush with the worktop sufficient seal for the worktop.

  • Page 40: Electrical Connection

    Electrical connection Connection should be made via a All electrical work should be carried suitable isolator or a double pole fused out by a suitably qualified and spur connection unit which complies competent person, in strict with national and local safety accordance with current local and regulations and the on/off switch should national safety regulations (BS 7671...
  • Page 41 If the connection cable is damaged, it must be replaced by a suitably qualified electrician with a special connection cable of type H 05 V V-F (pvc insulated), available from the Miele Service Department. The manufacturer cannot be held liable for damage which is the direct or indirect result of incorrect installation or connection.

  • Page 42: Gas Connection

    Please contact your dealer or the Miele Spare Parts Department for the Check with your local gas supplier appropriate conversion jets if about the type of gas and its necessary.
  • Page 43 Gas connection Connection The gas connection must be installed so that connection can be made either from inside or outside the kitchen unit, and the isolating valve must be easily accessible and visible (by opening one of the kitchen doors, if necessary). After installing the appliance the gas burners have to be set for local conditions.

  • Page 44: Burner Ratings

    Burner ratings Nominal ratings for all gas types with the burner full on Burner Gas type KM 2014 KM 2034 / KM 2035 / KM 2052 Small Natural gas burner Liquid gas Medium Natural gas 1.75 1.75 burner Liquid gas 1.75...
  • Page 45 Burner ratings Nominal rating at low setting Burner Gas type KM 2014 KM 2034 / KM 2035 / KM 2052 / KM 2054 Small Natural gas 0.25 0.25 burner Liquid gas 0.25 0.25 Medium Natural gas 0.35 0.35 burner Liquid gas 0.35...

  • Page 46: Conversion To Another Type Of Gas

    Conversion to another type of gas Jet table Connection to the gas supply, or conversion from one type of gas to another, should only be undertaken by an approved and registered gas installer in strict accordance with local and national safety and building regulations (e.g.

  • Page 47: Changing The Jets

    Conversion to another type of gas Changing the jets Wok burner Disconnect the gas hob from the electricity supply by switching off at the socket or by disconnecting the mains fuse. To change the main jets Small, medium and large burners ^ Remove burner covers b, burner ring a and burner head c.

  • Page 48: To Change The Small Jets

    Conversion to another type of gas To change the small jets Small, medium and large burners The top of the appliance has to be removed before the small jets can be changed. ^ Loosen the fixing screws on the burners. ^ Pull the control knobs off.
  • Page 49 Conversion to another type of gas Wok burner ^ Remove ignitor a. ^ Using a small screwdriver, unscrew small jets b and c in the gas fitting. ^ Pull out the jets with a pair of pliers. ^ Fit the correct jets securely (see jet table).

  • Page 50: After Changing The Jets

    Conversion to another type of gas After changing the jets ^ Reassemble the burner parts in the reverse order, ^ Check all gas fittings for leaks by operating the burner without the top section of the hob in place (use a match to ignite the flame).

  • Page 51: After Sales Service, Data Plate

    Please note that telephone calls may be monitored and recorded to improve our service. When contacting Miele, please quote the model and serial number of your appliance. These are given on the data plate. N.B. A call-out charge will be applied for service visits where the problem could have been resolved as described in these instructions.
  • Page 52 Alteration rights reserved / 3209 M.-Nr. 07 181 160 / 03...
