Summary of Contents for Clifford Tazor 4
- Page 3 For the latest vehicle wiring information and for wiring diagrams and servicing information on older Clifford products: 24-hour AutoFax: 1-800-444-4667 24-hour dealer website: www.clifforddealer.com Clifford Electronics, Inc. n 20750 Lassen Street n Chatsworth, CA 91311 1-800-824-3208 or 1-818-709-7551 n fax 1-818-407-1743...
-
Page 5: Table Of Contents
Ta ble of Con tents Im por tant In for ma tion ....... . 2 Stan dard Fea tures of the Ta zor 4 . -
Page 6: Im Por Tant In For Ma Tion
Im por tant In for ma tion 1. DO NOT dis con nect the bat tery ca bles! Make bat tery con nec tions by re mov ing the lug nuts from the bat tery clamps with out de tach ing the clamp it self. 2. -
Page 7: Stan Dard Fea Tures Of The Ta Zor 4
AutoReMonitoring o High-Output Siren o Patented SmartPowerUp™ 2 Sys tem Com po nents The Tazor 4 installation kit contains the following components: One Prewired 24-pin connector harness One High Output Siren One Prewired 2-pin connector harness One PlainView 2 Coded Valet Switch... -
Page 8: Wir Ing Dia Gram
Wir ing De scrip tion for the 2- pin Con nec tor Wire Color Con nects to White/Red Starter or Ignition Interrupt White/Red Starter or Ignition Interrupt... -
Page 9: Wir Ing De Scrip Tion - 24- Pin Con Nec Tor
Con trol Unit and An tenna The Tazor 4 con trol unit must be in stalled in side the ve hi cle. Un der no cir cum stances should the unit be in stalled un der the hood or other simi larly hos tile en vi ron ment. -
Page 10: Door Locks
Lock/Unlock Diagram 6, then (if 1989 or older) program the system for a 3-second lock pulse. 6. The Tazor 4 can also provide two pulses (+ or -) for lock and/or two pulses (+ or -) for unlock required by some vehicles (such as some Nissans, VW’s, and Audis). Wire the door locks following the steps above and select the 2x lock or unlock feature in installer-programming. -
Page 11: Led Status In Di Ca Tor
Pas sen ger Com part ment Con nec tions (Con tin ued) Door Locks (Con tin ued) LED Status In di ca tor Select a prominent location on the dash or console visible through all windows. Discuss placement with the owner. 1. -
Page 12: Plain View 2 Coded Valet Switch
RED, ORANGE and BLUE wires. Trunk Trig ger Vehicles with a ground-switching trunk light will interface directly with the Tazor 4 (on positive switching Rolls-Royce vehicles, use a relay to invert polarity). The switch may be located in or near the trunk latch or at the trunk light. If a switch cannot be located, you must add a pin switch in a location away from water channels. -
Page 13: Aux Il Iary A With Se Lecta Ble Out Put Type
Pas sen ger Com part ment Con nec tions (Con tin ued) Dual Park ing Light Cir cuit (Most Euro pean Ve hi cles) 1. Turn on the parking lights and access the Parking Light wiring in one of the following locations: nNear the head light switch nIn the door sill har ness go ing to the rear lights... -
Page 14: Win Dow Con Trol
Pas sen ger Com part ment Con nec tions (Con tin ued) Win dow Con trol If the windows can be closed using a key in the door of the car then an optional relay can be added to automatically close the power windows or the sunroof. Auto matic Win dow/Sun roof Clo sure (re quires op tional re lay) If the door key can close the power windows/sunroof, you can make them automatically close upon remote arming:... -
Page 15: En Gine Bay Con Nec Tions
The Tazor 4 comes with two ergonomically designed remote controls. Up to two additional Clifford ACG 2 remote controls can be added (older Clifford ACG and non-ACG remotes are not compatible with the Tazor 4). For instructions on how to use the remote controls, please refer to the Tazor 4 User’s Manual. -
Page 16: Fact-False Alarm Con Trol And Test
The next number is the second most recent, and so on up to as many as the last eight activations. *These channels can be assigned to control other Clifford ACG 2 systems and accessories on the customer’s other... -
Page 17: Pro Gram Ma Ble Fea Tures
Pro gram ma ble Fea tures Tazor 4 comes from the factory with its features preprogrammed as noted in bold text in the tables on pages 15 and 16. Some features can be programmed by the installer or the user, others can only be programmed by the installer. -
Page 18: User- Programmable Fea Tures
To exit program mode, turn the ignition off (you’ll hear three chirps and the LED will turn off to indicate exit of program mode), or wait 60 seconds and the Tazor 4 will automatically exit program mode. Ta ble of User- Programmable Fea tures... -
Page 19: Installer- Programmable Fea Tures
NOTE 4: the system memory. You must now add the new and/or existing remote controls to the system (i.e., AutoProgram each remote that will be used with the Tazor 4). NOTE 5: Programs a remote control from any other Clifford system (that uses ACG 2 technology) to arm or disarm the vehicle. -
Page 20: Sys Tem Check List & Trou Ble Shoot Ing
Step 2. Test the Im mo bi li za tion cir cuit. Arm the Tazor 4 (either from inside or outside the vehicle) and wait 10 seconds. Turn the ignition to the “ON” position. nEngine does not respond and alarm triggers. This is the correct response, proceed to step 3. - Page 21 This is the correct response, proceed to step 5. nOne flash. If the parking lights flash only once, the Tazor 4 had pre vi ously AutoArmed it self pas sively and by press ing the but ton the sys tem dis armed (re mote dis arm ing is ac knowl edged with one chirp and one parking light flash).
- Page 22 If the LED does not flash, verify that the LED’s VIOLET and BLACK wires are solidly connected to the same color wires on the Tazor 4’s wireloom. Warn ing: This is a 2- volt LED, test ing with 12 volts will de stroy the LED.
- Page 23 1 of this sec tion. § Check the Tazor 4’s 20A fuse. If the fuse blew when you dis armed, the ve hi cle uses a posi tive door trig ger and you con nected the in te rior light sup ply wire to ground in stead of +12 volts.
- Page 24 Stand approximately 50 feet from the vehicle and use the remote control to arm and disarm the system. nThe Tazor 4 will re spond with the pre vi ously noted in di ca tions for arm ing and dis arm ing. If not: §...
- Page 25 Step 15. Dis trib ute all nec es sary pa per work in clud ing: nUser’s Manual must be given to the customer. nAdhere the Clifford window decals to the vehicle’s windows after discussing placement with the vehicle owner. Step 16.
