- Page 1 On-Premise Laundry Planning Handbook TM795C TMB795C 50 and 75 Pound Tumblers Through Serial No. 0904002963 Refer to Installation manual for full instructions. 4-08-44R3 June 2011...
-
Page 2: Table Of Contents
Table of Contents © Published by permission of the copyright owner. All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. ©... -
Page 3: Tumblers - 50 And 75
3V – DX4 vended 3X – DX4 prep for coin DO – DMP OPL © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 4-08-44 TMB795C Steam/Thermal Oil IPD50S2-IT050S IPD75S2-IT075S QT – dual digital timer RD – reversing DMP OPL RQ –... - Page 4 Tumblers – 50 and 75 Serial Plate Multiply 0.252 1055 Inch 25.4 Inches W.C. 0.036 Inches W.C. 0.249 lb/inch (psi) 6.895 28.32 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT M PE Conversion Table To Obtain Multiply kCal Pounds/sq.
-
Page 5: Specifications And Dimensions
Specifications and Dimensions Specifications Noise level measured during operation at operator position of 3.3 feet (1 meter) in front of machine and 5.2 feet (1.6 meters) from floor. Net Weight (approximate): Pounds (kg) Cylinder Size: Inches (mm) Cylinder Capacity (dry weight): Pounds (kg) Air Outlet Diameter: Inches (mm) -
Page 6: Cabinet Dimensions
Tumblers – 50 and 75 Cabinet Dimensions Models 30.75 in. 28.75 in. Pound Gas and (781 mm) (730 mm) Electric 30.75 in. 28.75 in. Pound (781 mm) (730 mm) Steam 30.75 in. 28.75 in. Pound Gas and (781 mm) (730 mm) Electric 30.75 in. -
Page 7: Exhaust Outlet Locations
Tumblers – 50 and 75 Exhaust Outlet Locations TMB811N 5.375 in. 8 in. 13.375 in. (137 mm) (203 mm) (340 mm) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 4-08-44... -
Page 8: Gas Connection Locations
Tumblers – 50 and 75 Gas Connection Locations Models 50 Pound 75 Pound © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Diameter 1/2 in. NPT 15.5 in. (394 mm) 1/2 in. NPT 15.75 in. (400 mm) TMB812N 65.75 in. -
Page 9: Electrical Connection Locations
Electrical Connection Locations GAS AND STEAM Models Gas and Steam Electric NOTE: These figures are approximate dimensions only. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 4-08-44 ELECTRIC 9.5 in. (241 mm) 19 in. (483 mm) Tumblers –... -
Page 10: Steam Connection Locations
Tumblers – 50 and 75 Steam Connection Locations TMB814N Diameter 15.25 in. 72.75 in. 7.5 in. 64.75 in. 3/4 in. NPT (387 mm) (1848 mm) (190 mm) (1645 mm) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 4-08-44... -
Page 11: Installation
Tumblers – 50 and 75 Installation Pre-Installation Inspection Upon delivery, visually inspect the crate, carton and parts for any visible shipping damage. If the crate, carton, or cover is damaged or signs of possible damage are evident, have the carrier note the condition on the shipping papers before the shipping receipt is signed, or advise the carrier of the condition as soon as it is discovered. -
Page 12: Tumbler Enclosure
Tumblers – 50 and 75 Tumbler Enclosure To reduce the risk of severe injury, clearance of tumbler cabinet from combustible construction must conform to the minimum clearances. NOTE: Shaded areas indicate adjacent structure. 0.5 in. (13 mm) recommended between machines for removal or installation Allow 2-4 in. -
Page 13: Exhaust Requirements
Exhaust Requirements WARNING A drying tumbler produces combustible lint. To reduce the risk of fire, the tumbler must be exhausted to the outdoors. To reduce the risk of fire and accumulation of combustible gases, DO NOT exhaust tumbler air into a window well, gas vent, chimney or enclosed, unventilated area such as an attic wall, ceiling, crawl space under a building, or concealed space of a... -
Page 14: Individual Venting
Tumblers – 50 and 75 NOTE: Exhaust ducts must be constructed of sheet metal or other noncombustible material. Such ducts must be equivalent in strength and corrosion resistance to ducts made of galvanized sheet steel not less than 0.0195 inches (0.495 mm) thick. Local codes may require additional thickness. - Page 15 Removable strip of panel in framing wall to permit removal of tumbler from framing wall Partition or bulkhead Minimum distance between exhaust opening and roof, ground or other obstruction: 36 in. (914 mm) 2 in. (51 mm) minimum clearance on both sides of duct Exhaust airflow –...
-
Page 16: Manifold Venting
Tumblers – 50 and 75 Manifold Venting While it is preferable to exhaust tumblers individually to the outdoors, a main collector duct may be used if it is sized according to Figure 4 and Figure 5. This illustration indicates minimum diameters, which should be increased if the collector length exceeds 14 feet (4.3 meters) and two 90°... - Page 17 NOTE: Where the exhaust duct pierces a combustible wall or ceiling, the opening MUST be sized per local codes. Duct Station © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 4-08-44 ONE MANIFOLD ASSEMBLY Figure 4 8 in. (203 mm) Duct Table 2 Tumblers –...
- Page 18 Tumblers – 50 and 75 CONTINUE TO A NOTE: Where the exhaust duct pierces a combustible wall or ceiling, the opening MUST be sized per local codes. Duct Station © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT TWO MANIFOLD ASSEMBLIES Outlet duct diameter 45°...
-
Page 19: 50 Pound Gas And Steam Models
50 Pound Gas and Steam Models Refer to Table 4. NOTE: Wire sizes were obtained from the Canadian Electrical Code for 75 C. wire and are intended for use as a guideline only. Electrical connections should be made by a qualified electrical contractor in accordance with all applicable local and national requirements. -
Page 20: Pound Gas And Steam Models
Tumblers – 50 and 75 75 Pound Gas and Steam Models Refer to Table 5. NOTE: Wire size and breaker ratings were obtained from the Canadian Electrical Code for 75 C. wire and are intended for use as a guideline only. -
Page 21: And 75 Pound Electric Models
50 and 75 Pound Electric Models Refer to Table 6. NOTE: Wire size and breaker ratings were obtained from the Canadian Electrical Code for 75 C. wire and are intended for use as a guideline only. Electrical connections should be made by a qualified electrical contractor in accordance with all applicable local and national requirements.
