OWNER'S MANUAL
30 lb. IPD LAUNDRY DRYER
IPD30.1
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER
MANIPD30.1 07/02
Gas: Natural and LP
Steam
Electric
IPSO - USA
3101 South Haven Highway 77, Suite A
Panama City, FL, 32405
Phone: (850)271-8486
Technical specifications
Installation instructions
Operating instructions
Maintenance
D0446

Advertisement

Table of Contents
loading

Related Manuals for IPSO IPD30.1

Summary of Contents for IPSO IPD30.1

  • Page 1 Gas: Natural and LP Steam Electric Technical specifications Installation instructions Operating instructions Maintenance IPSO - USA IPD30.1 3101 South Haven Highway 77, Suite A Panama City, FL, 32405 Phone: (850)271-8486 THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER MANIPD30.1 07/02...

  • Page 2: Safety Instructions

    IMPORTANT NOTICES—PLEASE READ For optimum efficiency and safety, we recommend that you read the manual before operating the equipment. Store this manual in a file or binder and keep for future reference. WARNING: Purchaser must post the following notice in a prominent location: WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or death.
  • Page 3 ATTENTION: L’ACHETEUR DOIT PLACER L’AVERTISSEMENT SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE: AVERTISSEMENT. Assurez-vous de bien suivre les instructions donnees dans cette notice pour reduire au minimum le risque d’incendie ou d’explosion ou pour eviter tuot dommage materiel, toute blessure ou la mort. __ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de tout autre...
  • Page 4 WARNING: To avoid fire hazard, do not dry articles containing foam rubber or similar texture materials. Do not put into this dryer flammable items such as baby bed mattresses, throw rugs,undergarments (brassieres, etc.) and other items which use rubber as padding or backing. Rubber easily oxidizes causing excessive heat and possible fire.

  • Page 5: Ipso Dryer Warranty

    IPSO's factory, transportation prepaid, within the applicable warranty period and found by IPSO to have been defective, and in no event shall IPSO be liable for damages of any kind, whether for any injury to persons or property or for any special or consequential damages.

  • Page 6: Table Of Contents

    Contents Safety Instructions .................... 2-4 IPSO Dryer Warranty ..................Table of Contents ....................Symbols ......................Unpacking / General Installation ..............8-9 Technical Data and Dimensions ..............10-11 Electric Connections ..................12 Gas Connections ....................13 Gas Piping Installation ..................14-15 Gas service Installation Instructions ...............

  • Page 7: Symbols

    SYMBOLS The following symbols are used in this manual and/or on the machine. Symbol Description Symbol Rotation in two directions Rotation dans les deux sens NOTE! Drehbewigung in zwei Richtungen Movimiento rotativo en los Hot! Do Not Touch dos sentidos Heiß! Nicht Beruhren Direction of rotation Haute temperature! Ne pas...

  • Page 8: Unpacking / General Installation

    Unpacking/General Installation (All Dryers) Upon arrival of the equipment, any damage in shipment should be reported UNPACKING to the carrier immediately. Upon locating permanent location of a unit, care should be taken in movement and placement of equipment. See outline clearance diagrams for correct dimensions. Remove all packing material such as: tape, manuals, skid, etc.
  • Page 9 Unpacking/General Installation (All Dryers) The dryer is so designed that when an operator opens the dryer door, the GENERAL basket and exhaust fan stop. You can expect fast drying from the laundry INFORMATION dryer. Hot, dry air is properly and effectively moved through the basket and exhausted through a lint trap to the atmosphere.

  • Page 10: Technical Data And Dimensions

    HD30.1 lb. Dryer Dimensions - Standard Gas, Steam and Electric Heated " " " " " Page 10...
  • Page 11 IPD30.1 Dryer Dimensions - Gas (Illustration) IPSO Page 11...

  • Page 12: Electric Connections

    Electric connection Dryers must be electrically grounded by a separate #14 or larger green wire from the grounding terminal within the Service Connection Box, to a cold water pipe. In all cases, the grounding method must comply with local electrical code requirements;...

  • Page 13: Gas Connections

    Gas connection The gas supply pipe should be connected to the union (I), which is on the right next to the wiring box on the back. It is very important to have the connections done by a qualified technician, in order to make sure that the installation is effected in accordance with the prevailing standards and instructions.

  • Page 14: Gas Piping Installation

    Gas Piping Installation 1. The installation must conform with local codes, or in the absence GAS PIPING of local codes with the National Fuel Gas Code as, ANSI INSTALLATION Z223.1 or the CAN/CGA-B149, Installation Codes. 2. Check identification nameplate for type of gas for dryer. 3.
  • Page 15 Gas Piping Installation (Illustrations) The dryer and it’s individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (.04 bar). The dryer must be isolated from the gas supply piping system by closing it's individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (.04 bar).

  • Page 16: Gas Service Installation Instructions

    Gas Service Installation Instructions The size of the gas service pipe is dependant upon many variables, such GAS SERVICE as tees, lengths, etc. Specific pipe size should be obtained from the gas INSTALLATION supplier. Refer to the “Gas Pipe Size” chart in this manual for general gas INSTRUCTIONS pipe size information.

  • Page 17: Gas Pipe Size Chart

    Gas Pipe Size Chart TOTAL BTU/HR GAS PIPE SIZE FOR 1000 BTU (250 KCAL) NATURAL GAS (for LP Gas correct AT 7” (17.5 MM) W.C. PRESSURE TOTAL total BTU/HR below by KCAL multiplying by .6) In figuring total length of pipe, make allowance for tees and elbows. HOUR (25 ft.) (50 ft.)

  • Page 18: Steam Piping Installation Instructions

    Steam Piping Installation Instructions STEAM PIPING 1. Set and anchor dryer in position. Machine should be level to INSTALLATION assure proper steam circulation. INSTRUCTIONS 2. To prevent condensate draining from headers to dryer, piping should have a minimum 12" above respective header. Do not make steam connection to header with a horizontal or downwardly facing tee or elbow.
  • Page 19 Steam Piping Installation (Illustration) Page 19...

  • Page 20: Dryer Installation With Multiple Exhaust

    Area of section “A-A” must be equal to the sum of dryer exhaust pipes entering multiple exhaust pipe. (See chart below.) IPD30.1 No. of Dryers 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24...
  • Page 21 Dryer Installation with Multiple Exhaust For Exhaust Duct more than 14 feet (5 m) and 2 elbows equivalent and more than 0.3 DRYER INSTALLATION WITH inches (.8 mbar) static pressure. (See illustration on page 21.) MULTIPLE EXHAUST Make-up air from outside building may enter enclosure from top or side walls. (See Dryer Make-Up Air Chart on page 22) Use constant diameter duct with area equal to the sum of dryer duct areas.

  • Page 22: Dryer Make-Up Air Requirements

    2250 3825 2787 IPD175 79.4 2780 4726 3445 IPD190 86.2 3000 5100 3716 IPD20.1 IPD30SL 13.6 1020 IPD30.1 13.6 1063 IPD50.1 22.7 1445 1058 IPD75.1 1000 1700 1240 IPD80.1 36.3 1000 1700 1240 Notes: 1) The Model IPD 30 ST has 2 pockets per dryer, each pocket has the above listed characteristics;...

  • Page 23: Dryer Installation With Seperate Exhaust

    Dryer Installation With Separate Exhaust (Preferred) For ductwork less than 14 feet (5 m) and 2 elbows equivalent and less than 0.3 DRYER INSTALLATION WITH inches (.8 mbar) static pressure: SEPARATE EXHAUST (PREFERRED) NEVER exhaust the dryer into a chimney. NEVER install wire mesh screen over the exhaust or make-up air area.

  • Page 24: Exhaust And Venting

    Exhaust and Venting DRYER AIR FLOW Nothing is more important than air flow for the proper operation of a clothes dryer. INSTALLATION A dryer is a pump which draws make-up air from the out-of-doors, through the heater, through the clothes and then forces the air through the exhaust duct back to the out- of-doors.

  • Page 25: Rules For Safe Operation Of Dryer

    Rules for Safe Operation of Dryer Be sure your dryer is installed properly in accordance with the RULES FOR SAFE recommended instructions. OPERATION OF DRYER CAUTION Be safe—shut main electrical power supply and gas supply off externally before attempting service. CAUTION Never use drycleaning solvents: gasoline, kerosene, or other flammable liquids in the dryer.

  • Page 26: Direct-Spark Ignition Operation

    Direct-Spark Ignition Operation NOTE: All dryers manufactured are equipped with the DSI (direct spark DIRECT SPARK ignition) modules. These are designed to increase dryer efficiency and to reduce IGNITION dryer operating costs. The main burner is directly ignited from a spark electrode. OPERATION A burning flame provides an electrical path for a small amount of sensing current to allow gas valve operation.
  • Page 27 DIRECT SPARK IGNITION OPERATION FLOW CHART The DSI module is powered by a 24 volts AC suppled by a step-down transformer in series with eight safety interlocks: A. Timer switching device (1) B. Main door and lint door switches (2) C.

  • Page 28: General Maintenance

    General Maintenance 1. Clean lint trap daily. Remove lint before or after each day of GENERAL MAINTENANCE operation. A clean lint trap will increase the efficiency of the dryer and the moisture-laden air will be exhausted outside more quickly. 2. Keep basket and sweep sheets clean. Clean as often as needed. The basket and sweep sheets are accessible by removing the front panel of the dryer.
  • Page 29 General Maintenance 7. Periodically clean and examine exhaust system. GENERAL MAINTENANCE (continued) 8. Keep dryer area clean and free of gasoline, combustible materials and other flammable liquids or vapors. 9. Do not obstruct the flow of combustion (make-up) air and ventilating air.

  • Page 30: Air Switch Adjustment

    Air Switch Adjustment 1. Shut off current; disconnect leads and remove air switch. AIR SWITCH ADJUSTMENT 2. Lay air switch assembly on flat surface. Adjust air blade at “A” (figure 1) so that air blade lays flat and surface “B” is parallel to the flat surface.

  • Page 31: Operating Instruction For Double Timer

    OPERATING INSTRUCTION - DOUBLE TIMER OPERATING INSTRUCTIONS - DOUBLE TIMER MODELS After loading the dryer with water washed clothes, close the loading door. Turn the 60 minute drying (heat) timer to the desired time. Turn the 15 minute cooling (air) to the desired time. Select the temperature desired: Low, Medium, or High.

  • Page 32: Parts

    FRONT VIEW Ref. Part No. Description TU15228 CSA-01435-0 Coin chute TUD0375 Coin Chute (Mechanical Coin only) EA-11621-0 Microswitch door SC404 Pop rivet CSA-01528-0 Lint trap w/a CA-13033-0 Lint Screen CA-10567-0 Lint screen frame TU15200WHT Jacket (white) TU3211 Leveling bolt 430146179 Gasket, 5 feet TU7733 Screw self drilling 8-18 X 1/2"...

  • Page 33: Access Door Assembly

    ACCESS DOOR ASSEMBLY Ref. Part No. Description CSA-01407* - Access Door Complete CA-00856-0 Trim - Control door LA-00121-0 Lock - Control door LA-11941-0 Cam lock-Control door SB-00951-0 Screw -Phillips #8 X 7/16 flat hd. TU14957 Logo CSA-01408* Panel - Welded asm. TU15446 Support arm.

  • Page 34: Door Assembly

    DOOR ASSEMBLY Ref. Part No. Description TU15110 Complete door assy CA-13218 Catch pin TU15536 Magnet - read switch MD-00360-0 Gasket - door rim gasket SB-00852-0 Washer 1/4" external starluck SB-00921-0 Screw 1/4"-20 round head TU15073 Door hinge spacer TU15076 Door rim w/a TU15107 Door glass TU15108...

  • Page 35: Front Panel Assembly - Opl

    FRONT PANEL ASSEMBLY - OPL Ref. Part No. Description TU14546WHT - Front panel assembly complete (E-stop button) TU15726WHT - Front panel assembly complete (with out E-stop button) ESA-00862-0 Reed switch SB-00975-0 #6-32 Screw TU14435 Emergency stop TU14544WHT Front panel W/A - OPL TU2876 Door catch TU3213...

  • Page 36: Front Panel Assembly - Coin

    FRONT PANEL ASSEMBLY - COIN Ref. Part No. Description CSA-01572WH - Front panel assembly complete CA-00699-0 Bezel - Coin box ESA-00862-0 Reed switch SB-00975-0 #6-32 Screw SB-00924-0 4-40 x 3/8 Screw SB-00938-0 #4 Ext. tooth lockwasher CSA-01564WH Front panel W/A - Coin TU2876 Door catch TU3213...

  • Page 37: Thermostat Assembly

    THERMOSTAT ASSEMBLY FOR DOUBLE TIMER NOTE: Items 3, 4, 7, 9, & 10 mounted in front wire box. Items 1, 2, 5, 6, & 8 are Ref. mounted under the Part No. Description basket CA-13214-0 Plate EA-00411-0 Thermostat - 220 Degree EA-00606-0 Thermostat EA-00607-0 Thermostat knob EA-00608 - 0Grommet / rubber...
  • Page 38 THERMOSTAT ASSEMBLY FOR DX3 COIN & OPL Ref. Part No. Description ESA-00940-0 - Complete Assmebly 254/00009/00 Temp. Sensor CA-13067 Mtg. bracket EA-00411 Switch - 220 Degree SB-00828 #8-32 x 1/2 Screw SB-00952 #6-32 x 3/8 Screw TU3266 #8-32 Hex nut TU3400 #6-32 Hex nut Page 38...

  • Page 39: Pro/Hc Sensor Assembly

    PROHC SENSOR ASSEMBLY - UPPER and LOWER Ref. Part No. Description TU14724 PROHC Sensor assembly (upper) SB-00952-0 Screw, #6-32x 3/8” long TU14693 Mounting plate upper probe TU14694 Cover plate, probe TU3400 Nut, #6-32 TU7733 Screw, self drill #8-18x 1/2” long 254/00060/00 Humidity sensor UPPER ASSEMBLY...

  • Page 40: Mech. Coin Control Asm

    CONTROL PANEL ASSEMBLY MECHANICAL COIN Ref. Ref. No. Part No. Description No. Part No. Description TU15251 - Complete Assembly TU1771 Tinnerman nut TU3266 #8-32 Hex nut CM7366 Coin meter 24V TU3400 #6-32 Hex nut EA-00619-0 Start switch TU4958 #8-32 Carriage bolt M262 #8-32 Screw TU9524...

  • Page 41: Dx3 Coin Control Assembly

    DX3 COIN CONTROL PANEL ASSEMBLY Ref. Part No. Description TU15262 - Complete Assembly 254/00033/00 Overlay 254/00066/00 Control board M262 #8-32 Screw SB-00915-0 #10-16 Screw TU12253 #6-32 Stud TU14701 Nylon spacer TU15414 Control panel W/A TU1771 Tinnerman nut TU3266 Nut, hex. brass #8-32 TU3400 #6-32 Hex nut TU9524...

  • Page 42: Dmp Coin Control Assembly

    DMP COIN CONTROL ASSEMBLY TU15256 - Complete Assembly TU15255 Control panel w/a M262 Screw, mach truss HD #8-32X3/8" TU14404 Controller OPL/COIN board new TU14406 Overlay TU3266 Nut, hex-brass #8-32 TU3400 Nut, hex #6-32 TUD0336 Coin drop-hanke TUD0367 Nut, hex - #5-40 machine TU12253 Stud, self clinch TU1771...

  • Page 43: Timer Control Assembly

    CONTROL PANEL ASSEMBLY (DUAL TIMER) REVERSING and NON-REVERSING TU15248 Control panel assembly (Non-Reversing) TU15249 Control panel assembly (Reversing) * - Parts used on TU15249 only Ref. Ref. Part No. Description Part No. Description EA-00619-0 Switch - start TU15247 Control panel F540* Screw, sheet metal #6x 5/8”...

  • Page 44: Dx3 Opl Control Assembly

    DX3 OPL CONTROL PANEL ASSEMBLY Ref. Part No. Description TU15260 - Complete Assembly M262 #8-32 Screw TU14701 Nylon spacer TU15259 Control panel TU3266 Nut, hex. brass #8-32 TU3400 #6-32 Hex nut TU12253 #6-32 Stud 254/00066/00 Control board 254/00069/00 Overlay TU1771 Tinnerman nut TU9524 #6 S.M.

  • Page 45: Dmp Opl Control Assembly

    DMP OPL CONTROL ASSEMBLY Ref. Part No. Description TU15254 - Reversing Control Panel Complete TU15252 Control panel M262 #8-32 Screw TU14137 Buzzer 24V (Optional) TU14404 DMP Control TU15184 Overlay TU3400 #6-32 Nut TU12253 #6-32 Stud M270 #6 Lockwasher TU1771 Speed nut twin type Page 45...

  • Page 46: Pro Control Assembly

    PRO CONTROL PANEL ASSEMBLY REVERSING & NON-REVERSING Ref. Part No. Description TU15314 - Reversing/Non Reversing Complete Assembly 254/00054/00 PCboard, professional 254/00039/00 Overlay M262 Screw, machine truss #8-32x 3/8” long TU3266 Nut, hex brass #8-32 TU3400 Nut, hex #6-32 TU14701 Spacer nylon 1/4” O.D. x 5/16” long TU14452 Chip, EPROM, PROHC TU15257...

  • Page 47: Pro/Hc Control Assembly

    PROHC CONTROL PANEL ASSEMBLY Ref. Part No. Description TU15298 Reversing/Non Reversing Complete Assembly 254/00054/00 PCboard, professional 254/00018/00 Lable, PRO moisture controller M262 Screw, machine truss #8-32x 3/8” long TU3266 Nut, hex brass #8-32 TU3400 Nut, hex #6-32 TU14701 Spacer nylon 1/4” O.D. x 5/16” long TU14452 Chip, EPROM, PROHC TU15257...

  • Page 48: Lint Door Assembly

    LINT DOOR ASSEMBLY Ref. Part No. Description TU15665* Lint door complete Assembly - OPL TU15661* Lint door complete Assembly - Coin TU15657* Lint door W/a (OPL & Coin) SB-00949-0 Fastener plastic kickplate CA-00646-0 Lint door handle CA-00833-0 Kickplate SB-00836-0 Screw, Pancake #10 CA-00655-0 Trim, Rubrail - specify 33”...

  • Page 49: Basket & Spider Assembly

    BASKET & SPIDER ASSEMBLY Ref. Part No. Description TUS15221 Basket & Spyder Asm. - S.S. TU15221 Basket & Spyder Asm. - Galv. CSA-01538-0 Stainless steel basket assy. CSA-01636-0 Galvanized basket assy. TU15220 Spider assy. SB-00965-0 Screw-button cap 5/16 - 18 TU2814 Lock washer 5/16"...

  • Page 50: Rear View

    REAR VIEW Ref. Part No. Description TU14725 Cover plate TU15200 Jacket (white) TU15230 Upper rear cover TU15231 Lower rear cover TU7733 Screw self drilling 8-18 x 1/2" TU15671 Air switch cover Page 50...

  • Page 51: Air Switch Assembly

    AIR SWITCH ASSEMBLY - TU8206 Part No. Description F888 E-Ring TU1770 Insulator TU1771 #6 Tinnerman Nut TU2463 Actuator Arm TU3219 #6 x 1 S.M.S. TU3476 Decal TU7733 #8 x 1/2 S.M.S. TU8155 Micro Switch TU8171 Bracket Asm. Page 51...

  • Page 52: Basket Bearings/Sheave Assy

    BASKET BEARINGS, SUPPORT, AND SHEAVE Part No. Description Part No. Description TU15173 18” Dia. Sheave (Non-reversing) TU2195 1/2-13 x 1 3/4” H.H. Screw TU15157 18” Dia. Sheave (Reversing) TU2831 1/2” Lockwasher TU15153 1 1/4” Tappered Bushing TU2883 1/2” Flatwasher OP233 1/2-13 Jam nut TU15304 1/4”...

  • Page 53: Motor & Fan Assembly

    MOTOR & FAN ASSEMBLY- NON-REVERSING Ref. Part No. Description MOTOR 110-120/60/1 DA-00428-0 SINGLE MOTOR MTR314 FAN-DOUBLE MOTOR C249 Nut, 5/16-18 (4 each) MTR315 BASKET-DOUBLE DA-00460-0 Seal MOTOR **** Motor, see chart on page 200-240/60/1 DA-00428-0 SINGLE MOTOR DA-00516-0 Sheave, 2.0” dia. (60 Hz) MTR314 FAN-DOUBLE MOTOR TU14169...
  • Page 54 MOTOR ASSEMBLY- REVERSING Ref. Part No. Description DA-11909-0 1/2HP 200-415/50-60/3 TU15162 Sheave, 1.8” dia. (60 hz) TU14689 Sheave, 2.2” dia. (50 hz) VSB130 Washer, cut 5/16” TU2814 Washer, lock 5/16” TU5439 Screw, cap HH 5/16-18 Page 54...

  • Page 55: Idler Assembly

    IDLER ASSEMBLY Ref. Ref. Part No. Description Part No. Description SB-00935-0 Screw 5/16-18x 3” Reversing DA-00523-0 Belt, upper (Basket) TU2814 Lock Washer 5/16" TU5439 Screw 5/16-18x 1" DA-00523-0 Belt, lower (Motor) Non-reversing TUD0187 Key 3/16” square 2 1/2” VSB130 Washer 5/16" DA-00523-0 Belt, upper (Basket) DA-00525-0...

  • Page 56: Rear Control Box Asm-Gas

    REAR CONTROL PANEL ASSEMBLY - GAS Ref. Ref. Part No. Description Part No. Description TU14958 T-Block CA-11935-0 Rear wiring box TU14959 T-Block end EA-00680-0 Plug knock out TU14985 Din rail EA-00685-0 Reverse control, 24V coil TU15007 T-Block ground end SB-00865-0 Screw, phillips head TU15265 Terminal Board...

  • Page 57: Rear Control Box Asm.-Elec

    REAR CONTROL PANEL ASSEMBLY - ELECTRIC Ref. Ref. Part No. Description Part No. Description CA-11935-0 Rear wiring box TU14986 Din rail EA-00680-0 Plug knock out TU15265 Terminal Board EA-00685-0 Reverse control, 24V coil TU2490 Plug, button SB-00867-0 Bushing, insulating TU2793 #8-18 Self-drilling screw SB-00868-0 Bushing, insulating...

  • Page 58: Nat. Gas Heating Unit Asm

    NATURAL GAS HEATING UNIT Ref. Ref. Part No. Description Part No. Description TU15129 - Complete assembly TU7733 #8-12 Screw, self drilling TU15693 Ignitor mtg. bracket FG274 1/2” x 30# lg. Nipple CA-11028-0 Bracket, HI limit TU15106 Burner cover plate GA-11006-0 Manifold OP290 1/2”...

  • Page 59: Gas Heating Unit Asm

    L.P. GAS HEATING UNIT Ref. Ref. Part No. Description Part No. Description TU7733 #8-12 Screw, self drilling TU15222 - Complete assembly TUD0242 Ignitor mtg. bracket FG274 1/2” x 30# lg. Nipple CA-11028-0 Bracket, HI limit TU15106 Burner cover plate GA-11006-0 Manifold OP290 1/2”...

  • Page 60: Steam Heating Unit Asm

    STEAM HEATING UNIT Ref. Part No. Description CSA-01675-0 Complete assembly CA-13220-0 Steam coil CFB0900 Cable, GREENFIELD 1/2" X 9" TU15246 Adaptor, w/a TU13517 Valve, steam solenoid 3/4” 24V TU2735 Reducer, pipe 1” x 3/4” TU4608 Nipple, 3/4” x 2” black TU4790 Connector TU7733...

  • Page 61: Electric Heating Unit Asm

    ELECTRIC BONNET ASSEMBLY Ref. Part No. Description TU15281 - 380-415/22.5KW Complete Asm. ESA-01054-0 - 440-480/22.5KW Complete Asm. ESA-01002-0 - 240V/22.5KW Complete Asm. ESA-01001-0 - 208V/22.5KW Complete Asm. CA-11984-0 Rear heater box cover EA-00243-0 Bonnet high limt switch EA-00472-0 Heater element EA-00473-0 Heater element( 208V) EA-10232-0...

  • Page 62: Recommended Spare Parts List

    RECOMMENDED SPARE PARTS LIST BELTS EA-11621-0 LINT DOOR SWITCH CA-13033-0 20-30# LINT SCREEN DA-00533-0 NON-REV UPPER BELT 20/30SL TU5261 30SL, 50,75# LINT SCREEN TU15206 NON-REV LOWER BELT 20/30SL MD-00337-0 MAGNET –READ SWITCH DA-00533-0 REV UPPER BELT 20/30SL MD-00360-0 GASKET DOOR RIM DA-00522-0 REV LOWER BELT 20/30SL...
