Pin Input / Output Harness - Code Alarm ca 1151 Installation Manual

6 RED
Locate 1 of the vehicle's constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage in all positions of the ignition
switch.
Connect the RED wire to the constant 12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.

6 Pin Input / Output Harness

1 PURPLE
Locate the vehicle's dome light or door pin switch wire.
Verification: This wire will register positive voltage (POS) when the door is
opened and the interior light is on. This wire will
register ground or "0" Volts when the door is closed and the interior light is
off.
Connect the PURPLE wire to the vehicle's positive door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide
2 GRAY
Install a Hood Pin Switch and connect to the GRAY wire.
Verification: This wire when connected will register ground when the
vehicle's hood is opened.
Connect the GRAY wire to the hood pin.
NOTE: Be sure to loom the wire, and seal the grommet.
6
BATTERY 12V ( + )
DOOR TRIGGER INPUT ( + )
HOOD PIN INPUT ( - )
ca1151 rev B. 2011 Audiovox Electronics Corporation. All rights reserved.
