Pin Input / Output Harness - Code Alarm ca 1552 Professional Series Installation Manual

5 RED
Locate 1 of the vehicle's constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage in all positions of the ignition
switch.
Connect the RED wire to the constant 12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.

9 Pin Input / Output Harness

1 BLUE/WHITE
This wire is a GROUND input for an external sensor or secondary pin switch.
Verification: This wire when connected will trigger the security system.
2 GREEN
Locate the vehicle's dome light or door pin switch wire.
Verification: This wire will register ground (NEG) when the door is opened
and the interior light is on. This wire will register positive voltage when the
door is closed and the interior light is off.
Connect the GREEN wire to the vehicle's negative door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide
3 ORANGE
This wire will have a continuous ( - ) 200mA output when the system is Armed. This
wire is typically used for controlling window modules or additional sensors.
This output is configurable in option programming.
6
BATTERY 12V ( + )
INSTANT TRIGGER INPUT ( - )
DOOR TRIGGER INPUT ( - )
GROUND WHEN ARMED OUTPUT ( - )
ca1552. 2011 Audiovox Electronics Corporation. All rights reserved.
