Additional Ports

LED Port

The LED included in the kit will serve as a visual indicator of the alarm's status. It
should be installed in the dash, located where it can be easily seen from outside
the vehicle, yet not be distracting to the driver. Once a location has been
selected, check behind the panel for wire routing access, and to confirm the drill
will not damage any existing components as it passes through the panel. Drill a
1/4" hole, and pass the red and blue wires from the LED through the hole, from
the front of the panel. Firmly press the body of LED into the hole until fully seated.
Programming / Valet Button Port
Select a mounting location that is within reach of the ignition switch, as this
switch in combination with the ignition switch, will be used to program the certain
features of the system. It is suggested that the switch be mounted to the lower
dash panel in the driver's area within reach of the driver.

Shock Sensor Port

Select a solid mounting surface for the shock sensor inside the passenger
compartment (behind the dash), and mount the sensor using cable ties, making
sure to allow access to the sensitivity adjustment for use later in the installation.
Data Bus Interface Port
This 4 pin port is used for Flashlogic Door Lock and Transponder Databus
Interfaces to communicate with the vehicle's Databus. When using the DBI port to
control the Flashlogic Door Lock and Transponder Interface modules the
following options may be available. Please refer to the D2D (Data to Data)
function list available per vehicle on the tech service web site.
Door Trigger
Trunk/Hatch Open
Dome Light Supervision
Manual Arm / Disarm Inputs (factory keyless controls system)
10
Door Lock Control
Factory Alarm Arm / Disarm
