Summary of Contents for Vivotek IP3111

  • Page 2 Product name: Network Camera (IP31x1) Release Date: 2005/07/04 Manual Revision: 2.10 Web site: www.vivotek.com Email: technical@vivotek.com sales@vivotek.com Made in Taiwan. ©Copyright 2000-2005. All rights reserved www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 3: Before You Use

    Network Camera, review "Advanced functions" to get creative ideas. To those professional developers, "URL Commands of Network Camera" will be a very helpful reference. Those paragraphs preceding by should be fully understood and cautioned. Ignoring the warnings may result in serious hazards. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 4: Table Of Contents

    Cable connection ................14 Power on ..................15 Software configuration ............ 16 Install a new modem ................ 20 Setup a new connection ..............23 First access to Network Camera........28 How to Use ............30 www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 5 Uploading snapshots periodically to an external FTP server ....72 Customizing homepage images ............72 Viewing system log ................73 Uploading the configuration file ............73 Software revision upgrade..............73 System core debugging ..............75 Monitor changed status of digital inputs ..........75 www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 6 Image quality configuration URL ............84 Camera configuration URL ..............85 Camera custom command configuration URL ........86 Modem configuration URL..............87 Application configuration URL ............88 Homepage layout configuration URL ........... 89 DDNS & UPNP configuration URL ......89 www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 7 Appendix ............91 A. POST procedure ............91 C. Technical specifications ..........96 Electromagnetic Compatibility (EMC) ..........97 www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 8: Package Contents

    Package Contents IP3111/3121 CD-ROM Power adapter Quick installation guide I/O terminal block connector and Wrench Warranty card Null modem cable www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 9: Physical Description

    This RS232 serial port can connect with a modem or included null modem cable to utilize dial-up network when Ethernet is not available. If Network Camera operates with Ethernet interface, administrators may use this port to control custom Pan-Tilt device. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 10: General I/O Terminal Block

    Network Camera provides one digital input and one relay switch. Pin 1 and pin 2 can be connected to external sensor and the state of voltage will be monitored according to the programmed scripts in configuration. The relay switch can be used to turn on or off external devices. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 11: Status Leds

    Network Condition LED2 LED3 (Status) Interface (Heartbeat) Ethernet before installed after installed flash during camera control flash Flash PPP with modem after POST flash PPP with null before connected modem after connected flash www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 12: Restore Button

    The pin assignment of the auto iris lens connector is as follows: VIDEO Drive DC Drive Pin 1 Power source Damp- Pin 2 Video signal Damp+ Pin 3 Not used Driver+ Pin 4 Ground, Shield Driver- www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 13: How To Install

    In the following content, "user" refers to those who can access Network Camera and "administrator" means the supervisor who has the root password to configure Network Camera in addition to general access. Administrators should carefully read this manual, especially during installation. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 14: Ethernet Environment

    Dial-out connection denotes an active Network Camera to dial out to the other end of a dial-up server or any Internet service provider, abbreviated as ISP, to request a point-to-point connection. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 15: Cable Connection

    Shut down all the peripheral devices prior to connection. Connect the supplied cables from Network Camera to related devices according to the following steps. Note that the power adaptor must be kept unplugged until other cables are firmly connected. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 16: Power On

    Refer to the configuration section for further information. Connect the power jack of the power adapter to Network Camera prior to plugging the utility end into the utility power socket. It will reduce accidental electric surge shock. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 17: Software Configuration

    CD into the CD-ROM drive of the PC running in MS Windows. An auto-run program will pop up (If the program is not on auto-run, go to the root directory of the software CD and click on “autorun.exe”). www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 18 LAN: After searching, Video Servers or Network Cameras will be located by the Installation Wizard. There may be several entries shown in the window. The Administrator may differentiate the Network Cameras with the serial number. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 19 Administrator can click on button “Link to selected device” to connect the I.E. to the camera. If the camera is not on the IP installer list, click on the “Search” button to search for the camera on the LAN. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 20 For more detailed usage of the Installation Wizard, please refer to the user’s manual of the Installation Wizard. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 21: Install A New Modem

    For the first time, users should connect the included null modem cable between the COM port of Network Camera and any COM port of the PC for initial setup. Install a new modem Open the control panel and double click the modems icon. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 22 Check "Don't detect my modem.." item and click on to install a new modem. From (Standard Modem Type) choose the Standard 33600 bps Modem and click on www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 23 Choose the serial port that the included null modem cable is attached to and click on The null modem is now ready for use. If no Dial-Up adapter exists in the system, Windows will automatically prompt to install. Press to continue. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 24: Setup A New Connection

    Setup a new connection After the 33600 bps modem is installed, open the dialup network folder in Windows to build a new connection. Select the device as the newly installed standard 33600 bps modem and click on www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 25 Just enter arbitrary digits as phone number and click on . The phone number used here is not important. After clicking on , this new connection will display in the Dial-up Networking folder and will be used for null modem connections. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 26 Right-click on the newly setup connection icon for properties. In the first General page, clear "Use area code and Dialing Properties" option and click on www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 27 Select 115200 as the speed and click on On the second page, only check "Enable software compression" and "TCP/IP" while leaving others blank. Keep other settings as default values and click on . Now the connection is ready for null modem connection. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 28 After connection is established successfully, go to the next section, "First access to Network Camera". If an error message indicates a hardware error while connecting for the first time, especially in a Windows 2000 environment, try again to recovery the possible detection failure. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 29: First Access To Network Camera

    Note that the new password will also be used in the next dialup. To make Network Camera successfully work in dial-in and dial-out modes, follow the www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 30 If dial-out configuration is activated, Network Camera will dial out to send a system startup log to test and drop the call after the pre-configured period. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 31: How To Use

    Open your web browser and connect to Network Camera just like a general web site and the audio and video will present on demand. Make sure the web address of the target Network Camera is accurate. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 32: Authentication

    In the figure below, the foreground is the login window and the background shows the message when authentication fails. The user may check the option to save the password for future convenience. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 33 Users may click on to install the plug-in. If the web browser does not allow the user to install, check the Internet security option to lower security levels or contact network supervisors. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 34: Primary User's Capability

    Click on the configuration link to the right of the image window to enter the configuration page. Snapshot button The snapshot button enable user to capture a snapshot within a new window. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 35: Pan/Tilt Positioning Device Control

    They should be pre-configured by administrators with reference to the instruction manual of the PT positioning devices. <url> http://<Network Camera> <Network Camera> is the domain name or pure IP address of Network Camera. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 36: Client Setting

    There are three protocols - UDP, TCP and HTTP. When you choose UDP protocol, audio and video streams can be more real-time. But some packets may be lost and decoding error will happen. If you select TCP protocol, www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 37 When using modem as the network connection, Network Camera will not send the audio automatically, and send video only because the low bandwidth environment doesn’t meet the requirement for both. In the Client setting page, protocol option will be set as Http protocol. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 38: System Configuration

    If administrators also want to set certain options through the URL, read the section on advanced usage for reference. <url> http://<Network Camera>/setup/config.html <Network Camera> is the domain name or original IP address of Network Camera. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 39: System Parameters

    Leaving the NTP server blank will let Network Camera connect to default timeservers. If some specific timeserver is assigned, type it in the text box. Domain name or IP address format is acceptable as long as DNS server is available. Do not forget to set www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 40 "Time Zone" offset for local settings. It only affects the hour in NTP method. Click on to validate changes. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 41: User Group Administration

    To delete a user, pull down the user list to find the user name to be deleted and press Demo account would be enabled as long as “view” is checked. User can view, control DO or camera by entering user name “demo” without password. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 42: Network Settings

    Users can run IP installer to check the IP address assigned to the Video Server if the IP address is forgotten or using the UPnP function provided by the Video Server (MS Windows XP provides UPnP function in the “my network place”) www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 43 Administrator has setup some applications in either event mode or sequential mode, the Video Server will send out snapshots once conditions are met. There are two methods to send files, including e-mail (SMTP) and FTP. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 44: Smtp

    FTP may be prohibited. By selecting passive mode, the FTP can bypass the rule and allow snapshot upload to proceed. If the passive mode is selected, the Video Server can automatically attempt for active mode, if the external FTP server does www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 45 Improve audio quality in low bandwidth environment” item. It can make the audio quality better, but the media delay is longer and real-time issue is bad. If the network performance is worst, please select the”UDP protocol” as the communication protocol in “client setting” www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 46 Administrator should notice that the IP address, subnet mask, default router and DNS servers will be cleared when the network interface is switched to the other. Refer to the related section of Ethernet or modem for software installation. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 47: Upnp And Ddns Settings

    “Password/Key” Please input the password or key to get the DDNS service. “Enable UPnP” This turns on or off the UPnP function. When UPnP is turned off, the camera cannot be found through “my network place” in MS Windows XP. If the UPnP network www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 48 “Save” Click on the button save current settings for the DDNS service and UPnP function. Network Camera provides a free DDNS service. Administrators can choose safe100.net in the “Providers” field to use it. At the first time, Administrators must register an account for www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 49: Video Codec Parameters

    “Double” but of a lesser quality. Network Camera uses MPEG4 codec compression for best streaming solution. The compressed video data is far less than JPEG in normal cases but it still depends on the level www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 50 Motion detection will increase system load. Enter the motion detection option page for advanced configuration. To adjust video from external cameras, use "Flip" to map the video vertically and "Mirror" to map the video horizontally. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 51 When the image is O.K., press to memorize the image settings or to recall the original settings. If parameters are changed without saving, they will be used until the next system startup. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 52: Motion Detection

    , a graphic bar will go up or down depending on the image variation. A green bar means the image variation is under monitoring level and a red bar means the image variation is over monitoring level. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 53 The following figure shows the screen when is clicked. The monitoring windows will be marked by red squares. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 54: Camera Positioning Device Configuration

    RS232 and RS485 interface to control external serial port devices. Refer to the hardware description to connect an RS485 device. The “Port Settings” and “Control Settings” must be configured according to the instruction manual of the external serial www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 55 The "Command" should be entered in ASCII format alike the pan, tilt commands. "Display string" is for those texts on command buttons and should be less than 8 characters. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 56 To enter more commands or commands other than pan and tilt, a flexible URL is provided for customized interface. See the “Clear data path for proprietary commands” section in Advanced functions for details. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 57: Modem And Dialup Settings

    To initialize the modem with further commands, type into the edit box. The prefix "AT" should be included. Administrators should choose an appropriate "Dial Method" according to the local POTS www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 58 When using modem as the network connection, Network Camera will mute the audio automatically, and send video only because the low bandwidth environment doesn’t meet the requirement for both. In the Client setting page, protocol option will be set as Http protocol. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 59: Application

    Network Camera can use FTP to upload and overwrite snapshot files periodically. The remote folder of snapshot files for FTP can be configured on the network page. The snapshot period is between "Snapshot begin" and "Snapshot end" and it will repeat www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 60 If administrators are not sure of the digital output status before configuring applications, "Reset output" can be used to return the digital output to the default “Normal Close” state. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 61: Homepage Layout Settings

    The "font color" and "background color" can be chosen from sixteen colors to achieve the best visual effect. See "Customizing homepage images" section in "Advanced functions" for how to replace images. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 62: One-Shot Fast Configuration Via Ftp

    A sample CONFIG.INI is attached below. The italic text following each line describes the format of the field and the bold italic characters are the possible values of each field. ******* sample file ********** Network Camera Initial Configuration File [SYSTEM] <reset system> or NO www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 63 Read only string <time zone> From 12 to -12 <user name> (0) root Read only string String shorter than 15 characters The followings are as same as above (10) (11) (12) (13) (14) (15) (16) (17) www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 64 The followings are as same as above (10) (11) (12) (13) (14) (15) (16) (17) (18) (19) (20) <language> read only <ptzenabled> read only <NTP Update Interval> 0 for hourly, 1 for daily, 2 for weekly, 3 for monthly www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 65 (2)Command3 no longer than 8 characters(some language will use double bytes) (3)Command4 no longer than 8 characters(some language will use double bytes) (4)Command5 no longer than 8 characters(some language will use double bytes) www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 66 Standard IP format or string shorter than 40 characters <smtp mail server> Standard IP format or string shorter than 40 characters <SMTP account name 1> String shorter than 40 characters <SMTP password 1> String shorter than 40 characters <mail recipient address> www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 67 <backup ftp username> String shorter than 15 characters <backup ftp password> String shorter than 15 characters <backup ftp init path> String shorter than 40 characters <http server port> Integer less than 1024 <control channel port> www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 68 3 for TZO.com", 4 for dhs.org", 5 safe100 6 dyn-interfree <hostname> String shorter than 127 characters <username/email> String shorter than 63 characters <password/key> String shorter than 20 characters [UPNP] <enablepresentation> YES for enable, NO for disable www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 69 1200k, 1000k, 768k, 512k, 384k, 256k, 128k, 64k <frame rate> 1, 2, 3, 5, 10, 15, 20, 25, 30 (30 for NTSC only) <video size> 1, 2, 3 representing half, halfx2, normal <motion detect enabled> <flip> <mirror> www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 70 String shorter than 80 characters String shorter than 80 characters <PT control commands> HOME String shorter than 80 characters String shorter than 80 characters DOWN String shorter than 80 characters LEFT String shorter than 80 characters www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 71 <file with time suffix> or NO <seconds to snapshot after event> <seconds to snapshot periodically> <time to start snapshot> 00:00:00 24 hours format <time to stop snapshot> 00:00:00 24 hours format <seconds delay before next event> www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 72: Advanced Functions

    After confirmation, the system will restart and require the installer program to setup the network. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 73: Uploading Snapshots Periodically To An External Ftp Server

    The followings are the referenced file names and size limitations. Object File name Maximal size Logo logo.gif Logo and background share 8000 bytes Background back.gif Logo and background share www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 74: Viewing System Log

    Network Camera is able to keep the most up-to-date software. Customers are allowed to download the updated binary codes upon receiving additional license from Vivotek and consequently upload it to Network Camera via FTP. This function is open to administrators only.
  • Page 75 After Network Camera boots up, reload the web page in the browser. If power fails during the software upgrade, the program in the memory of Network Camera may be destroyed permanently. If Network Camera cannot restart properly, ask the dealer for technical service. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 76: System Core Debugging

    For example, after typing "dinote" the terminal will display DI=L DI=L and if DI changes to H, terminal will display only DI=H Stop information dumping Typing "stop" will cease dumping debug information and digital input status. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 77: Query Status Of Digital Inputs

    Typing "clear" will make Network Camera restore factory settings but not restart. To validate new settings, type "reset" to make the system restart. Reset system Typing "reset" will make Network Camera perform a software reset. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 78: Url Commands Of Network Camera

    192.168.0.201, to set digital output to connect to NC with COMMON. Clear data mode serial port driver This URL applies to the attached serial port device including supported PTZ cameras or non-supported custom cameras. Note the serial port settings of custom cameras must be www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 79: Restore Factory Default Settings

    0x41, 0x42, 0x43 read from COM port will show in returned homepage as 414243 instead of ABC. Restore factory default settings /setup/restore.cgi Network Camera will automatically restart after restoring factory default configurations. Restart system /setup/reset.cgi Restart Network Camera without warning. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 80: Page Url

    /setup/video.html image quality option /setup/image.html camera control /setup/camera.html modem /setup/modem.html custom command setting /setup/command.html custom camera setting /setup/custom.html application option /setup/app.html homepage layout option /setup/layout.html system log /setup/logfile.html system parameters /setup/parafile.html set factory default /setup/factory.html www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 81: System Resource Url

    NTP server to synchronize manu directly adjust date and time date <yyyy/mm/dd> year, month and date separated by slash time <hh:mm:ss> hour, minute and second separated www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 82: Security Configuration Url

    <text string shorter than 15 new user's password characters> deluser <text string shorter than 15 existing user name characters> Network configuration URL URL: /setup/network.cgi NAME VALUE DESCRIPTION reset enable installation at next boot disable installation at next boot www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 83 <text string shorter than 15 user name for primary FTP server characters> ftppass1 <text string shorter than 15 password for primary FTP server characters> ftpfolder1 <text string shorter than 40 upload folder in primary FTP server characters> www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 84: Video Configuration Url

    <text string shorter than 15 enclose caption characters> size half half x 2 normal quality fixb fix bit rate <other than fixb> fix quantization quan lowest quality of video lower quality of video normal quality of video www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 85: Image Quality Configuration Url

    <other than yes> normal image mirror mirror image <other than yes> normal image Image quality configuration URL URL: /setup/image.cgi NAME VALUE DESCRIPTION brightness <-5 ~ 5> adjust brightness of image www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 86: Camera Configuration Url

    <text string shorter than 80 tilt down command string of COM characters> left <text string shorter than 80 pan left command string of COM characters> right <text string shorter than 80 pan right command string of COM characters> www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 87: Camera Custom Command Configuration Url

    <text string shorter than 8 button name of custom command 5 characters> of COM com1 <text string shorter than 80 custom command 1 of COM characters> com2 <text string shorter than 80 custom command 2 of COM characters> www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 88: Modem Configuration Url

    <text string shorter than 40 phone number of secondary ISP characters> user2 <text string shorter than 40 user name for secondary ISP characters> pass2 <text string shorter than 40 password for secondary ISP characters> www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 89: Application Configuration Url

    DO when DI condition matched mdalarm < not required > trigger DO when motion detected ioupload < not required > upload snapshot when DI condition matched mdupload < not required > upload snapshot when motion detected www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 90: Homepage Layout Configuration Url

    <0 ~ 15> color index for font bcolor <0 ~ 15> color index for background DDNS & UPNP configuration URL URL: /setup/ddns.cgi NAME VALUE DESCRIPTION enddns <not required> Enable DDNS provider 1 or 2 dyndns www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 91 Host name characters> usermail <text string shorter than 38 Account name of DDNS characters> passkey <text string shorter than 38 password of DDNS characters> enupnp <not required> Enable UPnP enupnpnat <not required> Enable UPnP Port Forwarding www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 92: Appendix

    LED2 blink and LED3 ON U22(M5823) Real-time clock LED2 ON and LED3 blink U19(16C1550CJ), P2 COM interface Ethernet interface failure includes not only components on board but also Ethernet cable and the devices of the opposite end. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 93 A. The timestamp is based on the system time of Network Camera. It is maintained by a real-time clock inside and automatically synchronizes with the time server if Network Camera is connected to the Internet and the function is enabled. Differences of several hours may result from the time zone setting. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 94 5. the level of your PC or notebook which is responsible for displaying images. In general, the transfer rate in a general local network environment can achieve over 200 kilobytes per second and approximately 10 to 20 pictures of a normal environment per second. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 95 If you prefer to retrieve images via FTP, the value could be smaller since FTP responses quicker than the Web does. Once the system is too busy to configure, use the restore factory default and reset button to save the system. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 96 Q. I try to connect my black-and-white and color cameras with Network Camera but the image is not good. A. Although Network Camera allows users to choose color or black-and-white images for each camera, hybrid camera types may increase video processing time and reduce system performance. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 97: Technical Specifications

    Standard C or CS mount lens fitting 12V DC, 1.2A external power supply 6-15V DC, min. 15W - Viewing System Requirement Protocol Standard internet TCP/IP suite Operating System Microsoft Windows, Browser Internet Explorer 4.x or above www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 98: Electromagnetic Compatibility (Emc)

    Vivotek Inc. makes no warranty of any kind with regard to the material contained within this document, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
