*1 :This adjustment must be performed not only replacing the Lens Parts (Include MOS Unit), but also simply removing the Lens
Parts (Include MOS Unit).
*2 :White missing pixels means that the pixel which is always active (lit) although shading (Dark) condition.
*3 :Black missing pixels means that the pixel which is always non-active (off) although high-intensity light is coming.
*4 :If the adjusted data is backed up from the main board before replacement or repair, write the data to the new main board.
If parts other than the main board are not replaced, adjustment is not necessary for items other than "Venus Zoom (PZM)/
Backfocus/GYRO(BF)/Flash(STB)".
IMPORTANT NOTICE (After replacing the Main P.C.B.)
After replacing the MAIN P.C.B., make sure to perform the
"INITIAL SETTINGS" first, then release the "INITIAL
SETTINGS" in order to proceed the electrical adjustment.
Note:
1. If electrical adjustment or data re-writing is executed
before "INITIAL SETTINGS", suffix code list is never
displayed, and it cannot be chosen suitable suffix code.
2. Never remove the battery during initial setting in process.
