SALON™ SPA
AIR BATH AND WHIRLPOOL
INSTALLATION AND OPERATING INSTRUCTIONS
Save These Instructions for Future Use.
Complete and mail-in the product registration card provided with your unit.
Write and save the model and serial number of your unit below.
Owner's Record
Date Purchased ____________________________________________________________
Purchased From ____________________________________________________________
Installed By ________________________________________________________________
Serial Number ______________________________________________________________
Model _____________________________________________________________________
Installer: Leave this manual for homeowner.
Homeowner: Read this manual and keep for future reference.
©2006 Jacuzzi Whirlpool Bath
EL21000B
10/06
Advertisement
Table of Contents
Related Manuals for Jacuzzi SALON
Summary of Contents for Jacuzzi SALON
- Page 1 Write and save the model and serial number of your unit below. Owner's Record Date Purchased ____________________________________________________________ Purchased From ____________________________________________________________ Installed By ________________________________________________________________ Serial Number ______________________________________________________________ Model _____________________________________________________________________ Installer: Leave this manual for homeowner. Homeowner: Read this manual and keep for future reference. ©2006 Jacuzzi Whirlpool Bath EL21000B 10/06...
-
Page 2: Safety Instruction
F) UNCONSCIOUSNESS RESULTING IN DANGER OF DROWNING. WARNING — THE USE OF ALCOHOL, DRUGS OR MEDICATION CAN GREATLY INCREASE THE RISK OF FATAL HYPERTHERMIA. WARNING — DO NOT TAMPER WITH USER-OPERATED CONTROLS OR SUCH DEVICES. Jacuzzi Whirlpool Bath EL21000B 10/06... -
Page 3: Safety Instruction
NOTE: This is a professional grade product. A knowledge of construction techniques, plumbing and electri- cal installation according to codes are required for proper installation and user satisfaction. We recommend that a licensed contractor perform the installation of all Jacuzzi Whirlpool Bath products. Our warranty does not cover improper installation related problems. -
Page 4: Table Of Contents
Fuzion Overfl ow Installation ______________________________________________________________ 16 Clean Up After Installation _______________________________________________________________ 16 Operating Instructions __________________________________________________________________ 17-21 Salon Control Panel __________________________________________________________________ 18-19 Salon Control Panels (for Mito™ 6) ______________________________________________________ 20 Maintenance Instructions _________________________________________________________________ 22-23 General Troubleshooting Guide ____________________________________________________________ 24 Authorized Service _____________________________________________________________________ 25 Warranty _____________________________________________________________________________ 27-28 NOTE: To obtain a referral for a service agent in your area call 1-800-288-4002. -
Page 5: Specifi Cations
Immediately upon receipt, inspect the shell before installing. Should inspection reveal any damage or defect in the fi nish, do not install the bath. Damage or defect to the fi nish claimed after the bath is installed is excluded from the warranty. Jacuzzi Whirlpool Bath's responsibility for shipping damage ceases upon delivery of the products in good order to the carrier. - Page 6 NOTE: The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4 mm). FOR MITO™ UNIT: Electrical Service Requirements: It requires a dedicated GFCI protected separate circuit. Blower and Motor/Pump: 120 VAC, 20 AMP, 60 Hz. dedicated GFCI protected separate circuit. Jacuzzi Whirlpool Bath EL21000B 10/06...
- Page 7 FOR ALL UNITS: Electrical Service Requirements: All require a dedicated GFCI protected separate circuit. Blower: 120 VAC, 20 AMP, 60 Hz. dedicated GFCI protected separate circuit. Motor/Pump and RapidHeat™: 240 VAC, 20 AMP, 60 Hz. dedicated GFCI protected separate circuit. Jacuzzi Whirlpool Bath EL21000B 10/06...
- Page 8 FOR ALL UNITS: Electrical Service Requirements: All require a dedicated GFCI protected separate circuit. Blower: 120 VAC, 20 AMP, 60 Hz. dedicated GFCI protected separate circuit. Motor/Pump and RapidHeat™: 240 VAC, 20 AMP, 60 Hz. dedicated GFCI protected separate circuit. Jacuzzi Whirlpool Bath EL21000B 10/06...
-
Page 9: Roughing-In Reference
2. Measurements inside each unit represent cutout in fl oor to allow for drain/overfl ow. 3. All measurements are in inches. To convert to millimeters, multiply inches by 25.4. 4. Service Access dimensions given are minimum size. Jacuzzi Whirlpool Bath EL21000B 10/06... - Page 10 2. Measurements inside each unit represent cutout in fl oor to allow for drain/overfl ow. 3. All measurements are in inches. To convert to millimeters, multiply inches by 25.4. 4. Service Access dimensions given are minimum size. Jacuzzi Whirlpool Bath EL21000B 10/06...
- Page 11 2. Measurements inside each unit represent cutout in fl oor to allow for drain/overfl ow. 3. All measurements are in inches. To convert to millimeters, multiply inches by 25.4. 4. Service Access dimensions given are minimum size. Jacuzzi Whirlpool Bath EL21000B 10/06...
- Page 12 2. Measurements inside each unit represent cutout in fl oor to allow for drain/overfl ow. 3. All measurements are in inches. To convert to millimeters, multiply inches by 25.4. 4. Service Access dimensions given are minimum size. Jacuzzi Whirlpool Bath EL21000B 10/06...
-
Page 13: Framing And Support
fi cient air for the blower. Also provide adequate area around 12" unit for air circulation for cooling the motor and to supply suf- fi cient air to the jets. Do not insulate this area or around blower or motor. FRONT 24" HEATER Jacuzzi Whirlpool Bath EL21000B 10/06... -
Page 14: Electrical Connections
Two (2) separate Ground Fault Circuit Interrupter (GFCI) (Except Mito™ 6) are required for the Salon™ Spa units (except Mito™ 6). Install a 240 VAC, 20 AMP RATED GFCI single outlet to the The Mito™ 6 requires a single Ground Fault Circuit Interrupter studwall underneath the bathtub, at least 4 inches (10,2 cm) (GFCI). -
Page 15: Fuzion Control Panel Installation
Apply adhesive sparingly around base of control panel. Thread wire through cutout and to control box. Orientate control panel so that the Jacuzzi logo is read from the inside of the tub. Lower control panel in cutout and press fi rmly to embed adhesive. -
Page 16: Plumbing And Water Supply
After opening the carton, inspect for damage and tubs) the counter is installed. verify that the kit is of the proper fi nish. In the Jacuzzi Whirlpool Remove and open the overfl ow fi tting from the drain kit (sup- Bath drain/overfl... -
Page 17: Operating Instructions
All baths manufactured by Jacuzzi Whirlpool Bath are designed for "fi ll and drain," which means the bath should be drained after each use and fi lled with fresh water by the next bather. This is a health precaution, as these baths are not designed to hold water continuously like pools or spas. - Page 18 General Functions This Jacuzzi tub is equipped with a eight button electronic control panel. The eight button panel controls a two speed pump/ motor, Chromatherapy lighting, air controls, blower, and wave control. LED lights (on the control panel) indicate function levels.
- Page 19 • Pressing a toggle button after pressing the Air Bath Switch increase or decrease the air fl ow through the bottom air channels. Jacuzzi Whirlpool Bath EL21000B 10/06...
-
Page 20: Salon Control Panels (For Mito™ 6)
Simply push down on the switch button to turn on the whirlpool system. To turn the system OFF, push down on the button again. The control switch will automatically shut OFF after 20 minutes. Push down on the switch button to restart the whirlpool system again. Jacuzzi Whirlpool Bath EL21000B 10/06... -
Page 21: Controlling Whirlpool Action
– direction of fl ow, force of water, and (whirlpool jet) force of provided) can purchased and installed on the Mito™ 6. Follow air. All baths manufactured by Jacuzzi Whirlpool Bath are the installations instructions provided with that kit if a heater equipped with fully adjustable or partially adjustable jets, which kit is to be installed at this time. -
Page 22: Maintenance Instructions
Purging the Whirlpool System complete the draining process of the Jacuzzi Luxury/ Designer Air Bath and Salon™ Spa draining system. While the bathtub NOTE: THE WHIRLPOOL SYSTEM SHOULD BE PURGED is being drained, after normal use, dual water sensors monitor AT LEAST TWICE A MONTH the water level. -
Page 23: Maintenance Instructions
Restore the gloss using Meguiar's Mirror Glaze a product light fi xture. specifi cally designed for use on acrylic fi nishes. If Meguiar's Replacement fi xtures are available from your Jacuzzi is not available, an acrylic polish of equal quality or automotive Whirlpool Bath dealer. -
Page 24: General Troubleshooting Guide
NOTE: If unit is within the warranty period, contact Jacuzzi Whirlpool Bath Service Support at 1-800-288-4002 with bath's serial number before work is started. The Serial Number is located on the Specifi cation/Serial Number Plate. See page 24. -
Page 25: Authorized Service
(for location of specifi cation/serial number label see below). BATH PRODUCTS Salon™ Spa baths: The label is located on the wall of the bath near the pump/motor. SPECIFICATION/SERIAL NUMBER PLATE CORE NUMBER - SERIAL NUMBER XXXX - XXXXXX Applicable Electrical Specifications for your unit. - Page 26 USE INSTALLATION INSTRUCTIONS SUPPLIED WITH PRODUCT. Jacuzzi Whirlpool Bath has obtained applicable code (standards) listings generally available on a national basis for products of this type. It is the responsibility of the installer/owner to determine specifi c local code compliance prior to installation of the product.
-
Page 27: Warranty
RETURN OF WARRANTY CARD The attached Warranty Registration Card MUST be fi lled out by the purchaser within thirty (30) days from purchase and mailed to Jacuzzi Whirlpool Bath in order for this warranty to become effective. -
Page 28: Warranty
In order to obtain warranty service, consult your local telephone book for the location of the nearest Jacuzzi Whirlpool Bath Authorized Service Agent.
