Jacuzzi Platinum 2001 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading

Related Manuals for Jacuzzi Platinum 2001

Summary of Contents for Jacuzzi Platinum 2001

  • Page 3: Table Of Contents

    Table of Contents Important Hot Tub Owner Safety Information..............Installation.......................... Inspection and Shipping Claim................Positioning Your Hot Tub..................Electrical Requirements..................Electrical Precautions..................... Outdoor Installation....................Indoor Installation....................Drainage....................... Optional Ozone Generator Installation Instructions..........Preparing the Hot Tub for Filling................Operation..........................Operating Instructions................... Control Panel......................
  • Page 4 Skimmer Basket Maintenance................Filter Maintenance....................Factory Installed Wood Skirt................. Automatic Filtration/Maintenance................Winterizing......................Hot Tub Light......................Cleaning Your Hot Tub................... Covering Your Hot Tub................... Repairs to the Acrylic....................Headrest Pillows...................... Troubleshooting......................... Alternate Use of the Water Rainbow as a Fill Spout............

  • Page 5: Important Hot Tub Owner Safety Information

    We recommend that you always keep the hot tub full of water when it is exposed to direct sunlight and that you keep the Jacuzzi Premium Spas insulating cover in place at all times when the hot tub is not in use. Read and carefully follow the requirements for your hot tub’s support base (found in the section titled, “...
  • Page 6 Important Hot Tub Owner Safety Information Read and Follow ALL Instructions Warning-Risk of injury: Children, the elderly, and the infirm should not use the hot tub unless they are supervised at all times. Infants should not be permitted in the hot tub at water temperatures over 100 F(38 C).
  • Page 7 Important Hot Tub Owner Safety Information Read and Follow ALL Instructions Danger-Risk of injury: Do not remove the suction grille! It is a safety device and must always be in place on the suction fitting to minimize the potential hazard of hair entanglement or body entrapment.
  • Page 8 Important Hot Tub Owner Safety Information Read and Follow ALL Instructions The spa must be installed with adequate access and water drainage system (refer to Installa- tion), to drain water away from electrical components. CAUTION: Do not turn power ON to the hot tub unless it is filled with water to the normal water level, which is to the water level indicator mark on the skimmer frame.

  • Page 9: Installation

    Installation Inspection and Shipping Claim Check for shipping damage upon receipt of the hot tub. Jacuzzi Premium Spas is not responsible for damage to the hot tub sustained during shipment. If damage is evident before unpacking, refer to instructions regarding shipping claims on the outside of the carton and immediately file a claim with the carrier.
  • Page 10 Installation Wood decking is acceptable provided it is constructed so that it meets the requirements outlined on the previous page. However, we recommend a poured, reinforced concrete slab (minimum 4 inches thick) as shown below. Screed Start with the forms built from 2X4’s and 1X2 stakes as shown above. The foundation must be as large as the bottom of the hot tub.
  • Page 11 This can damage certain surfaces over time. If you have any questions regarding the placement or installation of your hot tub, consult your authorized Jacuzzi Premium Spas dealer or service organization. Page 7...

  • Page 12: Electrical Requirements

    Installation Electrical Requirements Your Jacuzzi Premium spa (except the Triton) requires a 230VAC, 50 AMP, 4-wire grounded type GFCI protected electrical service with copper conductors, and must be in a separate circuit having no other appliance connected in that circuit. If you do not have this kind of circuit, a qualified electrician should install the necessary wiring.
  • Page 13 Installation Equipment Area 1. Electrical Cabinet 6. Air Blower 2. Power Supply Entrance 7. Pump Drain Plugs 3. Pump 8. Pump #2 4. Heater 9. Circulation Pump 5. Hot Tub Drain Electrical Cabinet Terminal Block 50A 20A CIRCUIT BOARD Page 9...

  • Page 14: Outdoor Installation

    Jacuzzi Premium Spas is not responsible for damages resulting from excess moisture or water spillage. Consult an architect or engineer for aid in designing your indoor installation.

  • Page 15: Optional Ozone Generator Installation Instructions

    Installation Optional Ozone Generator Installation Instructions Your “ozone ready” hot tub is designed for easy field conversion to an ozone generator system. You will need: A. Complete Ozone Kit B. Mazzei Injector Instructions: 1. Turn OFF electrical power and drain the hot tub. 2.
  • Page 16 Installation 5. Install the ozone generator according to the manufacturer’s instructions. Several commercially available ozone generators will fit easily. OZONE GENERATOR USE #6 SCREWS MOUNTING BOARD ELECTRICAL CABINET FIGURE 3 - MOUNTING BOARD 6. Attach the ozone delivery tubing (supplied with the ozone generator) between the ozone generator outlet port and the ozone injector inlet.

  • Page 17: Preparing The Hot Tub For Filling

    Installation Preparing the Hot Tub for Filling 1. Remove the plastic sheet covering the spa. NOTE: Stepping into the hot tub with shoes will scratch the acrylic surface. 2. Remove any packing materials from the hot tub. 3. The filter cartridges are packaged in a plastic bag which MUST be removed before operating the hot tub.
  • Page 18 All Jacuzzi Premium spas are factory tested for proper operation and water tight connections prior to shipment. If leaks or other malfunctions are detected, immediately notify your Jacuzzi Premium Spas dealer or Authorized Service Agent.

  • Page 19: Operation

    Now that the hot tub is in place, you are probably eager to take advantage of its unique designed-in features - especially the patented hydromassage performance. Besides being a beautiful addition to your indoor decor or outdoor landscaping, your Jacuzzi Premium spa will provide you with the ultimate in hot tub pleasure.

  • Page 20: Control Panel

    Operation Control Panel The control panel is easy to use with fingertip control of all the hot tub’s functions. FILTER 1 I0IF HEAT STANDARD Temperature Control When either of these buttons is pressed once, the display will show the temperature that has been set, in addition to the words SET HEAT.
  • Page 21 Operation Light Control Press the button once to activate the highest setting, again for the medium setting and again for the lowest setting. A fourth press of the button will turn the light OFF. The light automatically turns OFF after four hours of operation. Time Control Press to display the time of day, press again to display the current water temperature.

  • Page 22: Control Panel Operation

    Operation Control Panel Operation Initial Start-up The hot tub will automatically begin to operate when electrical power is applied. There is no ON/OFF switch for the hot tub system. At power up, the jet pump will operate for one minute to clear any trapped air in the plumbing.

  • Page 23: Changing Heating Cycles

    Operation Changing Heating Cycles If you wish to leave the heater OFF during the day, the following procedure can be used to change the automatic heater operation. Press . The time of day will be shown. Then press . The SET TIME message will be shown.

  • Page 24: Panel Lock

    Operation Panel Lock The panel lock is provided to prevent tampering with the control panel. When the panel lock is engaged, all the automatic hot tub functions will operate normally. Press the following buttons within 3 seconds to activate the lock: Press .

  • Page 25: Unlocking The Panel

    Operation Unlocking the Panel To unlock the panel, these buttons must be pressed in the correct sequence and within 2 seconds. When the last button is touched, the lock symbol will disappear. All buttons are now active. Press , then press , then press Display Messages These are some of the messages you may see on the center display.

  • Page 26: Remote Controller (Pinnacle And Triton)

    Operation Display Messages (Continued) Message Meaning Freeze Protection: If a freeze condition is detected, the pump(s) are automatically activated. This is also a normal hot tub function; no corrective action is necessary. Open Sensor: The hot tub is deactivated. The high limit temperature sensor is nonfunctional.

  • Page 27: Remote Controller Operation

    Operation Remote Controller Operation Jets Control Press this button once to activate a jet pump on one side of the hot tub; press it twice for both pumps simultaneously for maximum effect. Press it a third time to turn off the jet pumps. This button does not affect the filter pump operation which is an independent function.

  • Page 28: Normal Operation/Whirlpool System

    Operation Normal Operation/Whirlpool System You can enjoy the hot tub with or without activating the whirlpool. Either way, bathing in your hot tub can be pleasurable, as well as therapeutic. After a busy, stressful day, you can look forward to soaking in your hot tub in still water with no turbulence - only the gentle warmth of the soothing and relaxing water.

  • Page 29: Silent Air Induction

    Operation Silent Air Induction The intensity of the whirlpool action is determined by how much air is inducted into the water. You can control this by adjusting the air induction control knobs located on the hot tub rim. For maximum air induction, rotate each control knob fully counterclockwise to the largest circle. For fewer air bubbles, decrease the amount of air induction by rotating the control knobs clockwise.

  • Page 30: Water Rainbow

    Operation Water Rainbow Activate the water feature by rotating downward the flow control lever located on the left side of the spout. Use this lever to adjust the amount of water flowing through the Water Rainbow spout. Turning OFF the flow at the fully adjustable jets will dramatically increase flow through the Water Rainbow and other jets.

  • Page 31: Diverter Valves (Triton Only)

    Detailed stereo/CD information is provided on the stereo manufacturer’s manual that is packed with the hot tub installation instructions. NOTE: The quality of AM reception will vary by locality. Jacuzzi Premium is not responsible for the quality of AM reception.

  • Page 32: Maintenance

    Your Jacuzzi Premium Spas hot tub can be equipped with an optional ozone generator which operates automatically during the system filter operation. Ozone is fed into the hot tub footwell where it mixes with the water.

  • Page 33: Filtration

    Jacuzzi Premium Spas dealer. Such conditions include the following: Foaming: A defoamer is available to minimize foaming of the water. This condition is usually caused by the addition of soaps or oils, or other fatty substances to the hot tub water.

  • Page 34: Water Chemistry

    Obtain a water quality test kit, designed especially for hot tubs, from your Jacuzzi Premium Spas dealer. The test kit must be of the type which allows you to test for the disinfectant (chlorine) level, pH, and total alkalinity. Ensure that the chemicals used in your hot tub are especially for hot tub use, and not for swimming pools, as water quality maintenance of hot tubs and of swimming pools is very different.

  • Page 35: Balancing Ph

    Maintenance Balancing pH For good hygiene and equipment longevity, maintain the pH of your hot tub water according to the instructions provided. pH is the measure to determine if the hot tub water is too acidic (low pH) or too alkaline (high pH). The ideal range for hot tub water is 7.4 to 7.6 pH. For excessive acidity (below 7.2 pH) add soda ash or sodium bicarbonate to the hot tub water.

  • Page 36: Water Quality Definitions

    Maintenance Water Quality Definitions pH: A chemical term used in expressing relative acidity or alkalinity in numerical values with 7.0 usually regarded as neutral, and for purposes of this manual, indicating pure water. From 7 to 0 indicates increasing acidity, and 7 to 14 indicates alkalinity. PPM: Parts per million Ozone: Triatomic oxygen (O ), a gas found commonly in nature, which, when dissolved in hot tub water helps destroy impurities and contaminents.

  • Page 37: Water Level/Drain

    Maintenance Water Level/Drain The water level in the hot tub must be maintained at the normal level. Evaporation and splashing will cause the water level to drop. When concentrations of impurities from evaporation, water quality chemicals, body oils, perfumes, dirty feet, and winds, etc., accumulate in the hot tub and cannot be filtered out, it is necessary to drain your hot tub and refill it with fresh water.

  • Page 38: Skimmer Basket Maintenance

    Oils will coat the filter, resulting in a reduced flow. To remove such materials, soak the cartridge in a plastic pail containing a commercial filter cleaning solution (available from your Jacuzzi Premium Spas dealer or most pool supply stores). Follow the manufacturer’s instructions for use.

  • Page 39: Factory Installed Wood Skirt

    Maintenance Factory Installed Wood Skirt Your hot tub is supplied with a factory-installed wood skirt which completely surrounds the hot tub. The skirt can be opened for service. If it becomes necessary to remove one or more of the skirt panels for service access, simply remove all the screws from the panel being detached.

  • Page 40: Automatic Filtration/Maintenance

    Maintenance Automatic Filtration/Maintenance If you plan to be away, minimum water quality will be maintained by running the filter system. If you will be away for an extended period, however, we recommend that you drain the hot tub (following the procedure described under Winterizing on this page), as long periods without maintenance of water quality could be detrimental to the hot tub.

  • Page 41: Hot Tub Light

    Maintenance Winterizing (Continued) Remove, clean and store the filter cartridge(s) in a dry location. Keep water and debris out by covering with a hot tub cover. Before using the hot tub again, review the Operating Instructions. In a warm climate where there are occasional freezing temperatures, your hot tub is automatically protected against freezing.

  • Page 42: Cleaning Your Hot Tub

    2-3 inches before cleaning; then refill to the normal level. Covering Your Hot Tub An optional hot tub cover for your hot tub is available from your Jacuzzi Premium Spas dealer. Use of this cover will help reduce energy costs by minimizing heat loss and evaporation. In addition, the attractive cover is an effective means of preventing debris such as leaves and dirt from entering your hot tub when not in use.

  • Page 43: Repairs To The Acrylic

    Major scratches or gouges which penetrate the acrylic surface will require refinishing. Ask your Jacuzzi Premium Spas dealer for special instructions. Headrest Pillows Clean the pillows regularly with soap and water and a clean cloth. Use a vinyl conditioner once a month to maintain the water resistance and lustrous finish.

  • Page 44: Troubleshooting

    H. Call a qualified electrician H. Subnormal voltage. or your power company. *NOTE:The skills and tools necessary for the safe repair of this hot tub require the services of qualified personnel. Contact your Jacuzzi Premium Spas dealer or service organization. Page 40...
  • Page 45 G. Motor windings burned out. H. * H. Defective starting switch inside motor. *NOTE:The skills and tools necessary for the safe repair of this hot tub require the services of qualified personnel. Contact your Jacuzzi Premium Spas dealer or service organization. Page 41...
  • Page 46 D. GFCI tripped. D. Reset GFCI. E. * E. Faulty motor. *NOTE:The skills and tools necessary for the safe repair of this hot tub require the services of qualified personnel. Contact your Jacuzzi Premium Spas dealer or service organization. Page 42...

  • Page 47: Alternate Use Of The Water Rainbow As A Fill Spout

    Alternate Use of the Water Rainbow as a Fill Spout You can use your Water Rainbow as a fill spout by permanently plumbing it to a fresh water supply if local codes permit. Local plumbing codes may require the use of an anti-siphon valve for such a connection.
  • Page 48 Notes Page 44...
  • Page 49 Notes Page 45...
  • Page 50 Notes Page 46...
  • Page 52 14525 Monte Vista Avenue, CA 91710 Part #2530-300 - REV. A - 2001 Jacuzzi Premium Spas...
