S W I M
S P A
C O L L E C T I O N
J-4000
™
PERFORMANCE
(4,72 m / 16 ft. - 5,64 m / 19 ft. )
2019 SWIM SPA
installation guide
technical data
All installations must follow local electrical and building codes. Please consult your local business and
planning division for your codes in your area.
JACUZZI
WILL NOT BE RESPONSIBLE FOR ANY ERRORS IN INSTALLATIONS
®
OR CODE INFRACTIONS.
data di validità: gennaio 2019 (sostituisce le precedenti)
Advertisement
Table of Contents
Related Manuals for Jacuzzi SWIM SPA Series
Summary of Contents for Jacuzzi SWIM SPA Series
- Page 1 All installations must follow local electrical and building codes. Please consult your local business and planning division for your codes in your area. JACUZZI WILL NOT BE RESPONSIBLE FOR ANY ERRORS IN INSTALLATIONS ® OR CODE INFRACTIONS.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. Types of installations pag. 4 - Type of installation: inground 1.1 “Free Standing” J-3000™ 4,72m/16ft. - plain view/section pag. 18 1.2 Partial-in grade Full inground (cross section) pag. 19 Partial inground (cross section) pag. 19 1.3 Below-grade (outdoor or indoor) Side view/cross section pag. -
Page 4: Types Of Installations
1.1 “Free Standing” This installation refers to a swim spa that is placed on a concrete pad, above ground and with a Jacuzzi Cabinet. Can be adjacent to a deck or butted up to a deck. 1.2 Partial-in grade This installation refers to a swim spa that is partially recessed in the ground. - Page 5 4.72m (16 ft.) J-4000 ™ SWIM SPA DIMENSIONS: 472 cm. x 236 cm. x 135 cm. USABLE SWIM AREA 284 cm. DRY WEIGHT 1162 kg. TOTAL FILLED WEIGHT. 8800 kg. AVERAGE SPA VOLUME 7638 L PUMPS No° 4 pumps (2-speed type), 3 Hp CURRENT DRAW.
-
Page 6: J-3000™ 5,64M/19Ft. Pag
5.64m (19 ft.) J-4000™ SWIM SPA DIMENSIONS 564 cm. x 236 cm. x 135 cm. USABLE SWIM AREA 376 cm. DRY WEIGHT 1374 kg. TOTAL FILLED WEIGHT 10412 kg. AVERAGE SPA VOLUME 9038 L PUMPS No° 4 pumps (2-speed type), 3 Hp CURRENT DRAW 1 x 32A: when pumps are ON, heaters are OFF 3 x 16A: when pumps are ON, heaters are OFF... -
Page 7: Pag
SAFETY COMES FIRST. WHEN INSTALLING & USING ELECTRICAL EQUIPMENT, BASIC SAFETY PRECAUTIONS MUST ALWAYS BE FOLLOWED! 1. READ AND FOLLOW ALL INSTRUCTIONS Codes and Regulations in effect at the time of installation. It is the installer’s responsibility to select the materials ac- cording to use, carry out the installation correctly, and verify the condition of the network to which the appliance will be connected, as well as its suitability in ensuring usage safety during maintenance and inspection operations. -
Page 8: Wiring Size Pag
2.4 Wiring Size The cable cross-section measurements must be chosen according to the system consumption, as well as the cable routes country where the Swim Spa is installed. IMPORTANT NOTE: This Guide is for standard installations where the wire run is 15 m (50 ft. ) or less. For longer wire runs, consult a Power Requirements Terminal Block Connections 1. -
Page 9: Typical Swim Spa Wiring Diagrams Pag
2.5 Typical Swim Spa Wiring Diagrams national regulations in force. It is the installer’s responsibility to select the materials according to use, carry out the instal- lation correctly, and verify the condition of the network to which the appliance will be connected, as well as its suitability in ensuring usage safety during maintenance and inspection operations. -
Page 10: Delivery And Handling Considerations
3 Delivery and Handling Considerations All Jacuzzi Swim Spas are shipped with a layer of protective foam Each Swim Spa is shipped from the factory strapped onto a wood skid. The swim spa can then be lifted by a crane into place. -
Page 11: Pag
4.1 Preparation Installation of a level concrete pad is mandatory; If there is a possibility that the pad could shift by freezing / thawing ground movement (such as in clay regions, and / or areas with high water tables) concrete footings extending below the frost line are recommended. -
Page 14: Type Of Installation: "Free-Standing
Type of installation: “free-standing” (mod. J-4000 4,72 m/16 ft.) plain view concrete pad 236 cm*... -
Page 15: J-3000™ 5,64M/19Ft.- Plain View Pag
Type of installation: “free-standing” (mod. J-4000 5,64 m/19 ft.) plain view concrete pad 236 cm*... -
Page 16: Below-Grade Or Partial In-Grade
This forms a Vault or ’bunker‘, in which the swim spa is placed. Call before you dig! Please make sure you have any permits in place that are required from your municipality. Jacuzzi this makes the space under the spa ®... -
Page 17: Service Access Pag
5.7 Overall support Your Jacuzzi Swim Spa is equipped with a factory installed load support substructure, which distributes the weight of the water over the entire foot print area of the swim spa. Although the lip of the swim spa must be supported to ensure it remains level, NEVER SUSPEND duct damage and/or serious personal injury. -
Page 18: Type Of Installation: Inground
Type of installation: inground (mod. J-4000 4,72 m/16 ft.) plain view / section hollow concrete block with steel re-bar sump pump and poured concrete in cavity space switch gravel drain pit access service area ~ 60 cm* ~ 60 cm* 236 cm* (wide crawl way) (wide crawl way) -
Page 19: Full Inground (Cross Section) Pag
(stone size: 2-2,5 cm) * Jacuzzi can not be held liable for the accuracy of thi drawing; it is purely provided as a guide only. As each Swim Spa installation has its own set of challenges and variations due to materials used and location of the installation. -
Page 20: Side View/Cross Section Pag
Type of installation: inground (mod. J-4000 4,72 m/16 ft.) side view / cross section hollow concrete block with steel re-bar and poured concrete in cavity space 472 cm* ground level steel frame support ~ 60 cm* (wide crawl way) steel frame support steel... - Page 21 ** necessari soltanto per le installazioni in regioni che sono caratterizzate da gelo e disgelo support posts hollow concrete block with steel re-bar and poured concrete in cavity space ground ~ 90 cm* service area level steel frame support steel frame support steel frame support...
-
Page 22: J-3000™ 5,64M/19Ft. - Plain View/Section Pag
Type of installation: inground (mod. J-4000 5,64 m/19 ft.) plain view / section sump pump hollow concrete block with steel re-bar and poured concrete in cavity space gravel drain pit access service area ~ 60 cm* 236 cm* ~ 60 cm* (wide crawl way) (wide crawl way) -
Page 23: Full Inground (Cross Section) Pag
Full inground (cross section) 236 cm* ground level steel steel frame frame support support ~ 60 cm* ~ 60 cm* (wide crawl (wide crawl way) way) steel frame hollow concrete block with support steel re-bar and poured concrete in cavity space sump pump ** concrete... -
Page 24: Side View/Cross Section Pag
Type of installation: inground (mod. J-4000 5,64 m/19 ft.) side view / cross section hollow concrete block with steel re-bar and poured con- crete in cavity space 564 cm* ground level steel frame support ~ 60 cm* (wide crawl way) steel frame support... - Page 25 * Jacuzzi can not be held liable for the accuracy of thi drawing; it is purely provided as a guide only. As each Swim Spa installation has its own set of challenges and variations due to materials used and location of the installation. ** Only required in installations that are in regions that experience freezing and thawing.
-
Page 26: Filling And Draining
6 Filling and Draining 6.1 General considerations • Be sure to check with your local by-laws regarding disposal of waste water from your swim spa. • Filling through the skimmer is optimal for reducing / eliminating any air locks. 6.2 Indoor installations There will be water lost in the swim spa due to splash out, hence, you will need to top up the Swimspas periodically. -
Page 27: Hard Cover Storage
9 Hard Cover Storage 9.1 Hard Cover If your swim spa comes with a hard cover, make sure to prepare storage area for when the swim spa is being used. The swim spa cover comes standard in a number of sections that are velcroed together depending on the size. - Page 28 Direzione e coordinamento Jacuzzi Brands, LLC (USA) SS Pontebbana km. 97,200 33098 Valvasone Arzene (PN) www.jacuzzi.eu info@jacuzzi.eu Jacuzzi Europe SPA JACUZZI EUROPE S.p.A. • all rights reserved • JUNE 2019...
