- Page 1 1002FX / 1202FX OPERATING MANUAL AND USER GUIDE www.wharfedalepro.com...
-
Page 2: Table Of Contents
OPERATING MANUAL AND USER GUIDE TABLE OF CONTENTS IMPORTANT WARNINGS & SAFETY INSTRUCTIONS ...........2 INTRODUCTION .......................4 ABOUT THE CONNECT 002FX/202FX ................4 COMMON FEATURES ......................4 EFFECTS SECTION (FX Interface): .................5 CONNECT 002FX FEATURES ..................6 CONNECT 202FX FEATURES ..................6 MONO CHANNEL WALKTHROUGH ................7 STEREO CHANNEL WALKTHROUGH ................7 MASTER SECTION WALKTHROUGH ................8 REAR PANEL WALKTHROUGH ..................9... -
Page 3: Important Warnings & Safety Instructions
CONNECT 1002FX / 1202FX IMPORTANT WARNINGS & SAFETY INSTRUCTIONS Read these instructions. Follow all instructions. Keep these instructions. Heed all warnings. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. - Page 4 OPERATING MANUAL AND USER GUIDE ATTENTION: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR 19. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
-
Page 5: Introduction
Connect 002FX/202FX mixer. ABOUT THE CONNECT 1002FX/1202FX The Connect 002FX/202FX from Wharfedale Pro are high quality compact mixers that are suitable for a wide range of applications. Professional big mixer features such as Phantom powered, balanced XLR microphone inputs give you full functionality and great sound in an ultra compact and cost effective package that is ideal for live sound, home studio recording and fixed installations. -
Page 6: Effects Section (Fx Interface)
OPERATING MANUAL AND USER GUIDE EFFECTS SECTION (FX Interface): You have a choice of 56 different effects, from Reverb to Flanging to Delay. You can send them to the main mix outputs. . Shows which of effect 2. Shows when the FX bus is overloaded 3. -
Page 7: Connect 002Fx Features
CONNECT 1002FX / 1202FX CONNECT 1002FX FEATURES • 2 Mono Mic/Line Channels and 8 Stereo Channels • Input Gain Controls On All Mono Channels • Studio grade phantom powered microphone pre-amps • Ultra musical 3 band EQ with high pass filters On All Mono Channels •... -
Page 8: Mono Channel Walkthrough
OPERATING MANUAL AND USER GUIDE MONO CHANNEL WALKTHROUGH Balanced XLR input for connecting microphones Balanced/Unbalanced TRS input for line level sources Gain control for calibrating sources and applying correct gain structure High EQ centred at 2KHz Mid EQ centred at KHz Low EQ centred at 80Hz Sends to the internal FX engine or to effect HPF with 80Hz cutoff point... -
Page 9: Master Section Walkthrough
CONNECT 1002FX / 1202FX MASTER SECTION WALKTHROUGH Balanced/unbalanced TRS main outputs Used for control room monitoring, connect directly to your power amplifier or active speakers For connecting FX send For connecting headphones 2-Track inputs for playback devices (⅛" jack takes priority) 2-Track outputs for recording devices (⅛"... -
Page 10: Rear Panel Walkthrough
OPERATING MANUAL AND USER GUIDE REAR PANEL WALKTHROUGH AC Supply input, use only the supplied Wharfedale Pro authorised power supply Turns the Connect Mixer on or off Switches the global +48V phantom power on or off WIRING DIAGRAM SIGNAL INPUT... -
Page 11: Guide Connect 002Fx Dimensional Drawing
CONNECT 1002FX / 1202FX GUIDE CONNECT 1002FX DIMENSIONAL DRAWING... -
Page 12: Guide Connect 202Fx Dimensional Drawing
OPERATING MANUAL AND USER GUIDE GUIDE CONNECT 1202FX DIMENSIONAL DRAWING... -
Page 13: Connect002Fx Block Diagram
CONNECT 1002FX / 1202FX CONNECT1002FX BLOCK DIAGRAM... -
Page 14: Connect202Fx Block Diagram
OPERATING MANUAL AND USER GUIDE CONNECT1202FX BLOCK DIAGRAM... -
Page 15: Specifications
CONNECT 1002FX / 1202FX SPECIFICATIONS Model Connect 002FX Connect 202FX Maximum Balanced Main XLR Balanced out +26dBu ±dBu Main XLR Balanced out +26dBu ±dBu Output Level (%T.H.D. Main 1/4" Jack Balanced out +26dBu ±1dBu Main 1/4" Jack Balanced out +26dBu ±1dBu... -
Page 16: Wharfedale Pro Limited Warranty
IAG HOUSE, Sovereign Court, Ermine Business Park Huntingdon, Cambs, PE29 6XU, England www.wharfedalepro.com Wharfedale Professional reserves the right to alter or improve specifications without notice. All rights reserved © 202 Wharfedale Pro. Wharfedale Pro is a member of the IAG Group.
