- Page 1 P R I M E R G Y E C O N E L 1 0 P R I M E R G Y E C O N E L 1 0 P R I M E R G Y E C O N E L 1 0 P R I M E R G Y E C O N E L 1 0 OPERATING MANUAL OPERATING MANUAL...
- Page 2 ... any technical problems or other questions which you would like to be clarified? Please contact: • your sales partner • your sales outlet Further information can be found in the "Safety, Warranty and Ergonomics" manual. The latest information on our products, tips, updates, etc., can be found on the Internet under: http://www.fujitsu-siemens.com...
- Page 4 Este manual ha sido impreso sobre papel reciclado. Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH A26361-K831-Z100-1-7619 A26361-K831-Z100-1-7619 A26361-K831-Z100-1-7619 A26361-K831-Z100-1-7619 Bestell-Nr./Order No.:...
-
Page 5: Operating Manual
Introduction Important notes PRIMERGY ECONEL 10 Preparing for use Operation Troubleshooting and tips Operating Manual System expansions Technical data Index April 2001 edition... - Page 6 All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged. Copyright ã Fujitsu Siemens Computers GmbH 2001 All rights, including rights of translation, reproduction by printing, copying or similar methods, even of parts are reserved.
-
Page 7: Table Of Contents
Contents Introduction .............................1 Notational conventions ........................1 Important notes ..........................3 Safety ..............................3 Manufacturer’s notes .........................3 Energy saving..........................3 Disposal and recycling.......................4 CE certificate ..........................4 FCC Class B Compliance Statement ..................5 Transporting the PC ..........................6 Cleaning the PC ..........................6 Preparing for use..........................7 Unpacking and checking the delivery ....................7 Steps for initial setup .........................7... - Page 8 Contents System expansions........................31 Information about boards ......................31 Opening the system unit ......................... 32 Assembling the system unit ......................33 Installing and removing a board ...................... 33 Installing a board........................34 Removing a board........................35 Installing an additional serial port ....................
-
Page 9: Introduction
Introduction This Operating Manual tells you how to put your PC into operation and how to operate it in daily use. The Operating Manual applies for all configuration levels. Depending on the configuration level chosen some of the hardware components described may not be available on your PC. Please observe the notes on your operating system. -
Page 11: Important Notes
Important notes In this chapter you will find information regarding safety which it is essential to take note of when working with your PC. The manufacturer's notes contain helpful information on your PC. Safety Pay attention to the information provided in the manual "Safety, Guarantee and Ergonomics"... -
Page 12: Disposal And Recycling
Any components not reclaimed will be disposed of in an environmentally acceptable manner. Devices protected by a 36 month warranty from Fujitsu Siemens meet the requirements of the eco-label "Blauer Engel". The warranty starts on the day of delivery (sale date) by Fujitsu Siemens Computers or a Fujitsu Siemens partner. -
Page 13: Fcc Class B Compliance Statement
• Consult the dealer or an experienced radio/TV technician for help. Fujitsu Siemens Computers GmbH is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Fujitsu Siemens Computers GmbH The correction of interference caused by such unauthorized modification, substitution or attachment will be the responsibility of the user. -
Page 14: Transporting The Pc
Important notes Transporting the PC Transporting the PC Transport all parts separately in their original packaging or in a packaging which protects them from knocks and jolts, to the new site. Do not unpack them until all transportation manoeuvres are completed. Never drop the monitor (risk of implosion)! Cleaning the PC Turn off all power and equipment switches and remove the power plug from the power... -
Page 15: Preparing For Use
Preparing for use Please take note of the safety information in the chapter "Important notes". Unpacking and checking the delivery It is recommended not to throw away the original packaging material! It may be required for reshipment at some later date. Ê... -
Page 16: Setting Up The Pc
Preparing for use Setting up the PC Setting up the PC When installing your PC, give consideration to the recommendations and safety notes in the manual "Safety, Guarantee and Ergonomics". Set up the PC only in its correct orientation. The points to observe are illustrated on the following pages. -
Page 17: Connecting The Mouse
Connect the monitor, mouse and keyboard Preparing for use Connecting the mouse Depending on the equipment level selected, your PC will be supplied with a PS/2 mouse or a USB mouse. Connecting a PS/2 mouse Ê Connect the PS/2 mouse to the PS/2 mouse port on the system unit. -
Page 18: Connecting The Pc To The Electricity Supply
Preparing for use Connecting the PC to the electricity supply Connecting the PC to the electricity supply 100 V - 125 V 200 V - 240 V Ê Check the voltage setting. The value displayed must agree with the local line voltage: 115 = 100 V to 125 V 230 = 200 V to 240 V If the rated voltage does not agree with the local line voltage, you must move the wiper... -
Page 19: Connecting The Monitor
Initial switch-on: Software will be installed Preparing for use Connecting the monitor Ê Follow the instructions contained in the monitor manual to prepare the monitor for operation. Ê Plug the data cable of the monitor into the monitor port of the system unit. Ê... -
Page 20: Initial Switch-On: Software Will Be Installed
Preparing for use Initial switch-on: Software will be installed The power-on indicator (1) lights up orange. (If the power-on indicator does not light up, see the section "Power-on indicator remains unlit after you have switched on your device".) Ê Press the ON/OFF switch (2). The PC starts. -
Page 21: Connecting External Devices
Connecting external devices Preparing for use Connecting external devices Do not connect or disconnect cables during a thunderstorm. Always take hold of the actual plug. Never unplug a cable by pulling the cable itself. Connect and disconnect the cables in the order described below. With the exception of USB devices, the power plug must be pulled when you connect the external devices! Read the documentation on the external device before connecting it. -
Page 22: Connections On The System Unit
Preparing for use Connecting external devices Connections on the system unit The ports for external devices are on the rear and on the front of the system unit. The ports available on your PC depend on the configuration level you have selected. The standard ports are marked with the symbols shown below (or similar). -
Page 23: Connecting External Devices To The Serial Port
Connecting external devices Preparing for use Connecting external devices to the serial port External devices can be connected to the serial port (e.g. a modem). Ê Connect the data cable to the external device. Ê Connect the data cable to the serial port For an exact description of how to connect external devices to the serial port , please see the device documentation. -
Page 25: Operation
Operation Switching on the PC Ê Switch the monitor on (see the Operating Manual for the monitor). Ê Switch the PC on with the ON/OFF switch. The power-on indicator turns green and the PC will start. While the PC boots, the screen remains dark for up to a minute depending on the system configuration. -
Page 26: Indicators On The System Unit
Operation Indicators on the system unit Indicators on the system unit 1 = Floppy disk indicator 4 = Power-on indicator 2 = CD-ROM indicator 5 = ON / OFF switch 3 = Hard disk indicator 1 - Floppy disk indicator The indicator lights up when the floppy disk drive of the system unit is accessed. -
Page 27: Keyboard
Keyboard Operation 5 - ON/OFF switch Switches the PC on or off. With Windows 98 with ACPI or with Windows 2000 you can set additional functions of the ON/OFF switch in the Control Panel (Power management). Keyboard 1 = Function keys 4 = Cursor control keys 2 = ON/OFF switch (optional) 5 = numeric keypad (calculator keypad) - Page 28 Operation Keyboard Shift key enables upper-case letters and the upper key symbols to be used. Alt Gr (e.g. German keyboard) Alt Gr produces a character shown on the right-hand side of a key (e.g. the character "\" on the key [ß] [ß] [ß] [ß]).
-
Page 29: Working With Floppy Disks
Working with floppy disks Operation Working with floppy disks Follow the instructions supplied by the vendor of the floppy disks. Never clean the floppy disk drives with cleaning disks. Even one attempt would destroy the read/write head in the disk drive within 20 seconds. 1 = Insertion direction 2 = Label area 3 = Write protection switch for a 720 KB or a 1.44 MB floppy disk... -
Page 30: Property And Data Protection
Operation Property and data protection Property and data protection Software functions and mechanical locking offer a broad range of functions for protecting your PC and your personal data from unauthorized access. You can also combine these functions. Anti-theft protection There are two ways to protect your PC from theft: •... -
Page 31: Bios Setup Security Functions
Property and data protection Operation BIOS Setup security functions The Security menu in BIOS Setup offers you various options for protecting your personal data against unauthorized access, e.g.: • Preventing unauthorized BIOS Setup entry • Preventing unauthorized system access • Preventing unauthorized access to the settings of boards with their own BIOS •... - Page 32 Operation Property and data protection PC Lock permissions You can initialize a SmartCard with one of the following rights: System The system starts following entry of the user PIN. You can change the user PIN. Setup You can open and change the BIOS Setup and change the user PIN. System+Setup The system starts following entry of the user PIN.
-
Page 33: Troubleshooting And Tips
Troubleshooting and tips Take careful note of the safety warnings in the "Safety, Warranty and Ergonomics" manual and in the "Preparing for use" chapter, when you connect or disconnect cables. If a fault occurs, try to correct it as described: •... -
Page 34: Troubleshooting And
Troubleshooting and tips Power-on indicator remains unlit after you have switched on your d The screen stays blank If your screen remains blank this may be due to the following: Monitor is switched off Ê Switch your monitor on. Power saving has been activated (screen is blank) Ê... -
Page 35: Troubleshooting And
No mouse pointer displayed on the screen Troubleshooting and tips Wrong monitor has been set under Windows 2000 Ê Restart the PC. Ê If the message Starting Windows appears, press function key [F8] [F8] [F8] [F8]. The Windows 2000 Advanced Options Menu appears. Ê... -
Page 36: Time And/Or Date Is Not Correct
Troubleshooting and tips Time and/or date is not correct Time and/or date is not correct You can set the time and date in the BIOS Setup or in the operating system. Ê Set the time and date. If the time and date are repeatedly wrong when you switch on your PC, the on-board battery is flat. - Page 37 Tips Troubleshooting and tips BIOS settings in Power Management are not activated (Windows 9x with APM function) The Auto insert notification setting may be active for the CD-ROM drive. This setting causes Windows 9x to inquire about any modifications on the drive at regular intervals. Because of this the timer for the idle time cannot time out.
-
Page 39: System Expansions
System expansions It may be necessary to update the BIOS when carrying out a system expansion or hardware upgrade. In this instance, please contact our customer service center. When installing components with a high power loss, make sure that the maximum permissible temperatures of the individual components are not exceeded. -
Page 40: Opening The System Unit
System expansions Opening the system unit Opening the system unit Ê Switch the PC off. The PC may not be in the Suspend mode! Please take note of the safety information in the chapter "Important notes". Pull the power plug out of the power outlet! Ê... -
Page 41: Assembling The System Unit
Assembling the system unit System expansions Assembling the system unit Ê Place the top cover on the system unit in the direction of the arrow (1) so that the distance (a) is approx. 10 mm. Ê Push the top cover in the direction of the arrow (2). Make sure that the eye (b) for the anti-theft protection fits in the recess on the top cover. -
Page 42: Installing A Board
System expansions Installing and removing a board Installing a board Ê Open the system unit (see "Opening the system unit"). Ê Remove the screw (1). Ê Remove the rear slot cover plate from the slot (2). Do not dispose of the cover plate. For cooling, protection against fire and in order to comply with EMC regulations, you must refit the cover plate if you remove the board. -
Page 43: Removing A Board
Installing an additional serial port System expansions Removing a board Ê Open the system unit (see "Opening the system unit"). Ê Disconnect the cables connected to the board. Ê Remove the screw (1). Ê Remove the board from the system unit (2). Ê... -
Page 44: Installing And Removing Drives
System expansions Installing and removing drives Installing and removing drives The system unit houses a total of three accessible drives (two 5 1/4-inch drives and one 3 1/2-inch drive) and one non-accessible half-height (Slimline) drive. IDE drives By default four IDE drives are supported. Ideally hard disks are connected to IDE port 1, and accessible drives, for example CD-ROMs, to IDE port 2 (see also the Technical Manual for the system board). - Page 45 Installing and removing drives System expansions Ê Slide the drive into the system unit (1). Ê Fasten the drive into place with the screws (2). Ê Plug the connectors of the data cable and the power supply cable into the drive (3). Make sure the polarity is correct.
-
Page 46: Removing An Accessible Drive
System expansions Installing and removing drives Removing an accessible drive Ê Open the system unit (see "Opening the system unit"). Ê Pull the data and the power supply connectors from the desired drive (1). Ê Remove the screws (2) and take the drive out of the system unit (3). For cooling, protection against fire and in order to comply with EMC regulations, you must refit the plastic cover. -
Page 47: Changing The Floppy Disk Drive
Installing and removing drives System expansions Changing the floppy disk drive Ê Open the system unit (see "Opening the system unit"). Ê Pull the data and the power supply connectors from the floppy disk drive (1). Ê Remove the screws (2) on the left side of the floppy disk drive. Ê... - Page 48 System expansions Installing and removing drives Ê Remove the screws. Ê Take the new floppy disk drive out of its packaging. Ê Replace the floppy disk drive. Ê Fasten the drive with the screws. Ê Slide the drive into the system unit (1). Ê...
-
Page 49: Replacing A Hard Disk Drive
Installing and removing drives System expansions Replacing a hard disk drive Ê Open the system unit (see "Opening the system unit"). Removing the hard disk carrier Ê Remove the screw (1) and push the hard disk carrier in the direction of the arrow (2) out of its securing lugs. - Page 50 System expansions Installing and removing drives Replacing a hard disk drive Ê Remove the screws of the hard disk drive you want to replace. Ê Take the new hard disk drive out of its packaging. Ê Make the required settings (e.g. master/slave, stand alone) on the drives. Ê...
-
Page 51: Mounting A Hard Disk Drive In A 5¼" Slot
Installing and removing drives System expansions You may have to check the entry for the drive in the BIOS Setup. Mounting a hard disk drive in a 5¼" slot To do this, you require a special mounting frame. Ê Open the system unit (see "Opening the system unit"). -
Page 52: Installing A Usb Front Panel
System expansions Installing and removing drives Installing a USB front panel Ê Remove the system board carrier as described in "Replacing processor". Ê Remove the cover of the bay by pressing against it from the inside. Ê Position the USB front panel in the bay (1) and secure the USB front panel with the screws (2). Ê... -
Page 53: Removing A Usb Front Panel
Extensions to the system board System expansions Removing a USB front panel Ê Remove the system board carrier as described in "Replacing processor". Ê Disconnect the cable from the USB front panel and from the system board. Ê Remove the screws (1) and take out the USB front panel of the slot (2). Ê... -
Page 54: Replacing Lithium Battery
System expansions Extensions to the system board Replacing lithium battery Incorrect replacement of the lithium battery may lead to a risk of explosion. The lithium battery may be replaced only with an identical battery or with a type recommended by the manufacturer. Do not throw lithium batteries into the household waste. -
Page 55: Replacing Processor
Extensions to the system board System expansions Replacing processor To replace the processor you must remove the system board bracket. Ê Open the system unit (see "Opening the system unit"). Ê Remove all boards (see "Removing a board"). Ê Unscrew the screw on the system board rack (1), push the system board rack somewhat in the direction of the arrow (2) and then tilt it out upward (3). -
Page 57: Technical Data
Noise emission: Sound power level (L ) < 5,5 B (A) *) These values only apply for a PRIMERGY ECONEL 10 with the configuration below. When additional or other components are incorporated, the power consumption or the sound emission (L ) in energy saving mode may exceed the requirements for the environment symbol ("Blue Angel") (30 W or 5,5 B). - Page 58 Technical data Environmental conditions Environment class 3K2 DIN IEC 721 part 3-3 Environment class 2K2 DIN IEC 721 part 3-2 Temperature: • Operating (3K2) 15 °C ..35 °C • Transport (2K2) -25 °C ..60 °C Condensation in operating must be avoided. Clearance required to ensure adequate ventilation: •...
-
Page 59: Index
Index Data electrical environmental Additional serial port, installing technical Alphanumeric keypad Data protection Alt Gr key Date, not correct Anti-theft protection Device drivers Audio input Devices Audio output connecting 13, interface Dimensions Battery 46, Diskette disposal Display, cleaning lithium battery replacing 46, Disposal BIOS Setup Drive... - Page 60 Index cannot read write protection Main memory write-protection Manuals, further Floppy disk drive Memory, upgrading changing Menu key indicator Microphone jack removing Monitor connecting transporting Monitor port 8, Game port Mouse Guarantee coupon booklet connecting error Mouse pointer Hard disk contents, restoring Mouse port 8, IDE drives No screen display...
- Page 61 Index ready-to-operate installing 11, setting up new installation switching off Standard keyboard, connecting switching on Streamer switching on for the first time installing transporting removing Ports, external devices Summer time Power management Surface Power voltage Symbols, explanation of connecting System board carrier connecting to installing Power-on indicator...
