PRIMERGY RX600 S3
incl. SAS version
System configurator and order-information guide
February 2007
Contents
Instructions
Configurator
0
0
System software
1
2
II
3
4
5
V
USB devices / optical devices
6
VI Hard disk drives
7
8
9
10
X
11
12
XII National accessories pack
PRIMERGY Server
Advertisement
Table of Contents
Related Manuals for Fujitsu Siemens Computers PRIMERGY RX600 S3
Summary of Contents for Fujitsu Siemens Computers PRIMERGY RX600 S3
-
Page 1: Table Of Contents
PRIMERGY RX600 S3 incl. SAS version System configurator and order-information guide February 2007 Contents Instructions Configuration diagram Configurator System software Basic unit Processor III Memory IV onboard SCSI / SAS Contr USB devices / optical devices VI Hard disk drives... - Page 2 Further information in the internet see: http://www.primergy.com http://extranet.fujitsu-siemens.com/primergy Prices and availability see price list and PC-/System-Architect. Subject to change and errors excepted. Fujitsu Siemens Computers Enterprise Products PRIMERGY Server System configurator and order-information guide PRIMERGY RX600 S3 (internet) (extranet) Status 2007-01-24...
-
Page 3: Configuration Diagram
Hot Plug Redundant Power Supply 1. PSU Key: Included in basic unit Option Fujitsu Siemens Computers Enterprise Products PRIMERGY Server System unit ( I ) Tape drives ( VII ) Operating Panel 5.25"x1.6" Tape Drive Hard disk drives ( IV ) hot-plug SAS Version: 8x 2.5"... - Page 4 Find detailed software configurators and release lists (OS-matrix / system management) under following addresses: for internal users: for partners: Continue with PRIMERGY HW configurator Fujitsu Siemens Computers Enterprise Products PRIMERGY Server PRIMERGY-Software Configurators and Release Lists Usage of OEM SW from MS is not possible under VMware Details eg. version numbers are published...
- Page 5 You'll find single software configurators and release lists (OS-matrix / system management / security) under following addresses: for internal users: for partners: Continue with PRIMERGY HW configurator Fujitsu Siemens Computers Enterprise Products PRIMERGY Server PRIMERGY-Software Configurators and Release Lists Usage of OEM SW from MS is not possible under VMware Linux - Software *) **)
- Page 6 - KVM S2 series needs the KVM S2 Adapter USB<->VGA - For ES4/8+ KVM series with PS/2 connector as well as for standard PS/2 KB / Mouse an additional USB to PS/2 adapter must be bought additionally and connected to the RX600 S3. The adapter offers 2x PS/2 ports.
-
Page 7: Processor
4MB TLC on Chip, heat sink and "Easy retention" occupies socket for one CPU max. 2x per VRM module Fujitsu Siemens Computers Enterprise Products PRIMERGY Server System configurator and order-information guide PRIMERGY RX600 S3 S26361-F3124-E420 S26361-F3124-E430 Xeon MP 7120M 3.00GHz Xeon MP 7130M 3.20GHz... -
Page 8: Memory
Optional hot-spare memory functionality can be configured in the BIOS (redundant memory bank n + 1) RX600 S3 supports the memory protection through Memory Mirroring or Memory RAID. Memory Mirroring requires 2 or 4 Memory boards, Memory RAID requires 4 Memory boards. -
Page 9: Onboard Scsi / Sas Contr
(plus cable to connect to the subsystem SX10, see configurator SX10) S26361-F3128-E20 ROM Battery Backup Unit for on-board RAID controller max. 1x per system Overview SCSI-cabling of a PRIMERGY RX600 S3 SCSI Base Unit Picture 1: Two channels for Disks onboard SCSI / RAID... - Page 10 For the connection of external Tape devices to the on board SCSI controller, also an additional cable is needed in the system. (plus cable to connect to the subsystem SX10, see configurator SX10) Overview SAS / SCSI-cabling of a PRIMERGY RX600 S3 SAS Base Unit Eight SAS ports for Disks...
- Page 11 8 10000rpm,<4,5ms, 8MB Cache SAS 3Gb/s hot plug/hot replace tray max. 8x per base unit Fujitsu Siemens Computers Enterprise Products PRIMERGY Server S26361-F3236-E1 DVD-RW 8x super multi drive all formats, DUAL/DL, DVD-RAM only W2K, W3K and Linux 0.5 x 5.25", anthracite bezel max.
- Page 12 Connector: HD68 without cable incl. description (Ger/US) data and cleaning cartridge 1.6 * 5.25", anthracite bezel max. 1x per system Fujitsu Siemens Computers Enterprise Products PRIMERGY Server System configurator and order-information guide PRIMERGY RX600 S3 S26361-F2849-E3 S26361-F3224-E3 Tape drive VXA-2...
-
Page 13: Optional Scsi / Raid Controller
1x per system S26361-F3215-E10 Cache Battery Backup Unit max. 1x per Controller Fujitsu Siemens Computers Enterprise Products PRIMERGY Server System configurator and order-information guide PRIMERGY RX600 S3 The RAID controller can be used only for the connection of external subsystems (SX30) Cables for the connection from the RAID Controllers to the subsystem see configurator SX30. -
Page 14: Fibre Channel Controller
For the configuration of external cabling see the configurator for external storage systems. For Fibre Channel SAN also other componets like switches, SFPs and optical wires are orderable (for details see price liste) Fujitsu Siemens Computers Enterprise Products PRIMERGY Server System configurator and order-information guide PRIMERGY RX600 S3... -
Page 15: Communication / Network
RJ45-plug, Cat 5 connection with Cat 5 cabling SW: VLAN, Fast & Gbit Etherchannel max. 3x / 4x per system Fujitsu Siemens Computers Enterprise Products PRIMERGY Server System configurator and order-information guide PRIMERGY RX600 S3 Teaming: Failover, Load Balancing... -
Page 16: System Management Products (Remoteview)
System will be shipped with two power cords ICE320 C14->C13 for rack installation. Country specific power cords are not required. End PRIMERGY RX600 S3 Fujitsu Siemens Computers Enterprise Products PRIMERGY Server System configurator and order-information guide PRIMERGY RX600 S3 S26361-F2425-E103... -
Page 17: Change Report
S26361-K988-V410 Rack mountable server 19" (4U) with 64-bit Xeon MP Dual Core processor 7110; 4MB TLC - now available 2006-02-13 first draft Fujitsu Siemens Computers Enterprise Products PRIMERGY Server System configurator and order-information guide PRIMERGY RX600 S3 Status 2007-01-24 17 of 17...
