Button Functions

1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
Note: The REC button must be pressed TWICE to record from
your VCR. For some brands of VCRs, you might need to press the
REC button once, then press it again for three seconds. Some
buttons on the remote might have functions that are referred to
by different names on the device you are controlling. E.G. LAST
may be called RECALL, or ENTER may be called DISPLAY.
These differences depend on the brand and model of your
product. Also, this remote can only operate features that exist on
your product. E.G., your product must have LAST ability for the
LAST button to operate this feature.
4
Button Functions, cont.
1. Red Indicator Lights when any button is pressed.
2. SETUP Used for setup.
29.
3. TV, DVD, SAT etc. Selects product to be operated.
4. GUIDE displays on-screen program or channel guides.
28.
5. MENU Brings up the device Menu screen (if available) -
use with UP, DOWN, LEFT, and RIGHT navigation
buttons.
27.
6. VOLUME UP/DOWN Changes the volume level of the
product, normally the TV.
26.
7. UP, DOWN, LEFT & RIGHT navigation buttons.
8. MUTE Turns off the TV sound while the picture remains.
25.
9. CC (SUBTITLE) TV Closed Caption (if your TV has this
feature) or DVD Subtitle toggle.
24.
10. SLEEP Turns off the TV after a period of 1 to 99 minutes.
11. ZOOM Zooms or enlarges a specific area of the screen.
23.
12. NUMBERS Enter numbers for direct channel selection.
Some products require Enter to be pressed after channel
selection.
22.
13. ENTER Used after direct channel number entry to
immediately change to the selected channel.
21.
14. REPLAY - Replays the last 8 seconds of a program.
15. RECORD, PLAY, STOP, REW, FF, PAUSE VCR control
20.
buttons operate your VCR even when the remote is set to
operate the TV. Also operates DVD Scan -/+.
19. 16. L1 - L4 used to store learned commands.
17. THUMBS UP/DOWN - set your Thumbs ratings.
18. ADVANCE - Catches you up to the live broadcast.
18.
19. DOT/DASH Used for digital channels, e.g. 2-3.
20. ANT/SD-HD Performs the TV/DVD or Standard
17.
Definition/High Definition switch function.
21. SAP Selects Secondary Audio Program channel if available.
16.
MTS selects MultiTrack Sound (if available).
22. LAST/REPEAT Returns to the previously selected channel,
or DVD repeat toggle.
23. INPUT For some TVs, press repeatedly to select available
viewing sources (antenna, cable box, VCR, etc.).
24. OK Selects menu items for the device you are controlling.
25. CHANNEL UP/DOWN Changes the channels. CHAPTER
+/- controls DVD/CD track selection i.e. DVD/CD Track
Skip Up/Down (in DVD and SAT modes). Note the VCR
buttons also control DVD when in DVD Mode.
26. INFO Displays/selects on-screen channel information, etc.
27. EXIT/RETURN Used to exit menu functions.
28. LEARN Used to setup learning functions.
29. POWER Turns product On or Off.
