Cradlepoint CBA750B Product Manual

Cba750b series cellular broadband adapter
Hide thumbs Also See for CBA750B:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for Cradlepoint CBA750B

Summary of Contents for Cradlepoint CBA750B

  • Page 2: Manual Revisions

    All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies. Copyright © 2013 by CradlePoint, Inc. All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written consent by CradlePoint, Inc.

  • Page 3: Table Of Contents

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Table of Contents 1   INTRODUCTION   ..............   3   5.3   GPS  ................   4 0   5.4   I   .............   4 1   NTERNET  ...
  • Page 4 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.7   S   ............   1 51   YSTEM   OFTWARE 9   GLOSSARY   ..............   1 53   10   APPENDIX   ..............   1 67  ...

  • Page 5: Introduction

    ARC CBA750B-W – 4G WiMAX for Sprint or CLEAR 1.2 System Requirements • An Internet source: a CradlePoint 3G/4G business-grade modem or broadband data modem (USB, ExpressCard) with active subscription. • Windows 2000/XP/7, Mac OS X, or Linux computer.

  • Page 6: Cba750B Overview

    For most applications, simply connect the CBA750B to an existing CPE router configured for WAN failover, and it’s ready to go. The CBA750B handles the wireless WAN connection through a 3G/4G modem (included with ARC models) when failover occurs.
  • Page 7 CradleCare – Access the Experts 24/7 CradlePoint understands how important and critical network uptime is to your business. We have a knowledgeable enterprise technical support staff that is available anytime via phone, chat, or email to protect your investment. Our experts will expedite issue resolution and provide flexible device-by-device solutions to help maximize operational...

  • Page 8: Radle Ointa Rcc Ba750B Eries

    CRADLEPOINT 1.4 CradlePoint ARC CBA750B Series ARC Series includes a CradlePoint 3G/4G business-grade modem with the CBA750B and creates an effortless instant network from high-speed wireless broadband. CradlePoint integrated business-grade modems are specifically designed to provide the highest level of performance, reliability, and security for 24x7 business-critical applications.
  • Page 9 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT CBA750B-LE-VZ 4G LTE/EVDO for Verizon Technology: LTE, EVDO Rev A Downlink Rates: LTE 100 Mbps, EVDO 3.1 Mbps (theoretical) Uplink Rates: LTE 50 Mbps, EVDO 1.8 Mbps (theoretical) Frequency Band: • LTE Band 13 (700 MHz) •...
  • Page 10 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT CBA750B-LP-AT 4G LTE/HSPA+ for AT&T Technology: LTE, HSPA+ Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps (theoretical) Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps (theoretical) Frequency Band: • LTE Band 17 (700MHz), Band 4 (AWS) •...
  • Page 11 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT CBA750B-LP2-EU 4G LTE/HSPA+ for Europe Technology: LTE, HSPA+ Downlink Rates: LTE 50 Mbps, HSPA+ 21.1 Mbps (theoretical) Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps (theoretical) Frequency Bands: • LTE (800/900/1800/2100/2600 MHz) •...
  • Page 12 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT CBA750B-LP 4G LTE/HSPA+ for Canada Technology: LTE, HSPA+ Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps (theoretical) Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps (theoretical) Frequency Band: • LTE Band 17 (700MHz), Band 4 (AWS) •...
  • Page 13 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT CBA750B-W 4G WiMAX for Sprint or Clear Technology: WiMAX 802.16e Wave 2 Downlink Rates: 10M bps peak, 6 Mbps average Uplink Rates: 5 Mbps peak, 1.2 Mbps average Frequency Band: 2,500 MHz band Power: 23.5 +/−...

  • Page 14: Hardware Overview

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 2 HARDWARE OVERVIEW © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 12...

  • Page 15: Ports , Buttons

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 2.1 Ports, Buttons, and Switches 40 mm 130 mm USB 2.0 LAN Port USB 2.0 ExpressCard Lock ExpressCard Slot Power On/Off DC Power Port Router/Passthrough Reset Switch 3G 2G R I G H T S I D E...
  • Page 16 10 seconds if the modem does not support concurrent data connection and signal strength measurement. A blinking LED indicates ½ bar. LAN Port: The CBA750B has one Ethernet port for a local network connection. Use this for connectivity and also for Power-over-Ethernet (optional).

  • Page 17: Leds

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 2.2 LEDs © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 15...

  • Page 18: Quick Start

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 3 QUICK START 3.1 Basic Setup 1) Connect a CradlePoint business-grade modem or USB/ExpressCard wireless broadband data modem with an active subscription. Integrated Business-Grade Modem (Optional) A) Purchase a data plan. Insert SIM B) Connect modem to CBA750B.

  • Page 19: Administration Pages

    IP address “192.168.0.1” into the address bar. • Enter your Default Password. This password can be found on the bottom of the CBA750B. Then click the LOGIN button. • When you log in for the first time, you will be automatically directed to the First Time Setup Wizard.

  • Page 20: Common Problems

    (Status → Dashboard). If you have a weak signal in your location, contact your service provider. If you are still not online after activating the modem, call CradlePoint Technical Support for further assistance. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...
  • Page 21 If your USB Modem has not been updated recently, it is recommended that you do so if it is having trouble connecting to the CBA750B. Insert your USB data modem into your PC and access the Internet using the software provided by your cellular carrier.
  • Page 22 Go to System Settings → System Software and click on “Manual Firmware Upload”. If you are still unable to access the Internet after following the above directions, contact CradlePoint Technical Support for further assistance.

  • Page 23: Web Interface -- Essentials

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 4 WEB INTERFACE -- ESSENTIALS The CBA750B has a Web interface for configuration and administration of all features. The interface is organized with 5 tabs at the top of the screen: • Getting Started •...

  • Page 24: Administrator Login

    The Administrator Login page will appear. Log in using your administrator password. Initially, this password can be found on the bottom of the CBA750B unit as the Default Password. This password is also the last eight digits of the unit’s MAC address.
  • Page 25 If you have forgotten your personalized password, you can reset the CBA750B to factory defaults. When you reset the router, the administrator password will revert back to the Default Password. Press and hold the reset button on the router unit until the lights flash (approximately 10-15 seconds).

  • Page 26: Getting Started - F

    2) When prompted for your password, type the eight character Default Password found on the product label on the bottom of the CBA750B (this is also the last 8 digits of the router’s MAC address). 3) When you log in for the first time, you will be automatically directed to the FIRST TIME SETUP WIZARD.
  • Page 27 6) Configuring Your Access Point Name (APN): If you are using a SIM-based modem (LTE/GSM/HSPA) with your CradlePoint router, you may need to configure the APN before it will properly connect to your carrier. Wireless carriers offer several APNs, so check with your carrier to confirm the appropriate one to use.
  • Page 28 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7) Modem Authentication: Some modems require a username and password to be entered to authenticate with a carrier. Do not fill in these fields unless you are sure your modem needs authentication.
  • Page 29 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8) Configuring Failure Check: It is possible for a WAN interface to go down without the router recognizing the failure. (For example: the carrier for a cellular modem goes dormant.) Enable Failure Check to ensure that you can get out to the Internet via your primary WAN connection.
  • Page 30 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 9) Review the details and record your administrative password. Click APPLY to save the settings and update them to your router. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 31: Uick Links

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 4.3 Quick Links The CradlePoint logo in the upper left-hand corner of all the administration pages is a link to the Dashboard (Status → Dashboard), which displays fundamental information about the router.

  • Page 32: Configuration

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 4.4 Configuration Pages The following table shows the navigation layout of the administration pages. Click on the tabs along the top bar to reveal the following dropdown menus. Getting Started Status Network Settings...
  • Page 33 LAN (Local Area Network) Examples: • If you want to change the content filtering settings for the network created by the CBA750B, go to the Network Settings tab. • If you want to track the data usage for your Internet source (such as your CradlePoint business-grade modem), go to the Internet tab.

  • Page 34: Registration

    CRADLEPOINT 4.5 Enterprise Cloud Manager Registration To register your device with CradlePoint Enterprise Cloud Manager, navigate to Getting Started → Enterprise Cloud Manager Registration. Input your ECM Username and ECM Password and click Register. You have now registered the device with Enterprise Cloud Manager.

  • Page 35: Ip Passthrough Setup

    4.6 IP Passthrough Setup The CBA750B’s IP passthrough function takes the IP address of the attached modem and passes it through to the LAN. By default, the CBA750B is configured for IP passthrough – the device ships with the ROUTER/PASSTHROUGH SWITCH set to the I position (“O”...
  • Page 36 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT router/passthrough switch. This option is listed in System Settings → Administration under the “Local Management” tab. Click on the “Disable IP Passthrough/Configuration mode switch” option. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/...

  • Page 37: Status

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 5 STATUS The Status tab displays information about many different aspects of the router. It provides access to 7 submenu options: • Client List • Dashboard • GPS • Internet Connections • Routing •...

  • Page 38: Lient List

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 5.1 Client List The Client List displays the Hostname, IP, and MAC of the device connected to your router. Hostname: The name by which each computer or device in a network is known.

  • Page 39: Dashboard

    After the initial setup of the router, every time you log in you will automatically be directed to this Dashboard. Also, you can click on the CradlePoint logo in the upper left-hand corner to return to the Dashboard from any page.
  • Page 40 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Router Information: “Detailed Info” links to System Settings → Administration. • Product: CBA750B • Serial: Device serial number • Firmware: Gives the number of the current firmware version • Build Date: Year-month-day-hours-minutes-seconds for the most recent firmware upgrade •...
  • Page 41 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Local Networks: “Detailed Info” links to Network Settings → Local Networks. • Clients: The number of current clients. For each network, the following information is displayed: • Network Name: IP Address/Netmask o Route Mode: NAT (Network Address Translation), Standard (NAT-less), IP Passthrough, or Disabled.

  • Page 42: Gps

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 5.3 GPS If GPS support is enabled and a modem capable of providing GPS coordinates is connected, this page shows a graphical view of your router's location. See the GPS section in System Settings →...

  • Page 43: Internet Connections

    The Internet Connections submenu option provides a list of attached WAN devices used as the Internet source for the CBA750B. Select one of these devices to see detailed information about that particular device. For each type of modem, different information will be included in the Device Information section. Possible devices...
  • Page 44 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 5.4.1 LTE Modem (PANTECH UML290) Diagnostics • Home Address • MN-HA SPI • Modem Firmware Version • Battery Status • MN-HA SS • Network Address Identifier (NAI) • Signal Strength(dBm) • Rev Tun •...
  • Page 45 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT General Information • Product PANTECH UML290 • Protocol IP DHCP • Unique Identifier • ESN/IMEI • Model UML290VW • Type modem • Port • Manufacturer Pantech, Incorporated IP Information • Netmask • IP Address •...
  • Page 46 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 5.4.2 HSPA+ Modem (Nokia Datacard) Diagnostics • Manufacturer Nokia • Product Nokia Datacard • Model Nokia Internet Stick CS-18 • ESN/IMEI • Modem Firmware Version • Mobile Directory Number • Carrier ID AT&T •...
  • Page 47 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT IP Information • DNS Servers • IP Address • Gateway Statistics • Incoming Bytes • Outgoing Bytes • Connection Uptime (secs) © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 48 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 5.4.3 WiMAX Modem (U300 – 4G) Diagnostics For a WiMAX modem, the CINR and Signal Strength values are important as they show how strong the signal is and that has significant effects on how much data the router can download or send.
  • Page 49 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT • Type WiMAX • Port • Manufacturer Franklin Wireless Corporation Statistics • Outgoing Bits/Second • Incoming Bits/Second • Incoming Bytes • Outgoing Bytes © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...
  • Page 50 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 5.4.4 GSM Modem (Nokia Datacard) Diagnostics • Signal Error Rate • Modem Firmware Version • Battery Status • Battery Level • Carrier Status • Signal Strength(dBm) • PIN Status • Connection State (connected, idle, etc.)
  • Page 51 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT • Incoming Bits/Second • Incoming Bytes • Outgoing Bytes © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 49...
  • Page 52 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 5.4.5 EVDO Modem: (MC760 Comcast) Diagnostics • Modem Firmware Version • PRL Version • Service Display EVDO • Carrier Status • Signal Strength(dBm) • Connection Type CDMA • Connection State (connected, idle, etc.) General Information •...

  • Page 53: Routing

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 5.5 Routing System Routes displays routes associated with networks connected to the router. Static Routes displays user-specified routes configured in Network Settings → Routing, © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES...

  • Page 54: Statistics

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 5.6 Statistics The Statistics submenu option displays basic traffic statistics. Wireless Statistics: View the signal strength and other wireless modem information. The wireless device’s signal strength will only be displayed as long as it supports “Live Diagnostics.” Sample rate and size can be adjusted from the dropdown boxes.
  • Page 55 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Data Usage: A measure of amount of information that is currently being sent or received through the network. Sample rate and size can be adjusted from the dropdown boxes. © 2013 CRADLEPOINT, INC.
  • Page 56 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Failover/Failback/Load Balance: An easy way to view current connective states of the devices plugged into the router as compared to the past. Sample rate and size can be adjusted from the dropdown boxes.

  • Page 57: System Logs

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 5.7 System Logs The router automatically logs (records) events of possible interest in its internal memory. If there is not enough internal memory for all events, logs of older events are deleted, but logs of the latest events are retained. The log options allow you to filter the router logs so you can easily find relevant messages.

  • Page 58: Network Settings

    6 NETWORK SETTINGS The Network Settings tab provides access to 7 submenu options for administering the following functions/tasks. These functions are all related to controlling the LAN (Local Area Networks), the networks you set up with the CBA750B. • Content Filtering •...

  • Page 59: Content Filtering

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.1 Content Filtering You have two main options for filtering content in a network created by your router. 1) Network WebFilter Rules: Create a list of websites that will be either disallowed or allowed. Customize the filter settings for each network.
  • Page 60 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Click Add or Edit to open the Filter Rule Editor. • Assigned Network: Select either “All Networks” or one of your LAN networks from the dropdown list. • Domain/URL/IP: Enter the Domain Name or URL (address) of the website you wish to control access for, e.g.
  • Page 61 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.1.2 Default Filter Settings Use Default Network Filter Settings together with Network WebFilter Rules to control website access. All of your networks are set to allow website access by default. Select a network and click Edit to change the default filter settings.
  • Page 62 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.1.3 Cloud Based Filtering/Security Select a third-party Cloud Provider from the dropdown list. • Disabled • Umbrella by OpenDNS Umbrella by OpenDNS Umbrella by OpenDNS is a cloud- based web filtering and security solution that protects you online by filtering websites.

  • Page 63: Dhcp Server

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.2 DHCP Server DHCP stands for Dynamic Host Configuration Protocol. The built-in DHCP server automatically assigns IP addresses to the computers and other devices on each local area network (LAN). In this section you can view a list of assigned IP addresses and reserve IP addresses for particular devices.

  • Page 64: Dns

    DNS, or Domain Name System, is a naming system that translates between domain names (www.cradlepoint.com, for example) and Internet IP addresses (206.207.82.197). A DNS server acts as an Internet phone book, translating between names that make sense to people and the more complex numerical identifiers. The DNS page for the CBA750B has these distinct functions: •...
  • Page 65 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.3.2 Dynamic DNS Configuration The Dynamic DNS feature allows you to host a server (Web, FTP, etc.) using a domain name that you have purchased (www.yourname.com) with your dynamically assigned IP address. Most broadband Internet Service Providers assign dynamic (changing) IP addresses.
  • Page 66 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.3.3 Advanced Dynamic DNS Settings Update period (hours). (Default: 576) The time between periodic updates to the Dynamic DNS if your dynamic IP address has not changed. The timeout period is entered in hours so valid values are from 1 to 8760.

  • Page 67: Firewall

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.4 Firewall The router automatically provides a firewall. Unless you configure the router to the contrary, the router does not respond to unsolicited incoming requests on any port, thereby making your LAN invisible to cyber attackers.
  • Page 68 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT • Local Port(s): The port number(s) that corresponds to the service (Web server, FTP, etc) on a local computer or device. For example, you might input “80” in the Local Port(s) field to open a port for a Web server on a computer within your network.
  • Page 69 IPv6 providers, but it cannot be used effectively in all situations. The primary purpose for CradlePoint’s NPT implementation is for failover/failback and load balancing setups. LAN clients can potentially retain the original IPv6 lease information and may experience a more seamless transition when WAN connectivity changes than if not utilizing NPT.
  • Page 70 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT IP Filter Rules (Advanced) 6.4.3 An "Incoming" IP filter rule restricts remote access to computers on your local network. "Outgoing" filter rules prevent computers on your local network from initiating communication to the address range specified in the rule.
  • Page 71 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT that is NOT in the specified port range. • Port(s): Use for a single port or a range of ports. Fill in the left side for a single port. Use Network IP, Netmask, and Port(s) to specify the ports and addresses for which the rule applies. You can specify a range of ports or a single port.
  • Page 72 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.4.4 DMZ: DeMilitarized Zone (Advanced) A DMZ host is effectively not firewalled in the sense that any computer on the Internet may attempt to remotely access network services at the DMZ IP address. Typical uses involve running a public Web server or sharing files.
  • Page 73 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT • FTP: To allow normal mode when using File Transfer Protocol. This is not needed for passive mode. This is enabled by default. • IRC: For Direct Client to Client (DCC) transfer when using Internet Relay Chat. You may wish to forward TCP port 113 for incoming identd (RFC 1413) requests.
  • Page 74 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Remote Administration Access Control Editor IP Address: The IP address that will be allowed to access administrative services through the WAN. Netmask (Optional): The netmask allows you to specify what IP address sets will be allowed access. If this field is left empty a netmask of 255.255.255.255 will be used,...

  • Page 75: Ocal Networks

    This section is used to configure the settings for networks created by your router. The user can set up multiple networks on the CBA750B, each with its own unique configuration and its own selection of interfaces. Each local network can be attached to either (or both) of the following types of interfaces: •...
  • Page 76 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.5.1 Local IP Networks Local IP Networks displays the following information for each network: • Network Name and IP address/Netmask (along the top bar) • Enabled (Yes/No) • DHCP Mode (e.g. DHCP Server mode) •...
  • Page 77 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.5.2 Local Network Editor Click Add or select a network and click Edit to open the Local Network Editor to make configure a LAN. The Local Network Editor contains the following tabs: General Settings, IPv4 Settings, IPv6 Settings, Interfaces, Access Control, IPv4 DHCP, IPv6 Addressing, and Schedule.
  • Page 78 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT IPv4 Settings: IP Address: This is the address used by the router for local area network communication. Changes to this parameter may require a restart to computers on this network. Each network must have a distinct IP address. Most users...
  • Page 79 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT IPv6 Settings: IPv6 must be enabled through the WAN initially: go to Internet → Connection Manager to enable IPv6. IPv6 Address Source: By default, this is set to Delegated, which means the IPv6 address range for the LAN is passed through from the WAN side.
  • Page 80 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Interfaces: Select network interfaces to attach to this network. Choose from the Ethernet port and VLAN interfaces. Double-click on an interface shown on the left in the Available section to move them to the Selected section on the right (or highlight an interface and click the “+”...

  • Page 81: Access Control

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Access Control: Tune the access control settings of this network to match the intended use. Simply select or deselect any of the following: • LAN Isolation: When checked, this network will NOT be allowed to communicate with other local networks.
  • Page 82 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT IPv4 DHCP: Changing settings for the IPv4 DHCP server is optional. The default selections are almost always sufficient. DHCP Server: (Default: Enabled) When the DHCP server is enabled, users of your network will be able to automatically connect to the Internet without any special configuration.
  • Page 83 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Custom Options: Input a custom DHCP option by first clicking the Custom Options field to enable it and then clicking “Add” at the top of the table that appears. There are close to 200 possible DHCP options available. One of the more common uses is to assign a VoIP phone server using option 66 (Server name).
  • Page 84 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT IPv6 Addressing: Address Configuration Mode: SLAAC Only – SLAAC stands for stateless address autoconfiguration. The router regularly generates a router advertisement that includes network prefix and routing information, allowing clients to autogenerate an address and start communicating on the network.
  • Page 85 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Schedule: Set up a schedule for this network interface. This allows an interface to be enabled or disabled during specific hours of a day. For example, use this to limit the network to business hours.
  • Page 86 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.5.3 Local Network Interfaces Each LAN type—Ethernet and VLAN—has a separate section with configuration options. Unless the default configuration is sufficient, YOU MUST CONFIGURE EACH INTERFACE SEPARATELY in order to create the desired interface options for a network.
  • Page 87 Since the CBA750B has only 1 Ethernet port, this feature will rarely be necessary. The only use is to switch the port to a different local network.
  • Page 88 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT VLAN Interfaces A virtual local area network, or VLAN, functions as any other physical LAN, but it enables computers and other devices to be grouped together even if they are not physically attached to the same network switch.

  • Page 89: Mac

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.6 MAC Filter / Logging A MAC (Media Access Control) address is a unique identifier for a computer or other device. This page allows you to manage clients by MAC address. You can filter clients by MAC addresses and/or keep a log of devices connected to your router.
  • Page 90 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.6.2 MAC Logging Configuration Enable MAC Logging: Enabling MAC Logging will cause the router to log MAC addresses that are connected to the router. MAC addresses that you do not want to have logged (addresses that you expect to be connected) should be added to the “Ignored MAC Addresses”...

  • Page 91: Routing

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6.7 Routing Add a new static route to the IP routing table or edit/remove an existing route. Static routes are used in networks with more than one layer, such as when there is a network within a network so that packet destinations are hidden behind an additional router.

  • Page 92: Internet

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7 INTERNET The Internet tab provides access to 3 submenu items for managing a variety of Internet connection options. • Connection Manager • Data Usage • WAN Affinity / Load Balancing © 2013 CRADLEPOINT, INC.
  • Page 93 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7.1 Connection Manager The router can establish an uplink via any modems plugged into a modem port. If there is more than one modem attached and the primary connection fails, the router will automatically attempt to bring up a new link on another device. This feature is called failover.
  • Page 94 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7.1.2 Device Configuration Clicking on a device reveals the following information: • State (Connected, Available, etc.) • Port • UID (Unique identifier. This could be a name or number/letter combination.) • IP Address •...
  • Page 95 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7.1.3 General Settings • Enabled: Select/deselect to enable/disable. • Force NAT: Normally the LAN Route Mode controls the use of NAT (network address translation). When this option is selected the router will always perform NAT when traffic is sent out from this device.
  • Page 96 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT IPv4 Failure Check (Advanced) If this is enabled, the router will check that the highest priority active WAN interface can get to the Internet even if the WAN connection is not actively being used. If the interface goes down, the router will switch to the next highest priority interface available.
  • Page 97 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT IPv6 Failure Check (Advanced) These settings match IPv4 Failure Check; the only difference in the UI is that the ping address uses IPv6. Failback Configuration (Advanced) This is used to configure failback, which is the ability to go back to a higher priority WAN interface if it regains connection to its network.
  • Page 98 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7.1.4 IP Overrides IP overrides allow you to override IP settings after a device’s IP settings have been configured. Only the fields that are filled out will be overridden. Override any of the following fields: •...
  • Page 99 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7.1.5 IPv6 Settings The IPv6 (http://en.wikipedia.org/wiki/IPv6) configuration allows you to enable and configure IPv6 for a WAN device. These settings should be configured in combination with the IPv6 LAN settings (go to Network Settings → Local Networks, select the LAN under Local IP Networks, and click Edit) to achieve the desired result.
  • Page 100 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Enable IPv6 and select the desired IPv6 connection method for this WAN interface. • Disabled (default) – IPv6 disabled on this interface. • Auto – IPv6 will use automatic connection settings (if available).
  • Page 101 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Auto IPv6 auto-configuration mode uses DHCPv6 and/or SLAAC to configure the IPv6 networks. When you select Auto, all of the following settings are optional (depending on your provider’s requirements): • PD Request Size – Prefix Delegation request size. This is the size of IPv6 network that will be requested from the ISP to delegate to LAN networks.
  • Page 102 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Static As with IPv4, static configuration is available for situations where the WAN IPv6 topology is fixed. • IPv6 Address/CIDR – Input the IPv6 static IP address and mask length provided by your ISP (see http://en.wikipedia.org/wiki/Classless_Inter-Domain_Routing...
  • Page 103 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6to4 Tunnel Out of the box, 6to4 is the simplest mode to enable full end-to-end IPv6 connectivity in an organization if the upstream ISP properly routes packets to and from the 6to4 unicast relay servers.
  • Page 104 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6in4 Tunnel The 6in4 tunnel mode utilizes explicit IPv4 tunnel endpoints and encapsulates IPv6 packets using 41 as the specified protocol type in the IP header. A 6in4 tunnel broker provides a static IPv4 server endpoint, decapsulates packets and provides routing for both egress and ingress IPv6 packets.
  • Page 105 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 6rd Tunnel IPv6 Rapid Deployment (6rd) is a method of IPv6 site configuration derived from 6to4. It is different from 6to4 in that the ISP provides explicit 6rd infrastructure that handles the IPv4 ↔ IPv6 translation within the ISP network. 6rd is considered more reliable than 6to4 as the ISP explicitly maintains infrastructure to support tunneled IPv6 traffic over their IPv4 network.
  • Page 106 • Force 3G (EVDO, UMTS, HSPA): Connect to 3G network only. • Force 2G (1xRTT, EDGE, GPRS): Connect to 2G network only. See the following tables for a breakdown of the technologies used with various CradlePoint ARC models when any Modem Connection Mode is selected.
  • Page 107 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT CDMA Technology Auto Auto 3G Force 4G Force 3G (module auto selects) Force 2G (<= 3G) 1xEVDOAe 1xEVDO-A 1xEVDO-0 1xRTT (EHRPD) (HRPD) (3G) (HRPD) (3G) (2.5G) ARC CBA750B-LE ✔ ✔ ✔ ✔...
  • Page 108 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Network Selection Mode: Wireless carriers are assigned unique network identifying codes known as PLMN (Public Land Mobile Network). To manually select a particular carrier, select the Manual radio button and enter the network PLMN.
  • Page 109 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7.1.7 WiMAX Settings WiMAX Realm: Select from the following dropdown options: • Clear – clearwire-wmx.net • Rover – rover-wmx.net • Sprint 3G/4G – sprintpcs.com • Xohm –xohm.com • BridgeMAXX – bridgeMAXX.com • Time Warner Cable – mobile.rr.com •...
  • Page 110 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7.1.8 CDMA Settings These settings are usually specific to your wireless carrier’s private networks. You should not set these unless directed to by a carrier representative. If a field below is left blank, that particular setting will not be changed in the modem. You should only fill in fields that are required by your carrier.
  • Page 111 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT SIM/APN/Auth Settings 7.1.9 SIM PIN: PIN number for a GSM modem with a locked SIM. Authentication Protocol: Set this only if your service provider requires a specific protocol and the Auto option chooses the wrong one.
  • Page 112 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7.1.10 Update/Activate a Modem Some 3G/4G modems can be updated and activated while plugged into the router. Updates and activation methods vary by modem model and service provider. Possible methods are: PRL Update, Activation, and FUMO. All supported methods will be displayed when you select your modem and click “Control”.
  • Page 113 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Process Timeout: If the process fails an error message will display. Activation has a 3-minute timeout, PRL update has a 4-minute timeout, and FUMO has a 10-minute timeout. Update Modem Firmware Click on the Firmware button to open the Modem Firmware Upgrade window.
  • Page 114 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Configuration Rules (Advanced) 7.1.11 This section allows you to create general rules that apply to the Internet connections of a particular type. These can be general or very specific. For example, you could create a rule that applies to all WiMAX modems, or a rule that only applies to an Internet source with a particular MAC address.
  • Page 115 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT WAN Configuration Rule Editor After clicking “Add” or “Edit,” you will see a popup with the following tabs: • Filter Criteria • General Settings • IP Overrides • IPv6 Settings • Ethernet Settings •...
  • Page 116 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT • Unique ID: Select by ID. This is generated by the router and displayed when the device is connected to the router. Condition: Select “is,” “is not,” “starts with,” “contains,” or “ends with” to create your condition’s statement.

  • Page 117: Ata Usage

    Agreement shown to the right. The purpose of this agreement is to ensure that you understand that the data numbers for the CBA750B may not perfectly match those of your carrier: CradlePoint cannot be held responsible. You must accept the agreement by clicking Yes in order to begin creating data usage rules.
  • Page 118 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7.2.1 Data Usage Rules The Date Usage Rule display shows basic information for each rule you have created (including rules created with a template). The following information is displayed: • Rule Name •...
  • Page 119 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT keep all interfaces with these rules at a similar percentage utilization of data (e.g. 10%, 50%, 90%) as the cycle progresses, rather than quickly using 100% of a fast 1GB capped interface while using only a fraction of a slow 10GB capped interface, thus leaving the rest of the cycle with only the slow interface.
  • Page 120 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7.2.2 Template Configuration Templates allow you to control multiple WAN devices with the same rule. Each WAN device that matches a template will automatically have its own rule created. For example, you can set a template rule for all mobile data modems that causes your router to send an alert after 1000 MB of usage in a month.
  • Page 121 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 7.3 WAN Affinity and Load Balancing WAN affinity and load balancing both require multiple WAN devices, which is not typical usage Load Balance Select the Load Balance Algorithm from the following dropdown options: •...
  • Page 122 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Name: Give a name for your rule that is meaningful to you. DSCP (DiffServ): Differentiated Services Code Point is the successor to TOS (Type of Service). Use this field to select traffic based on the DSCP header in each IP packet. This field is sometimes set by latency sensitive equipment such as VoIP phones.
  • Page 123 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Source Netmask: 255.255.255.0 • Failover: (Default: Selected.) When this is selected and traffic from the chosen WAN device for this rule is interrupted, the router will fail over to another available WAN device. Deselect this option to restrict this traffic to only the selected WAN interface.
  • Page 124 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT • Spillover: This was the default algorithm in older (version 3) firmware. Load is always given to devices with the most available bandwidth. The estimated bandwidth rate is based on a combination of the upload and download configuration values and the observed capabilities of the device.

  • Page 125: System Settings

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8 SYSTEM SETTINGS The System Settings tab has the following submenu items that provide access to tools for broad administrative control of the CBA750B: • Administration • Device Alerts • Enterprise Cloud Manager •...

  • Page 126: Administration

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.1 Administration Select the Administration submenu item in order to control any of the following functions: • Router Security • System Clock • Local Management • Remote Management • GPS • SMS •...
  • Page 127 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Advanced Security Mode When you enable Advanced Security Mode, you have three different options for the Authentication Mode: • Local Users • TACACS+ • RADIUS Local Users Create users with administrative privileges by inputting usernames and passwords in the Advanced User Management table.
  • Page 128 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT "host.domain.com". Only lower case letters are allowed for a DNS name. Port: Port 49 is default for TACACS+. Shared Secret RADIUS RADIUS stands for “Remote Authentication Dial In User Service”. The router will use a RADIUS server (or two, optionally) to authorize administration.
  • Page 129 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT System Clock 8.1.2 Enabling NTP will tell the router to get its system time from a remote server on the Internet. If you do not enable NTP then the router time will be based on when the router firmware was built, which is guaranteed to be wrong.
  • Page 130 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.1.3 Local Management Enable Internet Bounce Pages: Bounce pages show up in your web browser when the router is not connected to the Internet. They inform you that you are not connected and try to explain why.
  • Page 131 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.1.4 Remote Management Allows a user to enable incoming WAN pings or to change settings for the router from the Internet using the router's Internet address. Allow WAN pings: When enabled the functionality allows an external WAN client to ping the router.
  • Page 132 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.1.5 If you have an attached device with GPS support, you can enable a graphical view of your router’s location which will appear in Status → GPS. Users can also configure GPS NMEA GGA...
  • Page 133 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT $GPGGA – Essential fix data including 3D location and accuracy information Example: $GPGGA,1753405,4916.450,N,12311.127,W,2,06,1.5,117.3,M,−26.574,M,6.0,0138*47 1753405 Time of fix – 17:34:05 UTC 4916.450,N Latitude 49 deg. 16.450 min North 12311.127,W Longitude 123 deg. 11.127 min West Fix quality: •...
  • Page 134 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.1.6 SMS (Short Message Service, or text messaging) requires a cellular modem with an active data plan. SMS is not designed to be a full remote management feature: SMS allows you to connect to the router for a few simple queries or commands with a text messaging service (e.g., from your phone).
  • Page 135 This list is blank by default, which means that the router will accept SMS messages from any phone number. Leaving this blank is unsecure, so CradlePoint recommends that you add phone numbers to this list. Once any numbers are listed, only those numbers have the ability to connect to the router via SMS.
  • Page 136 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT How to Send an SMS Message You can send SMS messages to the router via phone or email. The key elements are: 1. the modem’s MDN 2. the SMS password (defined above) 3.
  • Page 137 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT SMS Commands Below is a list of supported SMS messages and the syntax format. Due to security concerns, the set of commands are intentionally limited to those that can configure a modem’s connection, but cannot lock the administrator out due to malicious modem changes.
  • Page 138 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT This command returns info about the router along with the port names for ports with attached modems. These port names may be helpful for using the commands that follow. Example of response: uptime: 0:35:13 FW: v4.4.0...
  • Page 139 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT apn: Set the APN on the modem (for SIM-based modems)* • Syntax: <password>,apn,<new APN>,[port,] • Example: 1234,apn,myapn@apn.com, //set APN of highest priority modem • Example: 1234,apn,myapn@apn.com,usb1, //set APN for modem in port usb1 userpass: Set the modem's authentication username and password* •...
  • Page 140 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Sample Debug Session The following is an example of a debug session to discover a modem’s APN is misconfigured and needs to be set. Figure out the state of the modems on the router: 1234,rstatus, Receive the modem’s status and settings:...
  • Page 141 If this occurs, disable this option. Log to attached USB stick: Only enable this option if instructed by a CradlePoint support agent. This will write a very verbose log file to the root level of an attached USB stick. Please disable the feature before removing the USB stick, or you may lose some logging data.
  • Page 142 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.1.8 Router Services By default, router services (Enterprise Cloud Manager, NTP, etc.) connect to the router via the WAN. In some setups it makes sense to use the LAN instead. For example, if your router is used strictly for 3G/4G failover behind another router, you may not want to use 3G/4G data unnecessarily.

  • Page 143: Device

    Alert sent. SMTP Mail Server 8.2.1 Since the CBA750B does not have its own email server, to receive alerts you must enable an SMTP server. This is possible through most email services (Gmail, Yahoo, etc.) © 2013 CRADLEPOINT, INC.
  • Page 144 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Each SMTP server will have different specifications for setup, so you have to look those up separately. The following is an example using Gmail: • Server Address: smtp.gmail.com • Server Port: 587 (for TLS, or Transport Layer Security port;...

  • Page 145: Enterprise Cloud Manager

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.3 Enterprise Cloud Manager CradlePoint ECM is a cloud-based management service for configuring, monitoring, and organizing your CradlePoint routers. Key features include: • Group based configuration management • Health monitoring of router connectivity and data usage •...
  • Page 146 • Ethernet Communication Only: Select this to ensure that the WiPipe Central client will not start unless the WAN is Ethernet. • Registration URL: Register your router using the code provided by CradlePoint when you purchase WiPipe Central. © 2013 CRADLEPOINT, INC.

  • Page 147: Redirector

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.4 Serial Redirector A single USB Serial device can be used to establish a serial link to a host port on the router. The USB Serial device can also be accessed by running "serial" from an SSH session.
  • Page 148 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT • 1200 • 1800 • 2400 • 4800 • 9600 • 19200 Byte Size: The number of bits in a byte. Select from: 5, 6, 7, and 8. Parity: Change this value to enable parity bit checking. Select from the following dropdown options: •...

  • Page 149: Snmp Configuration

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.5 SNMP Configuration SNMP, or Simple Network Management Protocol, is an Internet standard protocol for remote management. You might use this instead of CradlePoint Enterprise Cloud Manager if you want to remotely...
  • Page 150 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT SNMPv3: SNMP version 3 includes all prior features with security available. SNMPv3 is the most secure setting for SNMP. If you wish to configure traps then you must use SNMP version 3.
  • Page 151 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Trap community string: The trap notifications will be returned to the trap server using this SNMPv1 trap community name. Address for trap server: Enter the address of the host system that you want trap alerts sent to.

  • Page 152: System Control

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.6 System Control Restore to Factory Defaults: This changes all settings back to their default values. Reboot The Device: This causes the router to restart. Advanced: System Automatic Reboot and Ping Test Scheduled Reboot: This causes the router to restart at a user-determined time.

  • Page 153: System Software

    This allows the administrator to load new firmware onto the router to add new features or fix defects. If you are happy with the operation of the router, you may not want to upgrade just because a new version is available. Check the firmware release notes (www.cradlepoint.com/firmware) for information to decide if you should upgrade. Current Firmware Version: Shows the number of the current firmware and the date it was updated.
  • Page 154 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 8.7.2 System Config Save/Restore Backup Current Settings: Click on “Save to disk” to save your current settings to a file on a computer. Restore Settings: Click on “Upload from file” to restore your previous settings from a file on a computer.

  • Page 155: Glossary

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 9 GLOSSARY 802.11 Alphanumeric A family of specifications for wireless local area networks Characters A-Z and 0-9. (WLANs) developed by a working group of the Institute of Antenna Electrical and Electronics Engineers (IEEE).
  • Page 156 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Authentication BOOTP To provide credentials, like a Password, in order to verify Bootstrap Protocol. Allows for computers to be booted up that the person or device is really who they are claiming and given an IP address with no user intervention.

  • Page 157: Information

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Client DB-25 A program or user that requests data from a server. A 25-pin male connector for attaching External modems or RS-232 serial devices. Collision DB-9 When do two devices on the same Ethernet network try and transmit data at the exact same time.
  • Page 158 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT DHCP Dynamic Host Configuration Protocol: Used Digital Subscriber Line. High bandwidth Internet automatically assign IP addresses from a predefined pool connection over telephone lines. of addresses to computers or devices that request them.
  • Page 159 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Ethernet The most widely used technology for Local Area File Transfer Protocol. Easiest way to transfer files Networks. between computers on the Internet. Fiber optic Full-duplex A way of sending data through light impulses over glass Sending and Receiving data at the same time.
  • Page 160 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Hashing IGMP Transforming a string of characters into a shorter string Internet Group Management Protocol is used to make with a predefined length. sure that computers can report their multicast group membership to adjacent routers.
  • Page 161 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Internet Protocol Security Java IPsec provides security at the packet processing layer of A programming language used to create programs and network communication. applets for web pages. Internet Service Provider Kbps An ISP provides access to the Internet to individuals or Kilobits per second.
  • Page 162 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT LPR/LPD MPPE “Line Printer Requestor”/”Line Printer Daemon”. A Microsoft Point-to-Point Encryption is used to secure data TCP/IP protocol for transmitting streams of printer data. transmissions over PPTP connections. MAC Address A unique hardware ID assigned to every Ethernet Maximum Transmission Unit is the largest packet that adapter by the manufacturer.
  • Page 163 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Network Interface Card routers in the network as opposed to sending the entire routing table at a regular interval, which is how RIP NIC. A card installed in a computer or built onto the functions.
  • Page 164 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT channel) but can have multiple ports (logical channels) Rendezvous each identified by a number. Apple’s version of UPnP, which allows for devices on a network to discover each other and be connected without the need to configure any settings.
  • Page 165 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Session key An encryption and decryption key that is generated for Secure Shell is a command line interface that allows for every communication session between two computers. secure connections to remote computers.
  • Page 166 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT TFTP Upload Trivial File Transfer Protocol is a utility used for To send a request from one computer to another and transferring files that is simpler to use than FTP but with have a file transmitted from the requesting computer to less features.
  • Page 167 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Wake on LAN WiFi Protected Access Allows you to power up a computer through it’s Network An updated version of security for wireless networks that Interface Card. provides authentication as well as encryption.
  • Page 168 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT Yagi antenna A directional antenna used to concentrate wireless signals on a specific location. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 166...

  • Page 169: Appendix

    CBA750B-LE the maximum antenna gain must not exceed 8 dBi in the cellular band, 3 dBi in the PCS band and 10 dBi in the LTE band. For the CBA750B-LP the maximum antenna gain including cable loss must not exceed 7.5 dBi in the cellular band, 3 dBi in the PCS band, 5.5 dBi in LTE Band 4, and 9 dBi in LTE Band 17. For the CBA750B- W the maximum antenna gain must not exceed 9.2 dBi in the 2.5 GHz band (2496-2690 MHz).

  • Page 170: Privacy

    CradlePoint, Inc. warrants this product against defects in materials and workmanship to the original purchaser (or the first purchaser in the case of resale by an authorized distributor) for a period of one (1) year from the date of shipment. This warranty is limited to a repair or replacement of the product, at CradlePoint’s discretion as purchaser’s sole and exclusive remedy.

  • Page 171: Specifications

    CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT 10.3 Specifications MODEL NAME CBA750B Cellular Broadband Adapter 3G/4G via three modem ports (2 USB 2.0, 1 ExpressCard) One Ethernet port (10/100) BUTTONS / SWITCHES Power, reset, modem signal strength, router/passthrough (allows automatic IP passthrough setting)
  • Page 172 CBA750B | USER MANUAL Firmware version 5.0 CRADLEPOINT http://www.cradlepoint.com/ Copyright © 2013 by CradlePoint, Inc. All rights reserved. © 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 170...
