Cradlepoint CBA750 Quick Start Manual

Register your CBA750
Mobile Broadband Adapter Today!
~ YOU WILL RECEIVE ~
Technical Support
Firmware Upgrades
cradlepoint.com/register
What's Included In The Box
Mobile Broadband Adapter
•
Power Adapter Mounting Hardware
• •
A B O U T T H E C B A 7 5 0
The CradlePoint CBA750 Adapter provides on-demand Ethernet WAN connectivity
using plug-in 3G and 4G modems.
The CradlePoint CBA750 Adapter is typically used to provide backup (failover)
Internet connectivity.
F E A T U R E S
FLEXIBLE Uses either Power-over-Ethernet or Included AC Adapter
SIMPLE TO USE Modem Hot-Swap and Automatic Detection
DURABLE Robust Housing for Wide Application Use
COMPATIBLE Supports a Broad Range of Devices
SECURE ACCESSORY Modem Security Enclosure Available
RELIABLE Supports up to 4 Modems with Failover For Reliable Connectivity
P O R T D I A G R A M
40 mm
L E F T S I D E
Reset
AC Power Port
Power On/Off
LAN Port
USB 2.0
New Product Information
Special Offers & Promotions
Ethernet Cable
•
Quick Start Guide
•
130 mm
L E D S TAT U S I N D I C AT O R S
Activation Modem Signal Strength
CBA750
Mobile Broadband Adapter
3G/4G Ready
A C C E S S O R I E S
Modem Security Enclosure
Protect your USB and ExpressCard modems with our security enclosure,
specially designed for the CBA750.
- External Cellular Modem Antenna Holes
- Star-Topped Security Screws
- Vented for Proper Air Flow
29
$ 99
R I G H T S I D E
Configuration Switch
ExpressCard Slot
ExpressCard Lock
USB 2.0
USB 2.0
QUICK START GUIDE
115 mm
Modem Security Enclosure
(optional)
PART NUMBER: 170529-001
