GE CustomStyle Profile Performance 22 Owner's Manual page 25

Reversing the hardware.
Transfer Top Hinge to the Left
Position the top hinge over the screw holes in the top
1
left of the cabinet, ensuring that it is lined up with the
other two hinges.
Put the Torx screws two or three threads into the
2
holes that were not used when the hinge was on the other
side, but DO NOT tighten them at this time.
Remove Door Stops, Cam Riser, and Cam Closure
Remove the left hand door stops and cam closure
1
from the reversibility kit. The reversibility kit is taped
onto the bottom shelf of the fresh food door. If you
have misplaced the kit, contact your local GE consumer
service for kit.
From the freezer door, remove the door stop, along
2
with the cam riser, spacer shims, and aluminum foil from
the right side of the bottom flange, using the T-20 Torx
Driver.
From the fresh food door, remove the door stop, along
3
with the cam closure, spacer shims, and aluminum foil
from the right side of the bottom flange using the T-20
Torx Driver.
The door stops and cam closure on the right side can be
4
placed in the reversibility kit bag, and the rest of the parts
can be put aside, along with the new left hand cam
closure and door stops.
Top Hinge
Freezer Door
Tape, Aluminum
Shim, Door Stop
Door Stop
Cam Riser
Screw
Fresh Food Door
Tape, Aluminum
Shim, Door Stop
Door Stop
Closure Cam
Screw
25
