Inserting the door panels.
Install the Freezer Door Side Trim
NOTE: Two side trim pieces are included with the
refrigerator. Make sure they are not discarded with
the shipping materials.
Do not remove the protective film on the outside
of the Side Trim until the Side Trim is installed.
Install the Fresh Food Door Side Trim
Fit the Side Trim over the ends of the fresh food
door Top and Bottom Trim as illustrated. Make
sure the Side Trim is fitting correctly and that you
are satisfied with the appearance of all parts before
pulling the two pieces of blue tape liner.
Pull the top blue tape liner up about 3" (80 mm),
pressing the trim with your hand as the adhesive is
exposed to the door. Then pull the bottom blue
tape liner down about 3" (80 mm). Follow the tape
with your hand, pressing the trim adhesive against
the door.
Remove the Protective Film From the Outside of the Side Trim
18
Fit the top of the freezer door Side Trim under the
corner of the Top Trim and fit the bottom of the
Side Trim under the Bottom Trim as illustrated.
Make sure the Side trim is fitting correctly and that
you are satisfied with the appearance of all parts
before pulling the blue tape liner.
Holding the trim in place with one hand, gradually
pull the blue tape liner out, perpendicular to the
trim. Pull about 3" (80 mm) out at a time, pressing
the trim with your hand as the adhesive is exposed.
Continue pulling the blue tape liner loose,
alternating between the top and bottom and
pressing the Side Trim against the door.
