Specifications - HP ProCurve 10/100 12 Installation Manual

Specifications

Physical
Width:
Depth:
Height:
Weight :
Electrical
The switch automatically adjusts to any voltage between 100-127 and 200-240
volts and either 50 or 60 Hz.
AC voltage:
Maximum current:
Frequency range:
Environmental
Temperature:
Relative humidity:
(non-condensing)
Maximum altitude:
42.5 cm (17 in)
20.3 cm (8 in)
4.36 cm (1.7 in)
2.2 kg (4.8 lbs)
100–127 volts 200–240 volts
1.0A max 0.5A max
50/60 Hz 50/60 Hz
Operating
0°C to 55°C (32°F to 131°F)
15% to 95% at 40°C (104°F)
4.6 Km (15,000 ft)
Non-Operating
-40°C to 70°C (-40°F to 158°F)
10% to 90% at 65°C (149°F)
4.6 Km (15,000 ft)
A
A-1
