Installing the Hub
Installation Summary

Wall Mounting

You can mount the hub on a wall. Note that the hub should be mounted only
to a wall or wood surface that is at least 1/2-inch plywood or its equivalent.
1.
2.

Horizontal Surface Mounting

Place the hub on a table or other horizontal surface. Use a sturdy surface in
an uncluttered area. You may want to secure the networking cables and hub
power cord to the table leg or other part of the surface structure to help
prevent people from tripping over the cords.
N o t e
Make sure the air flow is not restricted around the sides and back of the hub.
2-8
Use a #1 Phillips (cross-head) screwdriver and attach the mounting
brackets to the hub with the included 10-mm M4 screws.
Attach the hub to the wall or wood surface with 5/8-inch number 12 wood
screws (not included}.
