- Page 1 User Manual CS-9134 CS-9138 2001-05-21...
- Page 2 NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Subpart J of Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 3 Packing List The complete Master View KVM Switch package consists of: One CS-9134 or CS-9138 KVM Switch with Stacking Brackets One Power Adapter One User Manual Check to make sure that the unit was not damaged in shipping. If you encounter a problem, contact your dealer.
-
Page 4: Table Of Contents
CS-9134 / CS-9138 Rear View ........7... -
Page 5: Overview
Now, with the Master View CS-9134/CS-9138, you can easily access multiple computers in a cost effective manner. A single Master View CS-9134 or CS-9138 can control up to 4 or 8 computers, respectively. Since units can be cascaded to three levels, in a full three stage... -
Page 6: Features
Features Cascadable To Three Levels - Control Up to 64 (CS-9134) or 512 (CS-9138) Computers From a Single Console No Software Required - Computer Selection via Front Panel Switches, Hot Keys, or On Screen Display (OSD) Quick View Scan Feature for Monitoring Selected Computers PS/2 and Serial Mouse Emulation Provided For System Bootup Console’... -
Page 7: Hardware Requirements
Either a 6-pin mini-DIN (PS/2 Style) keyboard port with +5V DC on pin 4 and Ground on pin 3, or a 5-pin DIN (AT Style) keyboard port with +5V DC on pin 5 and ground on pin 4.* * See the note under Cables in the next section. CS-9134 / CS-9138 User Manual 2001-05-21... -
Page 8: Cables
3. Because of the wiring and pin assignments, you cannot use a Serial-to-PS/2 adapter at the end that plugs into the CS-9134 or CS-9138. Therefore, attempting to use a standard serial extender cable with adapters at both ends will fail. -
Page 9: Introduction
If the switch is kept in for longer than three seconds, a cold reset takes place. 5. Power LED Lights BLUE to indicate that the Master View CS-9134 is receiving power. CS-9134 / CS-9138 User Manual 2001-05-21... -
Page 10: Cs-9138 Front View
If the switch is kept in for longer than three seconds, a cold reset takes place. 5. Power LED Lights BLUE to indicate that the Master View CS-9138 is receiving power. CS-9134 / CS-9138 User Manual 2001-05-21... -
Page 11: Cs-9134 / Cs-9138 Rear View
The unit is designed to be non-powered (no external power required). It gets the necessary power for its operation from the computers it connects to. In general, there are two conditions when the CS-9134/CS-9138 requires external power: 1. When you cascade it;... -
Page 12: Installation
2. In a Single Stage Installation, PCs connect to all of the Master View’ s CPU ports (1 - 4 for the CS-9134; 1 - 8 for the CS-9138). Use connector cable sets (as described in the Cables section on p. 4), to connect the monitor, keyboard and mouse ports of the computers to any available Master View CPU Port. -
Page 13: Two Stage Installation
Stage unit. The cascaded Master Views that connect back to the First Stage unit are considered Second Stage units. As many as 16 (CS-9134) or 64 (CS-9138) computers can be controlled in a complete two stage installation. Tables showing the relation between the number of computers and the number of Master View units needed to control them are provided in the Appendix. -
Page 14: Three Stage Installation
The procedures for setting up a three stage installation are essentially the same as for a two stage installation. With a three stage setup, as many as 64 (CS-9134) or 512 (CS-9138) computers can be controlled in a complete installation. - Page 15 After all the Second Stage units are on, the First Stage unit must be powered on. Only after all the Master Views have been powered on in this sequence, can the computers be powered on. CS-9134 / CS-9138 User Manual 2001-05-21...
-
Page 16: Operation
Operation Hot Plugging The Master View CS-9134/CS-9138 supports hot plugging - components can be removed and added back into the installation by unplugging their cables from the ports without the need to shut the unit down. In order for hot plugging to... -
Page 17: Port Selection
Master View Station that connects directly to the computer you want to access. 2. Simultaneously pressing Port Selection buttons 3 and 4 (CS-9134) or 7 and 8 (CS-9138) on the First Stage unit initiates the Quick View Scan feature in which all the ports currently selected for Quick View scanning with the OSD’... -
Page 18: Port Id Numbering
For example, a computer attached to a First Stage unit has a one digit Port ID (from 1 to 4 for the CS-9134; from 1 to 8 for the CS-9138), that corresponds to the CPU port number that the computer is connected to. -
Page 19: Osd
OSD always starts in List view, with the highlight bar at the same position it was in the last time it was closed. The next two sections explain how to navigate using the OSD and OSD Hotkey methods. CS-9134 / CS-9138 User Manual 2001-05-21... -
Page 20: Osd Navigation
Number keys must be pressed from the regular keyboard; not from the numeric keypad. If you submit an incorrect Port ID, an error message displays, and you are returned to the OSD Main Menu. CS-9134 / CS-9138 User Manual 2001-05-21... -
Page 21: Osd Main Menu Headings
If the next letter you type is b, the list is narrows down even further to only those ports whose names begin with ab, etc. To return to the OSD Main Menu without making a choice, press [Esc]. CS-9134 / CS-9138 User Manual 2001-05-21... - Page 22 (see F4, below), and have been assigned names (see F5, below). NAME Lists only the ports that have been assigned names (see F5, below). POWERED ON Lists only the ports that have their attached computers Powered On. CS-9134 / CS-9138 User Manual 2001-05-21...
- Page 23 Case does not matter; OSD displays the Port Name in all capitals no matter how they were keyed in. 4. When you have finished editing, press [Enter] to have the change take effect. To abort the change, press [Esc]. CS-9134 / CS-9138 User Manual 2001-05-21...
- Page 24 HOTKEY [Ctrl] or [Scroll Lock] [Scroll Lock]. The default is the Ctrl key combination, but this may conflict with programs running on the computers, in which case, the Scroll Lock option should be used. CS-9134 / CS-9138 User Manual 2001-05-21...
- Page 25 Console. If no password has been set, pressing [Enter] will Lock / Unlock the Console. * If a password has been set, this setting requires you to supply it in order to gain access. See the OSD Security section, below, for details. CS-9134 / CS-9138 User Manual 2001-05-21...
-
Page 26: Factory Default Settings
Note: To modify or delete a previous password, access the Password function as in Steps 1 and 2, then use the backspace or delete key to erase the individual letters or numbers. CS-9134 / CS-9138 User Manual 2001-05-21... -
Page 27: Appendix
239 - 246 372 - 379 505 - 512 113 - 120 246 - 253 379 - 386 120 - 127 253 - 260 386 - 393 127 - 134 260 - 267 393 - 400 CS-9134 / CS-9138 User Manual 2001-05-21... -
Page 28: Troubleshooting
1. Reset the mouse (and keyboard) by responding. reset. simultaneously pressing Buttons 1 and 2 on the First Stage unit for 3 seconds. 2. Unplug the mouse connector from the Console Mouse Port, then plug it back in. CS-9134 / CS-9138 User Manual 2001-05-21... -
Page 29: Specifications
5 - 40 Storage Temperature -20 - 60 Humidity 0 - 80% RH Housing Metal Weight 2500 g 2850 g Dimensions (L x W x H) 483 x 150 x 44.5 mm (19" 1U) CS-9134 / CS-9138 User Manual 2001-05-21... -
Page 30: Stacking And Mounting
2. Screw the mounting brackets into the sides of the unit, as shown in the diagram below: 3. Slide the unit into the rack and secure it to the rack. CS-9134 / CS-9138 User Manual 2001-05-21... -
Page 31: Limited Warranty
The direct vendor also reserves the right to revise or update the device or documentation without obligation to notify any individual or entity of such revisions, or update. For further inquires please contact your direct vendor. CS-9134 / CS-9138 User Manual 2001-05-21...
