Installing or Changing a Hard Drive
IMPORTANT NOTE: The following instructions are for installing or changing the
hard drive. If your DVR4-5000™ already has a hard drive pre-installed, and you
don't want to change it, disregard these steps.
Installing / Changing a Hard Drive in the DVR4-5000™
1. Ensure the DVR4-5000™ is unplugged and removed from mains power.
2. Locate and remove the 4 screws on
the back of the DVR.
Power/SATA
Cable
4. Remove the combination Power/
SATA cable from the hard drive.
6. Screw in the hard drive to the bottom of the case as in step 5.
7. Replace the Hard Drive and plug in the Power/SATA cable as shown in step 4.
8. Replace the Hard Drive chassis, as shown in step 3.
9. Replace the screws removed in step 2.
Remove
3. Pull up the hard drive chassis on
the back of the DVR.
5. Locate the screws holding the hard
drive in the chassis, and remove.
Remove
17
