Page 1: Bluetooth Gps
Rikaline GPS-6036 Bluetooth GPS SiRF Star III User’s Guide Feb. 15, 2006 Rikaline International Corp. 14F, 171, ChengGong Rd., Sanchong City, Taipei 241, Taiwan, R.O.C Phone: +886-2-8973-1899 Fax: +886-2-8973-1896 E-Mail: info@rikaline.com.tw Web: www.rikaline.com.tw All Right Reserved... -
Page 2: Table Of Contents
Rikaline GPS-6036 Operating Manual TABLE OF CONTENTS 0. Quick Use ……….………………………………………………………………….. 0.0 Standard Package ..………………………………………………………….. 0.1 Fully charge the battery for at least 10 hours before using ……………… 0.2 Activate the Bluetooth function in your PDA or PC ………………………… 3 0.3 Automatically create a shortcut in Bluetooth Manager window …….……... -
Page 3: Quick Use
0.2 Activate the Bluetooth function in your PDA or PC Before activating the Bluetooth function in your PDA/PC, please Switch ON GPS-6036 Receiver for paring and check if your device is equipped with Bluetooth function. If not, you may need to acquire an optional CF (PD-3005) or SD Bluetooth card. -
Page 4: Introduction
RS-232 or TTL and saves critical satellite data by built–in backup memory. With low power consumption, the GPS-6036 tracks up to 12 satellites at a time, re-acquires satellite signals in 100 ms and updates position data every second. Trickle-Power (optional function) allows the unit operates a fraction of the time and Push-to-Fix (optional function) permits user to have a quick position fix even though the receiver usually stays off. - Page 5 Rikaline GPS-6036 Operating Manual 1.3.4 Performance 1.3.4.1 LED functions We built 3 LEDs in the GPS-6036 Bluetooth GPS with functions as follows: LED Status Flash Power (Red) Low Power Recharging / System on Sufficient Power Bluetooth (Blue) Paring or Power on...
-
Page 6: Operational Characteristics
1) The GPS-6036 utilizes initial data, such as last stored position, date, time and satellite orbital data, to achieve maximum acquisition performance. If significant inaccuracy exists in the initial data, or the orbital data is obsolete, it may take more time to achieve a navigation solution. -
Page 7: Hardware Interface
Weight: 25g 3.2 Hardware Interface The GPS-6036 includes a new generation low power GPS module, a Bluetooth module and a Li-ION rechargeable battery in a unique style gadget. Simply place it into the cradle (enclosed in the package) then stick it on the dashboard of the car or any place which is not deeply covered by metal or other heavy material for transmitting GPS signal to your notebook PC, PDA or other devices, which facilitated with Bluetooth functions. -
Page 8: Bluetooth Connection
Firstly, you need to find the device with which you want to establish connection. Open “Bluetooth Manager” on your pocket PC. Click “New” Click “Connect” Search Bluetooth device “Rikaline 6033” To find the Bluetooth device Select “Explore a Bluetooth device” Double click “Rikaline”... -
Page 9: Application
Fig. 2 Browse Service Fig. 3 Browse Service Finish Bluetooth Manager Setup Tap and Hold “Rikaline: SPP slave” Click “Connect” Finish Bluetooth setup After you click the SPP service, it will show as Fig. 4: Fig. 4 Connect to SPP Fig. - Page 10 Rikaline GPS-6036 Operating Manual 4.4.1 Double click the SPP shortcut, and click Disconnect on popup Menu. Fig. 6 Disconnect from pop menu Figure 7 Disconnect from Status Window 4.4.2 In the Status window, select the SPP connection, and then click Disconnect button.
-
Page 11: Safety Statement
6. Warranty The GPS-6036 is warranted to be free from defects in material and functions for one year from the date of purchase. Any failure of this product within this period under normal conditions will be replaced at no charge to the customers. -
Page 12: Appendix A Software Inferface
A.1 NMEA Transmitted Messages The GPS-6036 supported by SiRF Technology Inc. also outputs data in NMEA-0183 format as defined by the National Marine Electronics Association (NMEA), Standard. The default communication parameters for NMEA output are 4800 baud, 8 data bits, stop bit, and no parity. - Page 13 Rikaline GPS-6036 Operating Manual A.1.2 Geographic Position with Latitude/Longitude (GLL) Table A-4 contains the values for the following example: $GPGLL,3723.2475,N,12158.3416,W,161229.487,A*2C Table A-4 GLL Data Format Name Example Units Description Message ID $GPGLL GLL protocol header Latitude 3723.2475 ddmm.mmmm N/S Indicator...
- Page 14 Rikaline GPS-6036 Operating Manual Name Example Units Description Message ID $GPGSV GSV protocol header Number of Messages Range 1 to 3 Message Number Range 1 to 3 Satellites in View Range 1 to 12 Satellite ID Channel 1 (Range 1 to 32)
-
Page 15: Rtcm Received Data
The default communication parameters for DGPS Input are 9600 baud, 8 data bits, stop bit, and no parity. Position accuracy of less than 5 meters can be achieved with the GPS-6036 by using Differential GPS (DGPS) real-time pseudo-range correction data in RTCM SC-104 format, with message types 1, 5, or 9. As using DGPS receiver with different communication parameters, GPS-6036 may decode the data correctly to generate accurate messages and save them in battery-back SRAM for later computing. -
Page 16: Earth Datums
Rikaline GPS-6036 Operating Manual Appendix B Earth Datums & Output Setting B.1 Earth Datums The GPS-6036 is built in earth datum with WGS84. B.2 Setting B.2.1 Manufacturing Default Datum: WGS84. Baud Rate: 9600. Output: GGA, GSA, GSV, RMC, VTG. WAAS/EGNOS: OFF (Optional ON is for the area covered by WAAS/EGNOS) B.2.2 Baud Rate and Output Sentences Setting... -
Page 17: Bluetooth Specification
Rikaline GPS-6036 Operating Manual Appendix C Detailed Specifications C.1 Bluetooth Specifications C.1.1 Major Specification Specifications Wireless Interface Compliant with Bluetooth Spec. Version 1.2 Bluetooth Protocol Stack Supported All + Extended SCO Bluetooth Profiles Supported Frequency 2.4 GHz license-free ISM band... - Page 18 Rikaline GPS-6036 Operating Manual Capacity cut-off within 1 hour after complete charge. Measure the capacity after 300 cycles of complete charge ¡ Ù 80% of initial Capacity Cycle Life and discharge at 1C current to 2.75V cut-off Capacity after 30days storage at 25¢ J from complete Retention capacity¡...
-
Page 19: Appendix D Trouble Shooting
Methods No position output but Weak or no GPS signal can be Find an open space for your timer is counting received at the place of GPS-6036 GPS-6036 Execute fail Bluetooth function unstable Re-Start PDA or PC or re-install software... -
Page 20: Appendix E Ordering Information
GPS-6036 Operating Manual Appendix E Ordering Information E.1 Product Options E.1.1 Standard Package GPS-6036 (Bluetooth GPS Receiver) + Lithium-ION Rechargeable Bat tery + Cradle + Travel Charger + Cigarette Adapter + Documents CD + Warranty Card + Quick Installation Reference E.2 Accessories E.2.1 Color Cover Series...
