Rikaline GPS-6031-X7 User Manual

Sirf high sensitivity bluetooth gps receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rikaline
GPS-6031-X7
SiRF High sensitivity

Bluetooth GPS

Receiver
User's Guide
Aug. 18, 2003
V1.0
Rikaline
International Corp.
10F, 64, Kang-Ding Road, Taipei 108, Taiwan, R.O.C.
Phone: +886-2-2370-4688 Fax: +886-2-2370-4686
E-Mail: info@rikaline.com.tw Web: www.rikaline.com.tw
All Right Reserved

Advertisement

Table of Contents
loading

Related Manuals for Rikaline GPS-6031-X7

Summary of Contents for Rikaline GPS-6031-X7

  • Page 1: Bluetooth Gps

    Rikaline GPS-6031-X7 SiRF High sensitivity Bluetooth GPS Receiver User’s Guide Aug. 18, 2003 V1.0 Rikaline International Corp. 10F, 64, Kang-Ding Road, Taipei 108, Taiwan, R.O.C. Phone: +886-2-2370-4688 Fax: +886-2-2370-4686 E-Mail: info@rikaline.com.tw Web: www.rikaline.com.tw All Right Reserved...

  • Page 2: Table Of Contents

    D.2 Cautions ……..…………………………………………………………………………….… Appendix E Ordering Information E.1 Product Options E.2 Accessories ………………………………………………………………………….……… Rikaline International Corp. Tel: ++886 2 2370 4688 Fax: ++886 2 2370 4686 GPS-6031-X7 Operating Manual TABLE OF CONTENTS …………………………………………………….. ……………………………………………………………….. ……………………………………………………………….… …..……………………………………………………………….…… ……………………………………………………………………….… ……………………………………………………………………………. …..………………………………………………………………………. ……………………………………………………………. ……………………………………………………..…...

  • Page 3: Quick Use And Basic Specifications

    2. Software (Navigation Software + Digital Map) 3. Others 0.2 Have the Battery Fully Recharged. Before use the battery, please put it in GPS-6031-X7 and have it be recharged for 10 hours. Details please refer to Appendix D at P.17. 0.3 Power on GPS-6031-X7.

  • Page 4: Introduction

    The GPS-6031-X7 communicates with other electronic utilities via wireless Bluetooth technology and saves critical satellite data by built–in backup memory. With low power consumption, the GPS-6031-X7 tracks up to 12 satellites at a time, re-acquires satellite signals in 100 ms and updates position data every second.
  • Page 5 3) SiRF protocol. Rikaline International Corp. Tel: ++886 2 2370 4688 Fax: ++886 2 2370 4686 GPS-6031-X7 Operating Manual 5-25 meter CEP with SA off 0.1 meters/second, with SA off microsecond synchronized GPS time 18,000 meters (60,000 feet) max meters / second (1000 knots) max...

  • Page 6: Operational Characteristics

    2. Operational characteristics 2.1 Initialization Once you insert the battery into the housing, the GPS-6031-X7 is in standby mode and ready to work for you. When you activate the Bluetooth function in your machine (PDA or PC) and get pairing with PGS-6031-X7, you may start GPS function.

  • Page 7: Hardware Interface

    Weight: 87g 3.2 Hardware Interface The GPS-6031-X7 includes a SiRF LP (Low Power) and HS (High Sensitivity) GPS module, Bluetooth module and a Li-Polymer rechargeable battery in a unique style gadget. Simply place it on the dashboard of the car or any place facing to the sky for transmitting GPS signal to your notebook PC, PDA or other devices, which facilitated with Bluetooth functions.

  • Page 8: Bluetooth Connection

    The Default Passkey is 1234. Rikaline International Corp. Tel: ++886 2 2370 4688 Fax: ++886 2 2370 4686 GPS-6031-X7 Operating Manual Click this refresh button to find the device if the device is not in the device window. Fig. 1 Browse Device Fig.

  • Page 9: Application

    Rikaline GPS-6031-X7 Operating Manual SiRF LP, Bluetooth GPS Finally, it will show as follows: Click here Fig. 4 Service Searching Succeeds. After you click the SPP service, it will show at left of followings: Fig. 5 Connect to SPP Fig. 6 After connect successfully, it will show as Fig.

  • Page 10: Waranty

    Pop_Menu to re-establish the connection. 5. Warranty The GPS-6031-X7 is warranted to be free from defects in material and functions for one year from the date of purchase. Any failure of this product within this period under normal conditions will be replaced at no charge to the customers.

  • Page 11: Appendix A Software Inferface

    RTCM Special Committee No.104). A.1 NMEA Transmitted Messages The GPS-6031-X7 outputs data in NMEA-0183 format as defined by the National Marine Electronics Association (NMEA), Standard. The default communication parameters for NMEA output are 4800 baud, 8 data bits, stop bit, and no parity.
  • Page 12 Table A-8 contains the values for the following example: $GPGSV,2,1,07,07,79,048,42,02,51,062,43,26,36,256,42,27,27,138,42*71 $GPGSV,2,2,07,09,23,313,42,04,19,159,41,15,12,041,42*41 Rikaline International Corp. Tel: ++886 2 2370 4688 Fax: ++886 2 2370 4686 GPS-6031-X7 Operating Manual Units GLL protocol header ddmm.mmmm N=north or S=south dddmm.mmmm E=east or W=west hhmmss.sss...
  • Page 13 Reference Course Rikaline International Corp. Tel: ++886 2 2370 4688 Fax: ++886 2 2370 4686 GPS-6031-X7 Operating Manual Units GSV protocol header Range 1 to 3 Range 1 to 3 Range 1 to 12 Channel 1 (Range 1 to 32)

  • Page 14: Rtcm Received Data

    The default communication parameters for DGPS Input are 9600 baud, 8 data bits, stop bit, and no parity. Position accuracy of less than 5 meters can be achieved with the GPS-6031-X7 by using Differential GPS (DGPS) real-time pseudo-range correction data in RTCM SC-104 format, with message types 1, 5, or 9. As using DGPS receiver with different communication parameters, GPS-6031-X7 may decode the data correctly to generate accurate messages and save them in battery-back SRAM for later computing.

  • Page 15: Appendix B Earth Datums And Output Setting

    SiRF LP, Bluetooth GPS Appendix B Earth Datums & Output Setting B.1 Earth Datums The GPS-6031-X7 is built in earth datum with WGS84. B.2 Setting B.2.1 Manufacturing Default Datum: WGS84. Baud Rate: 4800. Output: GGA, GSA, GSV, RMC, VTG. WAAS OFF Rikaline International Corp.

  • Page 16: Appendix C Bluetooth Specifications

    For clear link key information of Bluetooth. Rikaline International Corp. Tel: ++886 2 2370 4688 Fax: ++886 2 2370 4686 GPS-6031-X7 Operating Manual Compliant with Bluetooth Spec. Version 1.1 2.4 GHz license-free ISM band Up to 10 meters Range (30ft) <-84dBm at 1 e-3 BER...

  • Page 17: Appendix D Battery Specifications

    Drop the cells from 1.5 m above a concrete floor for 18 times (3 times per face, 6 faces per cell), measure the AC impedance. Rikaline International Corp. Tel: ++886 2 2370 4688 Fax: ++886 2 2370 4686 GPS-6031-X7 Operating Manual Battery Specifications ITEM Lithium-Polymer Rechargeable Battery A-9001 1650 mAh 1500 mAh 3.7 V...

  • Page 18: Cautions

    3) Recharge the battery for 10 hours before use. Rikaline International Corp. Tel: ++886 2 2370 4688 Fax: ++886 2 2370 4686 GPS-6031-X7 Operating Manual 10F, 64, Kang-Ding Road, Taipei 108, Taiwan E-Mail: info@rikaline.com.tw No fire, no explosion No fire, no...

  • Page 19: Appendix E Ordering Information

    Appendix E E.1 Product Options E.1.1 Standard Package GPS-6031-X7 (Bluetooth GPS Receiver) + CD + Warranty Card + Cigarette Adapter + Battery Instruction + Quick Installation Reference + 2 Sets of Wings. E.1.2 Color Option Dark Grey Base + Color Wings (Standard) White Base + Color Wings (Optional) E.2 Accessories...
