ZyXEL Communications P-2812HNU-51c Quick Start Manual

Dual wan vdsl2 iad with 802.11n wireless
Hide thumbs Also See for P-2812HNU-51c:

Advertisement

Quick Links

Download this manual See also: User Manual
P-2812HNU-51c
Dual WAN VDSL2 IAD with
802.11n Wireless
Firmware V1.00
Edition 1, 11/2009
DEFAULT LOGIN DETAILS
IP Address:
Username:
Password:
www.zyxel.com
https://192.168.1.1
Admin account: admin
User account: user
Admin account: 1234
User account: user
Copyright 2009
ZyXEL Communications Corporation

Advertisement

loading

Related Manuals for ZyXEL Communications P-2812HNU-51c

Summary of Contents for ZyXEL Communications P-2812HNU-51c

  • Page 1 P-2812HNU-51c Dual WAN VDSL2 IAD with 802.11n Wireless Firmware V1.00 Edition 1, 11/2009 DEFAULT LOGIN DETAILS IP Address: https://192.168.1.1 Username: Admin account: admin User account: user Password: Admin account: 1234 User account: user Copyright 2009 ZyXEL Communications Corporation www.zyxel.com...
  • Page 2 Device Panels ON/OFF POWER RESET PHONE PORTS USB PORTS DSL/WAN LEDS WAN PORT ETHERNET PORTS DSL PORT...
  • Page 3 Overview The P-2812HNU-51c is a router which combines high-speed VDSL/ ADSL Internet access, a built-in switch, a firewall and high-speed wireless networking capability. It also has two USB 2.0 ports for sharing files via a USB compatible storage device and two phone ports for making calls over the Internet (Voice over IP or VoIP).

  • Page 4: Hardware Connections

    If a screen does not pop up, open Windows Explorer (click My Computer), click on the CD-ROM drive (usually drive D) and navigate to it from there. Hardware Connections Remove the P-2812HNU-51c’s plastic cover before using it.
  • Page 5 4. PHONE: Use a telephone cable (and any telephone adaptor provided with your P-2812HNU-51c) to connect a telephone to the PHONE 1 or PHONE 2 port. If you only have one telephone, you should use port 1.
  • Page 6 Look at the LEDs (lights) on the rear panel of the P-2812HNU-51c. • The PWR/SYS light blinks during start-up and is green once the P-2812HNU-51c is ready. • An ETHERNET light turns on if the corresponding ETHERNET port is properly connected.
  • Page 7 If no lights are on, check your connections. Make sure that you have the power adaptor connected to the P-2812HNU- 51c and plugged in to an appropriate power source. Make sure the power source is turned on. Turn the P-2812HNU- 51c off, wait for a few seconds and turn it back on.

  • Page 8: Set Up A Wireless Network

    If the login screen does not open, make sure you allow web browser pop-up windows, JavaScripts and Java permissions. Your computer should be also set to get an IP address automatically from a DHCP server. See the appendices in your User’s Guide for more information. See your User's Guide for how to use the VoIP >...
  • Page 9 PIN (Personal Identification Number) into the configuration screen of the P-2812HNU-51c. See PIN Configuration on page 10. You must use the same method on the P-2812HNU-51c and the wireless client. Push Button Configuration 1. Place a WPS-enabled device that is installed in your system and supports the WPS Push Button method within range of the P- 2812HNU-51c.
  • Page 10 You must press the second button within two minutes of pressing the first one. 4. The P-2812HNU-51c and the wireless device establish a secure connection. This can take up to two minutes. 5. Congratulations! Your computer is now ready to connect to the Internet wirelessly through your P-2812HNU-51c.
  • Page 11 Start in the P-2812HNU-51c web configurator screen. 6. The P-2812HNU-51c and the other WPS-enabled device establish a secure connection. This can take up to two minutes. 7. Congratulations! Your computer is now ready to connect to the Internet wirelessly through your P-2812HNU-51c.
  • Page 12 Click View Available Wireless Networks. 2. Select the P-2812HNU-51c’s SSID name and click Connect (A). The SSID “SecureWirelessNetwork” is given here as an example. 3. You are prompted to enter a password. Enter it and click Connect.
  • Page 13 Congratulations! Your computer is now ready to connect to the Internet wirelessly through your P-2812HNU-51c. If you cannot connect wirelessly to the P-2812HNU-51c, check you have selected the correct SSID and entered the correct security key. If that does not work, ensure your wireless network adapter is enabled by clicking on the wireless adapter icon and clicking Enable.
  • Page 14 (the sound a caller hears before you pick up the phone) and on hold tones (the sound someone hears when you put their call on hold). #### Internal Call Call the phone(s) connected to the P-2812HNU-51c.

  • Page 15: Usb File Sharing

    One Shot Caller Hidden Call To call into the phone that is attached to the P-2812HNU-51c, use your VoIP service provider’s dialing plan. USB File Sharing This section shows you how to enable USB file sharing. In order to start file sharing you need to: •...
  • Page 16 2. Check the box Enable File Sharing Services and click Apply/Save. The P-2812HNU-51c automatically recognizes the USB device which is connected to the USB port and makes it available for sharing. Browse to the USB File Share 1. In Windows Explorer’s...
  • Page 17 2. Enter the user name and password in the window prompt that appears and hit OK. 3. The files on the USB file sharing device connected to the P- 2812HNU-51c are now part of your file structure and you can manage those files just like any other files on your computer.
