■ Optional battery chargers

NOTE: See each instruction manual for details of the char-
ger LED indication, operation, etc.
D AD-110 installation
The AD-110
charger adapter
119N or BC-121N before battery charging.
➥ Connect the AD-110
charger adapter
121N as below, then install the AD-110 into the holder space
of the BC-119N or BC-121N with the supplied screws.
Connectors
AD-110
Plugs
must be installed into the BC-
and the BC-119N/BC-
Screws supplied
with the charger
adapter
This illustration shows the BC-119N.
BATTERY CHARGING
D Rapid charging with the BC-119N+AD-110
The optional BC-119N provides rapid charging of battery packs.
The following items are additionally required.
• AD-110 charger adapter
• An AC adapter (may be supplied with BC-119N depending
on version) or the DC power cable (OPC-515L/CP-17L).
BATTERY
AC adapter PACK
(A different type, or no AC
adapter is supplied, de-
pending on the version.)
Optional OPC-515L (for 13.8 V
power source) or CP-17L (for 12
V cigarette lighter socket) can be
used instead of the AC adapter.
4
TRANSCEIVER
Turn power OFF
AD-110 charger
adapter is installed
in BC-119N.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
21
