Site Selection - Hunter ceiling fan Installation Manual

Introduction and Preparation ....................................................................................................................................................................................................................................... 2
Using This Manual ................................................................................................................................................................................................................................................................ 3
Installation ................................................................................................................................................................................................................................................................................ 4
Operation and Troubleshooting .................................................................................................................................................................................................................................14
Congratulations!
Your new Hunter ceiling fan is an addition to your home or office that will
provide comfort and reliable performance for many years. We are proud
to supply you with the best ceiling fan available anywhere in the world.
Before installing your fan, we recommend that you record the following
information for your records and warranty assistance. Refer to the Hunter
nameplate on the top of your fan for the proper information. Be sure to
save your receipt for your records.
Model Name
Model Number
Serial Number
Date Purchased
Place Purchased
Site Selection and Preparation
Refer to the included booklet "Guide to Choosing and Preparing a Ceiling Fan Site" to determine the best location for your fan. The booklet also includes
information to ensure your fan support and outlet box meet applicable safety codes for ceiling fans.
Checking Your Fan Parts
Check your fan parts carefully. Unpack your fan parts as instructed by this manual to avoid damage. Be sure to save this manual for reference and save any
extra parts. If you have a damaged fan blade, please return all blades for replacement. If you are installing more than one fan, be sure to keep the blades in
sets, as shipped.
Optional Accessories
Hunter offers several accessories to complement your fan such as wall-mounted or remote speed controls and extension down-rods for ceilings higher than
8 feet (2.4 meters). To ensure wobble-free and stable performance, all Hunter fans use 2 cm inner-diameter pipe for extensions. Follow the instructions for
use and installation included with the Hunter accessory.
For quiet and optimum performance of your Hunter fan, use only Hunter speed controls and accessories.
Table Of Contents
Welcome
Before Installation
Before installing your fan, be sure you can do the following:
• Locate the ceiling joist or other suitable support in the ceiling.
• Drill holes and install wood screws or expansion anchors.
• If you have a concrete ceiling, you will need M5 x 30 mm expansion
anchors and screws. (Sold separately)
• Identify and connect electrical wires.
• Lift 16 kg (40 lbs).

Site Selection

2
