CDM-840 Remote Router
Flash Upgrading
9
Transfer the files:
Type "put Fw0000408x.bin bulk:" (where 'x' denotes the revision letter) to begin the file
transfers. It will take a few seconds to transfer the file.
The process sequences through several blocks – this may take several minutes. When the
upgrade image has been received, the image will be written to flash memory and the message
"UPLOAD COMPLETE" will be displayed.
10
Verify the file transfer.
a) Terminate the FTP session by typing "bye" and closing the Command-line window.
b) Verify that the new file loaded, either by using the CLI window or Web Server
11
Change the desired image to boot. Via the Web Server Interface's Admin | Firmware page,
use the 'Boot From:' drop-down menu to select Latest, Slot 1, or Slot 2. By default, the unit
will boot to the version with the latest date (Boot From: Latest).
"Boot From:" can otherwise be set to force the unit to boot up using either firmware image
loaded in Slot 1 or Slot 2.
12
Reboot the CDM-840. The firmware upgrade is implemented at this time.
Flash Upgrading of the CDM-840 Remote Router is now complete.
Interface as per the procedures described in Step 1.
4–4
Revision 0
MN-CDM840
