Extron electronics MLS 304MA User Manual page 51

Nominal level ................................ 1 Vp-p for Y of S-video, and for composite video
Minimum/maximum levels
RGB ..................................... Analog: 0.3 V to 1.5 Vp-p (follows input)
Composite video ............... Analog: 0.4 V to 2.0 Vp-p (follows input)
Impedance ..................................... 75 ohms
Return loss ..................................... <-40 dB @ 5 MHz
DC offset ........................................ ±5 mV with input at 0 offset
Switching type .............................. Triple-Action (RGB delay)
Sync
Input type ...................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................... RGBHV, RGBS, RGsB, RsGsBs (follows input)
Standards ........................................ NTSC 3.58, NTSC 4.43, PAL, SECAM
Input level ..................................... 2.0 V to 5.0 Vp-p
Output level .................................. TTL: 5.0 Vp-p, unterminated
Input impedance .......................... 10k ohms
Output impedance ....................... 75 ohms
Max input voltage ........................ 5.0 Vp-p
Max. propagation delay ............... 30 ns
Max. rise/fall time ........................ 4.0 ns
Polarity............................................ Positive or negative (follows input)
Audio
Gain ................................................ Unbalanced output: 0dB; balanced output: +6dB
Frequency response at 1 watt output
Preamp/Lineout ................ 20 Hz to 20 kHz, ±0.5 dB
Direct (4/8 ohm) ................ 20 Hz to 20 kHz, ±1.0 dB
Transformer (70V mono amplifier)
Transformer (100V mono amplifier)
THD + Noise
Power amp (mono or stereo)
Preamp ................................ 0.11% @ 1 kHz at nominal level
Lineout ................................ 0.018% @ 1 kHz at nominal level
S/N at maximum power output (unweighted)
Power amp ......................... >75 dB @ 10 Hz to 22 kHz
Preamp ................................ >80 dB @ 10 Hz to 22 kHz
Lineout ................................ >80 dB @ 10 Hz to 22 kHz
Crosstalk
Power amp ......................... <-75 dB @ 1 kHz, fully loaded
Preamp ................................ <-75 dB @ 1 kHz, fully loaded
Lineout ............................... <-80 dB @ 1 kHz, fully loaded
Stereo channel separation ........... >80 dB @ 1 kHz
CMRR ............................................. >85 dB @ 20 Hz to 200 Hz, >75 dB @ 20 Hz to 20 kHz
Bass .................................................. ±10 dB @ 100 Hz
Treble ............................................... ±10 dB @ 10 kHz
Loudness (contour) ....................... +6 dB @ 100 Hz to 10 kHz
0.7 Vp-p for RGB
0.3 Vp-p for C of S-video (MLS 406 Series)
50 Hz to 20 kHz, +0 dB/-3 dB
50 Hz to 20 kHz, +0 dB/-3 dB
0.037% @ 1 kHz at nominal level (1 watt, 8 ohm load)
MLS 304 Series, MLS 406 Series • Reference Material A-
