Pride Jazzy 1122 Owner's Manual

Jazzy 1122
Hide thumbs Also See for Jazzy 1122:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
Owner's Manual
Please read the content
of your owner's manual
before operating your
Exeter, PA
St. Catharines, ON
ATTENTION:
power chair.
1-800-800-8586
www.pridemobility.com

Advertisement

Table of Contents
loading

Related Manuals for Pride Jazzy 1122

Summary of Contents for Pride Jazzy 1122

  • Page 1 Owner’s Manual ATTENTION: Please read the content of your owner’s manual before operating your power chair. Exeter, PA St. Catharines, ON 1-800-800-8586 www.pridemobility.com...
  • Page 2 PROHIBITED! These actions are prohibited. These actions should not be performed at any time or in any circumstances. Performing a prohibited action can cause injury to personnel and/or damage to equipment (black symbol with red circle and red slash). Copyright © 2006 Pride Mobility Products Corp. INFMANU1489/RevH/May 2006 www.pridemobility.com Jazzy 1122...
  • Page 3 This owner’s manual is compiled from the latest specifications and product information available at the time of publi- cation. We reserve the right to make changes as they become necessary. Any changes to our products may cause slight variations between the illustrations and explanations in this manual and the product you have purchased. Jazzy 1122 www.pridemobility.com...
  • Page 4 I N T R O D U C T I O N SAFETY WELCOME to Pride Mobility Products Corporation (Pride). The power chair you have purchased combines state-of-the-art components with safety, comfort, and styling in mind. We are confident that these design features will provide you with the conveniences you expect during your daily activities.
  • Page 5 These message boards invite you to communicate with other Pride custom- ers as well as Pride representatives who are available to assist you with any questions or concerns you may have. My Authorized Pride Provider: Name:_____________________________________________________________________________________ Address:_______________________________________________________________________________ Phone Number:__________________________________________________________________________ Purchase Date:___________________________________________________________________________ Jazzy 1122 www.pridemobility.com...
  • Page 6 ! Check all electrical connections. Make sure they are tight and not corroded. ! Check all controller connections to the electronics tray. Make sure they are secured properly. ! Check the brakes. See IX. “Care and Maintenance.” ! Check battery charge. See VIII. “Batteries and Charging.” www.pridemobility.com Jazzy 1122...
  • Page 7 If your power chair starts to move down the incline faster than you anticipated or desired, allow it to come to a complete stop by releasing the joystick, then push the joystick forward slightly to ensure a safely controlled descent. Jazzy 1122 www.pridemobility.com...
  • Page 8 WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibil- ity of a tip or fall. To avoid personal injury and/or property damage, always exercise com- mon sense when cornering. www.pridemobility.com Jazzy 1122...
  • Page 9 WARNING! Do not attempt to have your power chair proceed backwards down any step, curb, or other obstacle. This may cause the power chair to tip and cause personal injury. CURB CURB Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach Jazzy 1122 www.pridemobility.com...
  • Page 10 WARNING! Always be sure your power chair and its batteries are properly secured when it is being transported. Failure to do so may result in personal injury and/or damage to your power chair. www.pridemobility.com Jazzy 1122...
  • Page 11 WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be properly belted into seats approved by the vehicle manufacturer. Jazzy 1122 www.pridemobility.com...
  • Page 12 WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or if you have certain physical limitations. Some medications and limitations may impair your ability to operate your power chair in a safe manner. www.pridemobility.com Jazzy 1122...
  • Page 13 NOTE: For further information on EMI/RFI, visit the Resource Center on www.pridemobility.com. If unintended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Call Pride at 800-424-8205 to report the incident. Jazzy 1122 www.pridemobility.com...
  • Page 14 (optional), harness connectors, and a body shroud. See figures 5 through 9. SEATBACK ARMRESTS SEAT ASSEMBLY CONTROLLER (REMOTE PLUS SHOWN) BODY SHROUD FOOTRIGGING POWER BASE ASSEMBLY (FOOT PLATFORM SHOWN) REAR CASTER WHEEL ANTI-TIP WHEELS DRIVE WHEEL Figure 5. The Jazzy 1122 www.pridemobility.com Jazzy 1122...
  • Page 15 (not shown). The Remote Plus and Europa use smaller, multi-pin communications cable connectors. See figure 6. CHARGER POWER CORD RECEPTACLE CONTROLLER CONNECTOR (REMOTE PLUS SHOWN) OPTIONAL ACCESSORY CONNECTOR LOCATION AMMETER CHARGER FUSE MAIN CIRCUIT BREAKER Figure 6. Electronics Tray Jazzy 1122 www.pridemobility.com...
  • Page 16 NOTE: If a lever is difficult to move in either direction, rock your power chair back and forth slightly. The lever should then move to the desired position. Figure 7. Freewheel Mode (left side shown) Figure 8. Drive Mode (left side shown) www.pridemobility.com Jazzy 1122...
  • Page 17 This system also enhances performance when the front anti- tip wheels are set lower to the surface. REAR CASTER FORK REAR CASTER WHEEL Figure 9. Rear Suspension System Jazzy 1122 www.pridemobility.com...
  • Page 18 ¹Varies with user weight, terrain type, battery amp hour rating (AH), battery charge, battery condition, and tire condition. ²Due to manufacturing tolerances and continued product improvement, this specification can be subject to variance of (+ or – ) 3%. ³AGM or Gel-Cell type recommended. NOTE: All specifications subject to change without notice. www.pridemobility.com Jazzy 1122...
  • Page 19 WARNING! Do not pick up the seat frame by the armrests. They are free to pivot, and you may lose control of the seat if they do so, resulting in personal injury or damage to the chair. SEAT LATCH SAFETY REAR TRAPEZE BAR REAR EXTRUSION FRONT TRAPEZE BAR FRONT EXTRUSION Figure 10. Seat Installation Jazzy 1122 www.pridemobility.com...
  • Page 20 6. Slide the rear cover to expose the electronics tray. Figure 12. Controller Installation 7. Plug the controller connector into the electronics tray. See figure 6. (Underside of Armrest) 8. Secure the controller cable to the armrest receiver with one or more wire ties. www.pridemobility.com Jazzy 1122...

  • Page 21: Comfort Adjustments

    10. Move the seat towers up or down to the desired height. 11. Reinstall the ball detent pin into each seat tower. 12. Reinstall the shroud. 13. Reinstall the trapeze bars and secure with the quick- Figure 14. Seat Height Adjustment release pins. 14. Reinstall the seat. Jazzy 1122 www.pridemobility.com...
  • Page 22 If your power chair is equipped with an optional deluxe high-back seat, you can adjust the headrest height. To adjust the headrest height: 1. Push in the headrest release button. 2. Move the headrest up or down to the desired position. www.pridemobility.com Jazzy 1122...
  • Page 23 4. Turn the adjustment screw clockwise to raise the front of the armrest, or turn the adjustment screw counter- clockwise to lower the front of the armrest. 5. Tighten the jam nut to lock the adjustment screw into place. Jazzy 1122 www.pridemobility.com...
  • Page 24 1. Remove the two screws from the side of each leg rest exten- sion. See figure 19. 2. Slide the leg rest in or out to the desired length. Figure 19. Swing-Away Footrests 3. Reinstall the two screws on each leg rest extension. www.pridemobility.com Jazzy 1122...
  • Page 25 Figure 21. Power Seat Switch By raising your seat, you are closer to the eye level of standing persons. This provides better interaction. For all the benefits the power elevating seat can pro- vide you, there are limitations. Jazzy 1122 www.pridemobility.com...
  • Page 26 3. Push the friction lock lever forward to lock the seat in place. WARNING! Prevent personal injury! Do not attempt to drive the power chair with the seat facing to the side. Always return the seat to the forward facing position before operating the power chair. www.pridemobility.com Jazzy 1122...
  • Page 27 Failure to do so may result in personal injury. PROHIBITED! Do not remove the anti-tip wheels from your power chair Jazzy 1122 www.pridemobility.com...
  • Page 28 2. Make sure your power chair is not in freewheel mode. See III. “Your Power Chair.” 3. Locate the ball detent pin at the base of the footrest bracket and remove. See figure 17. 4. Lift the foot frame straight up approximately 2 inches and pull toward you. www.pridemobility.com Jazzy 1122...
  • Page 29 Unless the joystick is damaged, this action should stop your power chair. Keypad The keypad is located in front of the joystick. It contains keys necessary to operate your power chair. See figure 27. Jazzy 1122 www.pridemobility.com...
  • Page 30 If your power chair was programmed with a drive profile, contact your authorized Pride Provider for more information. NOTE: We recommend that the first few times you operate your power chair, you use the lowest speed setting until you become familiar with your new power chair. www.pridemobility.com Jazzy 1122...
  • Page 31 VSI when the battery charger is on. The charger inhibit connector is coded with colored dots. The dots are positioned so that you align the flat side of the male connector with the flat side of the female connector before making the connection. Jazzy 1122 www.pridemobility.com...
  • Page 32 The parking brakes have a bad connection. Check the parking brake and motor connections. Make sure the controller connections are secure. An excessive voltage has been applied to the controller. This is usually caused by a poor battery connection. Check the battery connections. www.pridemobility.com Jazzy 1122...
  • Page 33 When you release the joystick and allow it to return to the neutral position, you engage the electromagnetic brakes. This causes your power chair to decelerate and come to a complete stop. Jazzy 1122 www.pridemobility.com...
  • Page 34 The right/left turn indicator keys toggle either the left or right turn indicators. Press once to turn on and press again to turn off. You can also turn off the selected indicator by pressing the opposite indicator key or the hazard key. Light Key The light key turns headlights/taillights on and off independent of other indicators. www.pridemobility.com Jazzy 1122...
  • Page 35 The chair will resume operation at the selected speed. NOTE: We recommend that the first few times you operate your power chair, you have your speed on the slowest setting until you become familiar with your new power chair. Jazzy 1122 www.pridemobility.com...
  • Page 36 For every degree above 122° F, the voltage is reduced by 5 volts. This reduces your power chair’s speed and allows the electrical components to cool down. When the temperature returns to a safe level, your power chair resumes its normal speed. www.pridemobility.com Jazzy 1122...
  • Page 37 Check connections. Right Motor Wiring Fault Check right motor wiring. Right Motor Disconnected Check right motor wiring. Left Motor Wiring Fault Check left motor wiring. Left Motor Disconnected Check left motor wiring. Low Battery Voltage Check batteries/battery wiring. Jazzy 1122 www.pridemobility.com...
  • Page 38 You can also use the joystick control power actuators. WARNING! If your power chair begins to move in an unexpected manner, immediately release the joystick. Unless the joystick is damaged, this action should stop your power chair. www.pridemobility.com Jazzy 1122...
  • Page 39 This means that it is still locked. 3. Hold the magnetic key on or near the key symbol again to unlock the system. When the key symbol stops flashing, you may turn on the power chair. Jazzy 1122 www.pridemobility.com...
  • Page 40 Of Neutral At Power Up.” Horn Key The horn key activates the horn. Battery Saver Feature When the battery capacity drops to below 21V (typically two lights), the controller will reduce power chair performance to conserve battery power. www.pridemobility.com Jazzy 1122...
  • Page 41 The controller must be turned off and then on again even if the source of the fault is removed. If you cannot resolve the problem, contact your authorized Pride Provider. Jazzy 1122 www.pridemobility.com...
  • Page 42 Contact your authorized Pride Provider if damage is found. WARNING! Prevent injury and/or equipment damage! Do not attempt to open the battery charger case. If the battery charger does not appear to be working correctly, contact your authorized Pride Provider. www.pridemobility.com Jazzy 1122...
  • Page 43 The green light indicates that the batteries are fully charged. If it is not a Pride off-board charger, then follow the instructions supplied by the manufacturer. 5. When the batteries are fully charged, disconnect the charger from the electrical outlet, then from the controller. Jazzy 1122 www.pridemobility.com...
  • Page 44 If you use your power chair infrequently (once a week or less), you should charge the batteries at least once per week for 12 to 14 hours. NOTE : Keep your batteries fully charged and avoid deeply discharging your batteries. Do not charge the batteries for more than 24 hours at a charging cycle. www.pridemobility.com Jazzy 1122...
  • Page 45 A fully charged, deep-cycle battery provides reliable performance and extended battery life. Keep your power chair’s batteries fully charged whenever possible. Batteries that are regularly and deeply discharged, infrequently charged, or stored without a full charge may be permanently damaged, causing unreliable power chair operation and limited battery life. Jazzy 1122 www.pridemobility.com...
  • Page 46 What about shipping? If you wish to use a freight company to ship your power chair to your final destination, repack your power chair in the original shipping container and ship the batteries in separate boxes. www.pridemobility.com Jazzy 1122...

  • Page 47: Care And Maintenance

    M A I N T E N A N C E CARE AND MAINTENANCE Your Jazzy 1122 is a sophisticated power chair. Like any motorized vehicle, it requires routine maintenance checks. You can perform some of these checks, but others require assistance from an authorized Pride Provider. Preven- tive maintenance is very important.
  • Page 48 ! Keep your power chair clean and free of foreign material, such as mud, dirt, hair, food, drink, etc. Yearly Checks Take your power chair to an authorized Pride Provider for yearly maintenance. This helps ensure that your power chair is functioning properly and helps prevent future complications. www.pridemobility.com Jazzy 1122...
  • Page 49 WARNING! Completely deflate pneumatic tires before attempting repair. TIRE TUBE DRIVE WHEEL SCREWS REAR RIM HALF FRONT RIM HALF DRIVE WHEEL WASHER Figure 32. Jazzy 1122 Drive Wheel Figure 33. Jazzy 1122 Drive Wheel Disassembled Jazzy 1122 www.pridemobility.com...
  • Page 50 (black) terminal. Install the battery in the rear of your power chair’s battery tray with the battery’s terminals facing inward, toward the center of the power chair. Plug the wiring harness into a quick disconnect. www.pridemobility.com Jazzy 1122...
  • Page 51 Disconnect both batteries before load testing and follow the directions that come with the load tester. If either one of the batteries fails the load test, replace both of them. If your power chair still does not power up, contact your authorized Pride Provider. Jazzy 1122 www.pridemobility.com...
  • Page 52 Pride to be defective in material and/or workmanship: ! Bearings and bushings ! Plastic components, except body The battery is covered by a separate six-month warranty, provided by the battery manufacturer. The batteries are not warranted by Pride. www.pridemobility.com Jazzy 1122...
  • Page 53 Circumstances beyond the control of Pride Labor, service calls, shipping, and other charges incurred for repair of the product, unless specifically autho- rized, IN ADVANCE, by Pride Mobility Products Corporation Repairs and/or modifications made to any part without specific consent from Pride...
  • Page 54 N O T E S www.pridemobility.com Jazzy 1122...
  • Page 55 Quality Control - Jazzy 1122 Thank you for making the Jazzy 1122 your choice in power chairs. The following checkmarks indicate that we have thoroughly inspected and test driven your power chair. Inclusion of all Parts Joystick Serial Number Controller Serial Number...
