When climbing an incline, try to keep your Scooter moving. If you must stop, start up again slowly, and
then accelerate cautiously. When driving down an incline, do so by setting the speed adjustment dial to the
slowest setting and driving in the forward direction only. If your Scooter starts to move down the incline
faster than you anticipated or desired, allow it to come to a complete stop by releasing the throttle control
lever. Then push the throttle control lever forward slightly to ensure a safely controlled descent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your Scooter straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the Scooter in manual freewheel
mode while seated on it or standing next to it.
In compliance with the Americans with Disabilities Act of 1990, all handicap public access ramps in the
United States are required to have a maximum slope of five degrees. Therefore, Pride recommends that the
maximum degree of an incline you attempt to safely ascend or descend on your Scooter does not exceed
those shown in figures 1 and 2.
These tests were conducted with the Legend’s seat in the highest position and adjusted backward on the
seat base to its farthest rearward position. Use this information as a guideline. Your Legend’s ability to
travel up inclines is affected by your weight, your Scooter’s speed, your angle of approach to the incline,
and your Scooter setup.
FIGURE 1. MAXIMUM RECOMMENDED INCLINE ANGLE FOR THE 3-WHEEL LEGEND
FIGURE 2. MAXIMUM RECOMMENDED INCLINE ANGLE FOR THE 4-WHEEL LEGEND
WARNING! Any attempt to climb or descend a slope steeper than shown in figures 1 and 2 may
put your Scooter in an unstable position and cause it to tip, resulting in personal injury.
8
I I . S A F E T Y
150 lbs. 200-250 lbs. 300 lbs.
7˚
CELEBRITY 3
150 lbs. 200 lbs.
8˚ 7˚
CELEBRITY 4
6˚
5˚
250 lbs. 300 lbs.
6˚ 5˚
Legend
