  • Page 1 ULTRA X...
  • Page 2 Any changes to our products may cause slight variations between the illustrations and explanations in this manual and the product you have purchased. The latest/current version of this manual is available on our website. Copyright © 2011 Pride Mobility Products Corp. INFMANU3234/Rev D/September 2011...

  • Page 3: Table Of Contents

    INTRODUCTION ...4 SAFETY ...5 III. YOUR TRAVEL SCOOTER ...19 IV. BATTERIES AND CHARGING ...23 OPERATION ...28 VI. COMFORT ADJUSTMENTS ...30 VII. DISASSEMBLY AND ASSEMBLY ...32 VIII. BASIC TROUBLESHOOTING ...34 IX. CARE AND MAINTENANCE ...36 WARRANTY ...39 Go-Go Ultra X C O N T E N T S www.pridemobility.com...

  • Page 4: Introduction

    I . I N T R O D U C T I O N SAFETY WELCOME to Pride Mobility Products (Pride). The product you have purchased combines state-of the- art components with safety, comfort, and styling in mind. We are confident the design features will provide you with the conveniences you expect during your daily activities.
  • Page 5 PRODUCT SAFETY SYMBOLS The symbols below are used on the Travel Scooter to identify warnings, mandatory actions, and prohibited actions. It is very important for you to read and understand them completely. Read and follow the information in the owner’s manual. Pinch/Crush points created during assembly.

  • Page 6: Ii. Safety

    Use only AGM or Gel-Cell batteries to reduce the risk of leakage or explosive conditions. Keep tools and other metal objects away from battery terminals. Contact with tools can cause electrical shock. Do not remove anti-tip wheels. Avoid exposure to rain, snow, ice, salt, or standing water whenever possible. Maintain and store in a clean and dry condition.
  • Page 7 Battery posts, terminals, and related accessories contain lead and lead compounds. Wear goggles and gloves when handling batteries and wash hands after handling. Do not place your Travel Scooter in freewheel mode while on an incline or decline. Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and new batteries.
  • Page 8 I I . S A F E T Y Travel Scooter does not conform to ISO 7176-19 for transport of an occupied Travel Scooter in a motor vehicle. Contains sealed, non-spillable batteries that meet DOT CRF 173.159 (d), IATA packing instructions 806, IATA provision A67 for safe transportation. Manufactured in.
  • Page 9 GENERAL MANDATORY! Do not operate your new Travel Scooter for the first time without completely reading and understanding this owner’s manual. Your Travel Scooter is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an extensive variety of products to best fit the individual needs of the Travel Scooter user. Please be aware that the final selection and purchasing decision regarding the type of Travel Scooter to be used is the responsibility of the Travel Scooter user who is capable of making such a decision and his/her healthcare professional (i.e., medical doctor, physical therapist, etc.).
  • Page 10 Perform the following inspections prior to using your Travel Scooter: Check for proper tire inflation. Maintain but do not exceed the psi/bar/kPa air pressure rating indicated on each tire if equiped with pneumatic tires. Check all electrical connections. Make sure they are tight and not corroded. Check all harness connections.
  • Page 11 When climbing an incline, try to keep your Travel Scooter moving. If you must stop, start up again slowly, and then accelerate cautiously. When driving down an incline, do so by setting the speed adjustment dial to the slowest setting and driving in the forward direction only. If your Travel Scooter starts to move down the incline faster than you anticipated or desired, allow it to come to a complete stop by releasing the throttle control lever.
  • Page 12 When you approach an incline, it is best to lean forward. See figures 2 and 2A. This shifts the center of gravity of you and your Travel Scooter toward the front of the Travel Scooter for improved stability. NOTE: When negotiating ramps, if the throttle control lever is released while moving forward, the powered Travel Scooter may “roll back”...
  • Page 13 OUTDOOR DRIVING SURFACES Your Travel Scooter is designed to provide optimum stability under normal driving conditions—dry, level surfaces composed of concrete, blacktop, or asphalt. However, Pride recognizes that there will be times when you will encounter other surface types. For this reason, your Travel Scooter is designed to perform admirably on packed soil, grass, and gravel.
  • Page 14 INCLEMENT WEATHER PRECAUTIONS Exposure of your Travel Scooter to inclement weather conditions should be avoided whenever possible. If suddenly caught up in rain, snow, severe cold or heat while operating your Travel Scooter, proceed to shelter at the earliest opportunity. Thoroughly dry your Travel Scooter before storing, charging, or operating your Travel Scooter.
  • Page 15 ELEVATORS Modern elevators have a door edge safety mechanism that, when pushed, reopens the door(s). If you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge or allow the rubber door edge to contact the Travel Scooter and the door will reopen. Use care that pocketbooks, packages, or Travel Scooter accessories do not become caught in elevator doors.
  • Page 16 MOTOR VEHICLE TRANSPORT Pride recommends that you do not remain seated in your Travel Scooter while traveling in a motor vehicle. The Travel Scooter should be stowed in the trunk of a car or in the back of a truck or van with the batteries removed and/or properly secured.
  • Page 17 POSITIONING BELTS Your authorized Pride Provider, therapist(s), and other healthcare professionals are responsible for determining your requirement for a positioning belt in order to operate your Travel Scooter safely. WARNING! If you require a positioning belt to safely operate your Travel Scooter, make sure it is fastened securely.
  • Page 18 ELECTROMAGNETIC AND RADIO FREQUENCY INTERFERENCE (EMI/RFI) WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can have an adverse effect on the performance of electrically-powered mobility vehicles. Electromagnetic and Radio Frequency Interference can come from sources such as cellular phones, mobile two-way radios (such as walkie-talkies), radio stations, TV stations, amateur radio (HAM) transmitters, wireless computer links, microwave signals, paging transmitters and medium-range mobile transceivers used by emergency vehicles.
  • Page 19 I I I . Y O U R T R A V E L S C O O T E R TILLER CONSOLE The tiller console houses all controls needed to drive your Travel Scooter, including the key switch, throttle control lever, horn button, speed adjustment dial, and the battery condition meter. See figure 5. PROHIBITED! Do not expose the tiller console to moisture.
  • Page 20 I I I . Y O U R T R A V E L S C O O T E R Speed Adjustment Dial This dial allows you to preselect and limit your Travel Scooter’s top speed. The image of the tortoise represents the slowest speed setting.
  • Page 21 I I I . Y O U R T R A V E L S C O O T E R BATTERY PACK Your Travel Scooter is equipped with an innovative, easy to remove battery pack. A handle on the top of the battery pack makes it easy to lift the pack off of the Travel Scooter with one hand.
  • Page 22 I I I . Y O U R T R A V E L S C O O T E R OFF-BOARD BATTERY CHARGER The off-board battery charger, when plugged into the charger power lead receptacle (located on the battery pack) and a standard electrical outlet, charges the Travel Scooter’s batteries.

  • Page 23: Batteries And Charging

    I V . B A T T E R I E S A N D C H A R G I N G Your Travel Scooter requires two long-lasting, 12-volt, deep-cycle batteries that are sealed and maintenance free. They are recharged by the supplied off-board charging system. Charge your Travel Scooter’s batteries for 8 to 14 hours prior to using it for the first time.

  • Page 24: Iv. Batteries And Charging

    I V . B A T T E R I E S A N D C H A R G I N G Follow these easy steps to charge your batteries safely: 1. Position your Travel Scooter or battery pack close to a standard electrical outlet.
  • Page 25 I V . B A T T E R I E S A N D C H A R G I N G How often must I charge the batteries? Two major factors must be considered when deciding how often to charge your Travel Scooter’s batteries: All day use on a daily basis.
  • Page 26 I V . B A T T E R I E S A N D C H A R G I N G What type and size of battery should I use? Your Travel Scooter requires two deep cycle batteries. We recommend only sealed, maintenance-free types such as AGM or Gel-Cell.
  • Page 27 I V . B A T T E R I E S A N D C H A R G I N G WARNING! Do not pull on electrical harness wires directly to detach them from the Travel Scooter. Always grasp the connector itself when disconnecting the harness to prevent wire damage.

  • Page 28: Operation

    BEFORE GETTING ONTO YOUR TRAVEL SCOOTER Have you fully charged the batteries? See IV. “Batteries and Charging.” Is the manual freewheel lever in the drive (backward) position? Never leave the manual freewheel lever in the forward position unless you are manually pushing your Travel Scooter. Ensure the tiller lock knob is in the unlocked position.

  • Page 29: V. Operation

    V . O P E R A T I O N NOTE: Your Travel Scooter’s reverse speed is slower than that of the forward speed you preset with the speed adjustment dial. GETTING OFF OF YOUR TRAVEL SCOOTER 1. Bring your Travel Scooter to a complete stop. 2.
  • Page 30 V I . C O M F O R T A D J U S T M E N T S TILLER ANGLE ADJUSTMENT WARNING! Remove the key from the key switch before adjusting the tiller or the seat. Never attempt to adjust the tiller or the seat while the Travel Scooter is in motion.

  • Page 31: Vi. Comfort Adjustments

    V I . C O M F O R T A D J U S T M E N T S POSITIONING BELT (OPTIONAL) Your scooter seat may be equipped with an auto-type positioning belt that can be adjusted for operator comfort.
  • Page 32 V I I . D I S A S S E M B L Y A N D A S S E M B L Y DISASSEMBLY You can disassemble the Travel Scooter into five pieces: the seat, the front section, the rear section, the basket, and the battery pack.

  • Page 33: Vii. Disassembly And Assembly

    V I I . D I S A S S E M B L Y A N D A S S E M B L Y ASSEMBLY NOTE: Before attempting assembly, tilt the rear half of the Travel Scooter slightly back on the anti-tip wheels as show in figure 20.
  • Page 34 V I I I . B A S I C T R O U B L E S H O O T I N G Any electromechanical device occasionally requires some troubleshooting. However, most of the problems that may arise can usually be solved with a bit of thought and common sense. Many of these problems occur because the batteries are not fully charged or because the batteries are worn down and can no longer hold a charge.

  • Page 35: Viii. Basic Troubleshooting

    V I I I . B A S I C T R O U B L E S H O O T I N G To check a fuse: 1. Remove the fuse by pulling it out of its slot. 2.

  • Page 36: Care And Maintenance

    I X . C A R E A N D M A I N T E N A N C E Your Travel Scooter requires a minimal amount of care and maintenance. If you do not feel confident in your ability to perform the maintenance listed below, you may schedule inspection and maintenance at your authorized Pride Provider.
  • Page 37 I X . C A R E A N D M A I N T E N A N C E EXTERIOR SURFACES Bumpers, tires, and trim can benefit from an occasional application of a rubber or vinyl conditioner. WARNING! Do not use a rubber or vinyl conditioner on the Travel Scooter’s vinyl seat or tire tread.
  • Page 38 I X . C A R E A N D M A I N T E N A N C E NYLON LOCK NUT REPLACEMENT Any nylon insert lock nut removed during the periodic maintenance, assembly, or disassembly of the Travel Scooter must be replaced with a new nut.

  • Page 39: Warranty

    Circumstances beyond the control of Pride Labor, service calls, shipping, and other charges incurred for repair of the product, unless specifically authorized, IN ADVANCE, by Pride Mobility Products Repairs and/or modifications made to any part of the Travel Scooter without specific and prior consent...

  • Page 40: X. Warranty

    Exclusions also include components with damage caused by: Contamination Abuse, misuse, accident, or negligence Battery fluid spillage or leakage Commercial use or use other than normal Improper operation, maintenance, or storage Batteries not properly maintained by recommended charging and storage procedures There is no other express warranty.
  • Page 41 N O T E S Go-Go Ultra X www.pridemobility.com...
  • Page 42 N O T E S www.pridemobility.com Go-Go Ultra X...
  • Page 43 *INFMANU3234*...
