SD8364E/ -M
User's Manual
1080P • 30x Zoom • NEMA 4x • IP66 •
Extreme Weatherproof
Speed Dome
Network Camera
Rev. 1.0

Advertisement

Table of Contents
loading

Related Manuals for Vivotek SD8364E/ -M

Summary of Contents for Vivotek SD8364E/ -M

  • Page 1 SD8364E/ -M Speed Dome Network Camera User’s Manual 1080P • 30x Zoom • NEMA 4x • IP66 • Extreme Weatherproof Rev. 1.0...

  • Page 2: Table Of Contents

    Security > Access List .........................94 PTZ > PTZ settings ..........................99 Event > Event settings ........................104 Applications > Motion detection......................118 Applications > DI and DO ........................121 Applications > Audio detection ......................122 Applications > VADP (VIVOTEK Application Development Platform) ..........124 2 - User's Manual...
  • Page 3 VIVOTEK Recording > Recording settings ........................126 Local storage > SD card management ....................... 131 Local storage > Content management ....................... 132 Appendix  134 URL Commands for the Network Camera ......................134 Technical Specifications ............................. 218 Technology License Notice ..........................219 Electromagnetic Compatibility (EMC) .........................

  • Page 4: Revision History

    VIVOTEK Overview VIVOTEK SD8364E is part of the SUPREME series product line offering 1080p Full HD resolution with superb image quality. Adopting a 30x optical zoom lens, the SD8364E is able to capture details at top-notch quality. The IP66- and NEMA 4X-rated housing protects the camera body against rain, dust and corrosion within a wide temperature range between -40°C to 55°C.

  • Page 5: Read Before Use

    Camera section serves as a helpful reference to customizing existing homepages or integrating with the current web server. Package Contents ■ SD8364E/ -M (-M specifies the camera that comes with a dehumidifier unit) ■ Wall Mount Bracket / Screws ■ Waterproof Connectors / Terminal Blocks / Ethernet Cable / Ground Wire ■...

  • Page 6: Physical Description

    VIVOTEK Physical Description Outer View Reset Button Network LED Status LED Lens This drawing shows a camera with its dome cover removed. Inner View Camera Body Board-to-board Connector SD/SDHC/SDXC Card Slot The card slot is accessed by removing the top section using the T25 stardriver.
  • Page 7 VIVOTEK Interface Section Ethernet 10/100 RJ45 Plug General I/O Terminal Block AC24V DI GND AC24V Reserved Spring Contacts for Dehumidifier MIC IN Line OUT Audio GND RS485- RS485+ DO+(12V) Status LED Item LED status Description Steady red Power on and system booting...
  • Page 8 VIVOTEK DI/DO Diagram Please refer to the following illustration for the connection method. Please note that the maximum load on the DO pins is 50mA. Camera Power (DO+ 12V) Camera Power Switch Switch Input Input Max. Output Output BJT transistor...

  • Page 9: Installation - For The Configuration W/ Extended Cables 9

    VIVOTEK Installation - for the Configuration w/ Ex- tended Cables Hardware Installation IMPORTANT: The SD8364E series comes with or without the extended Ethernet and IO combo cables. Different configurations come with different ordering numbers. Therefore, the installation procedure can differ, and the procedures are separately described as follows.
  • Page 10 VIVOTEK Install the Wall-mount Bracket 1. The camera weighs 3.66kg. Select a rigid mounting location to prevent vibration to the camera. Attach the alignment sticker to the wall. 2. Drill 4 pilot holes (10mm in diameter and 4cm deep) into the wall, and then hammer in threaded anchors.
  • Page 11 VIVOTEK Cabling Connections & Attach the Top Section 1. Hold your top section with one hand and pass all cables through the wallmount bracket. 2. Secure the top section to the wall mount bracket. Note that you should turn and orient the top section so that the C mark is facing a direction 15 degrees off the center line.

  • Page 12: Mounting The Camera

    VIVOTEK 3. Connect cables and use sealants and putties to make sure cable joints and the cabling hole are waterproof. 4. Secure the included ground wire to the dome cap, pass it through the mount bracket, and con- nect the other end to a grounded conduit later.

  • Page 13: Hardware Installation

    VIVOTEK Installation - for the Configuration w/o Ex- tended Cables Hardware Installation 1. Connecting RJ45 Ethernet Cable RJ45 Cable Dimension (unit: mm) Use CAT5e cables only. Components of the Waterproof Connector Sealing Nut (A) Seal (B) Screw Nut (C) Housing (D)
  • Page 14 VIVOTEK 2. Connecting Power and I/O Wires If you need to connect I/O wires and 24V power, disassemble the top section of the camera. It is highly recommended to complete the following before you can mount the speed dome camera at the installation site: Skip this section and move to Section 3-3 if you connect the Ethernet cable only.
  • Page 15 1. Use a small-size flat-blade screwdriver to secure IO Wire range: 13~16AWG wires to the included terminal blocks. You may also Strip length: 6~7mm purchase an IO combo cable from VIVOTEK. Screw: M2 AC24V DI GND AC24V DI4 Reserved DI3...
  • Page 16 VIVOTEK 2. Feed the Ethernet cable and IO wires through the mounting bracket, the openings on the dome cap, and to the interface section. Attach the rubber seal plug to dome cap for water proofing. 3. Secure the included ground wire to the dome cap, pass it through the mount bracket, and con- nect the other end to a grounded conduit later.
  • Page 17 VIVOTEK 1-3. Connect with the Mount Bracket Combine the components of the top section. 1. Press the seal ring into the groove on the interface section. Use the black machine screws (M4x8) to attach the interface section to the dome cap. Note that you should orient and align the spring contacts with the dehumidifier unit on the dome cap.
  • Page 18 VIVOTEK 2. Mounting the Network Camera Shown below are the dimensions of the wall mount bracket and its mounting holes: You can find the installation instructions on VIVOTEK’s website for other options such as parapet mount: http://www.vivotek.com/web/ product/accessories.aspx 18 - User's Manual...
  • Page 19 VIVOTEK NOTE: Before mounting the camera, install an SD card if you prefer recording to local storage. 1. Mounting with Ethernet Connection Only 1. The camera weighs 3.66kg. Select a rigid mounting location to prevent vibration to the camera. Attach the alignment sticker to the wall.
  • Page 20 VIVOTEK 2. Mounting with Ethernet & I/O Wires 1. The camera weighs 3.66kg. Select a rigid mounting location to prevent vibration to the camera. Attach the alignment sticker to the wall. 2. Drill 4 pilot holes (10mm in diameter and 4cm deep) into the wall, and then hammer in threaded anchors.

  • Page 21: Network Deployment

    VIVOTEK Network Deployment Setting up the Network Camera over the Internet There are several ways to set up the Network Camera over the Internet. The first way is to set up the Network Camera behind a router. The second way is to utilize a static...
  • Page 22 For more information with network configuration options (such as that of streaming ports), please refer to Configuration > Network Settings. VIVOTEK also provides the automatic port forwarding feature as an NAT traversal function with the precondition that your router must support the UPnP port forwarding feature.
  • Page 23 VIVOTEK Internet connection with static IP Choose this connection type if you are required to use a static IP for the Network Camera. Please refer to LAN on page 68 for details. Internet connection via PPPoE (Point-to-Point over Ethernet) Choose this connection type if you are connected to the Internet via a DSL Line. Please refer to PPPoE on page 69 for details.

  • Page 24: Software Installation

    After your network environment is analyzed, please click Next to continue the program. 3. The program will search for all VIVOTEK network devices on the same LAN. 4. After a brief search, the main installer window will prompt. Double-click on the MAC and model name which matches the product label on your device to connect to the Network Camera via a web browser.

  • Page 25: Ready To Use

    VIVOTEK Ready to Use 1. A browser session with the Network Camera should prompt as shown below. 2. You should be able to see live video from your camera. You may also install the 32-channel recording software from the software CD in a deployment consisting of multiple cameras. For its installation details, please refer to its related documents.

  • Page 26: Accessing The Network Camera 26

    3. Live video will display in your web browser. 4. If it is the first time installing the VIVOTEK network camera, an information bar will pop up as shown below. Follow the instructions to install the required plug-in on your computer.
  • Page 27 VIVOTEK ► By default, the Network Camera is not password-protected. To prevent unauthorized access, it is highly recommended to set a password for the Network Camera. For more information about how to enable password protection, please refer to Security on page 86.

  • Page 28: Using Rtsp Players

    VIVOTEK Using RTSP Players To view the H.264/MPEG-4 streaming media using RTSP players, you can use one of the following players that support RTSP streaming. Quick Time Player VLC Media Player VLC media player 1. Launch the RTSP player. 2. Choose File > Open URL. An URL dialog box will pop up.

  • Page 29: Using 3Gpp-Compatible Mobile Devices

    VIVOTEK Using 3GPP-compatible Mobile Devices To view the streaming media through 3GPP-compatible mobile devices, make sure the Network Camera can be accessed over the Internet. For more information on how to set up the Network Camera over the Internet, please refer to Setup the Network Camera over the Internet on page To utilize this feature, please check the following settings on your Network Camera: 1.

  • Page 30: Using Vivotek Recording Software

    VIVOTEK Using VIVOTEK Recording Software The product software CD also contains recording software, allowing simultaneous monitoring and video recording for multiple Network Cameras. Please install the recording software; then launch the program to add the Network Camera to the Channel list. For detailed information about how to use the recording software, please refer to the user’s manual of the software or...

  • Page 31: Main Page 31

    VIVOTEK Main Page This chapter explains the layout of the main page. It is composed of the following sections: VIVOTEK INC. Logo, Host Name, Camera Control Area, Configuration Area, and Live Video Window. VIVOTEK INC. Resize Buttons Host Name Logo...
  • Page 32 VIVOTEK VIVOTEK INC. Logo Click this logo to visit the VIVOTEK website. Host Name The host name can be customized to fit your needs. For more information, please refer to System on page 43. Camera Control Area Video Stream: This Network Camera supports multiple streams (stream 1 ~ 4) simultaneously. You can select either one for live viewing.
  • Page 33 VIVOTEK Pan /Tilt /Zoom /Focus speed: Adjust the speed of Pan/ Tilt/ Zoom/ Focus: Pan speed Tilt speed Zoom speed Focus speed Slower Faster Note that mouse screen control is also supported. You can refer to page 99 for related information.
  • Page 34 VIVOTEK Resize Buttons Click the Auto button, the video cell will resize automatically to fit the monitor. Click 100% is to display the original homepage size. Click 50% is to resize the homepage to 50% of its original size. Click 25% is to resize the homepage to 25% of its original size.
  • Page 35 VIVOTEK Snapshot: Click this button to capture and save still images. The captured images will be displayed in a pop-up window. Right-click the image and choose Save Picture As to save it in JPEG (*.jpg) or BMP (*.bmp) format. Digital Zoom: Click and uncheck “Disable digital zoom” to enable the zoom operation. The navigation screen indicates the part of the image being magnified.
  • Page 36 VIVOTEK ■ The following window is displayed when the video mode is set to MJPEG: Video Title Time Video (HTTP-V) 2011/03/10 17:08:56 Title and Time Video 17:08:56 2011/03/10 Video Control Buttons Video Title: The video title can be configured. For more information, please refer to Media > Image on page 53.

  • Page 37: Client Settings 37

    VIVOTEK Client Settings This chapter explains how to select the stream transmission mode and saving options on the local computer. When completed with the settings on this page, click Save on the page bottom to enable the settings. H.264/MPEG-4 Media Options H.264/MPEG-4 Media Options...

  • Page 38: Mp4 Saving Options

    VIVOTEK MP4 Saving Options Users can record live video as they are watching it by clicking the button - Start MP4 Recording - on the main page. Here, you can specify the storage destination and file name. Folder: Specify a storage destination for the recorded video files.

  • Page 39: Joystick Settings

    VIVOTEK Joystick Settings Enable Joystick Connect to the USB plug of the joystick to a USB port on your management computer. Once a USB joystick is connected, the related joystick configuration will be available on the Client settings window. The joystick should work properly without installing any other driver or software.
  • Page 40 VIVOTEK Buttons Configuration In the Joystick Settings window, you can use the combinations of pull-down menus, Actions and Button number, to assign joystick buttons with different functions. The number of buttons may differ from the joystick you attached. Please follow the steps below to configure your joystick buttons: 1.
  • Page 41 VIVOTEK NOTE: • If you want to assign Preset actions to your joystick, the PTZ preset locations should be configured in advance. • If your joystick is not working properly, it may need to be calibrated. Click the Calibrate button to open the Game Controllers window located in Microsoft Windows control panel and follow the instructions for trouble shooting.

  • Page 42: Configuration 42

    VIVOTEK Configuration Click Configuration on the main page to enter the camera setting pages. Note that only Administrators can access the configuration page. Please refer to page 86 Security > User Account for how to configure access rights for different users.

  • Page 43: System > General Settings

    VIVOTEK System > General settings This section explains how to configure the basic settings for the Network Camera, such as the host name and system time. It is composed of the following two columns: System and System Time. System Host name: Enter a desired name for the Network Camera. The text will be displayed at the top of the main page.

  • Page 44: System > Homepage Layout

    Theme Options (the second tab on this page). The settings will be displayed automatically in this Preview field. The following shows the homepage using the default settings: ■ Hide Powered by VIVOTEK: If you check this item, such wording will be removed from the homepage. Logo graph Here you can change the logo at the top of your homepage.
  • Page 45 VIVOTEK Theme Options Here you can change the color of your homepage layout. There are three types of preset patterns for you to choose from. The new layout will simultaneously appear in the Preview filed. Click Save to enable the settings.
  • Page 46 6. Click Save to enable the settings. Below are the options for system integrators or VARs. You can use the checkboxes to replace VIVOTEK’s company logo, the embedded website address or the slogan “Powered by VIVOTEK.“ When done, use the Save button to complete the configuration.

  • Page 47: System > Logs

    VIVOTEK System > Logs This section explains how to configure the Network Camera to send the system log to the remote server as backup. Log server settings Follow the steps below to set up the remote log: 1. Select Enable remote log.

  • Page 48: System > Parameters

    VIVOTEK Access log Access log displays the access time and IP address of all viewers (including operators and administrators) in a chronological order. The access log is stored in the Network Camera’s buffer area and will be overwritten when reaching a certain limit.

  • Page 49: System > Maintenance

    Note: Do not power off the Network Camera during the upgrade! Follow the steps below to upgrade the firmware: 1. Download the latest firmware file from the VIVOTEK website. The file is in .pkg file format. 2. Click Browse… and specify the firmware file.
  • Page 50 VIVOTEK General settings > Restore This feature allows you to restore the Network Camera’s factory defaults. Network: Select this option to retain the Network Type settings (please refer to Network Type on page 68). Daylight Saving Time: Select this option to retain the Daylight Saving Time settings (please refer to Import/Export files below on this page).
  • Page 51 VIVOTEK ® 3. Open and edit the file using Microsoft Notepad and locate your time zone in the strings; set the start and end time of DST. When completed, save the file. In the example below, DST begins each year at 2:00 a.m. on the second Sunday in March and ends at 2:00 a.m.
  • Page 52 VIVOTEK The following message is displayed when attempting to upload an incorrect file format. Export language file: Click to export language strings. VIVOTEK provides nine languages: English, Deutsch, Español, Français, Italiano, 日本語, Português, 簡体中文, and 繁體中文 . Update custom language file: Click Browse… and specify your own custom language file to upload.

  • Page 53: Media > Image

    VIVOTEK Media > Image This section explains how to configure the image settings of the Network Camera. It is composed of the following four columns: General settings, Picture settings, Exposure, and Privacy mask. General settings Video title Show_timestamp and video title in videos_and_snapshots: Enter a name that will be displayed on the title bar of the live video as the picture shown below.

  • Page 54: Image Settings

    VIVOTEK Image settings On this page, you can tune the White balance and Image adjustment settings. Sensor Setting 1: For normal situations Sensor Setting 2: For special situations White balance: Adjust the value for the best color temperature. ■ Select one of the white balance modes: 1.
  • Page 55 VIVOTEK Enable 3D Noise reduction ■ Check to enable noise reduction in order to reduce noises and flickers in image. This applies to the onboard 3D Noise Reduction feature. Use the pull-down menu to adjust the reduction strength. Note that applying this function to the video channel will consume system computing power.
  • Page 56 VIVOTEK Exposure control: ■ Exposure level: You can manually set the Exposure level, which ranges from -2.0 to +2.0 (dark to bright). You can also select other values from the Exposure mode menus and select a preferred scenario or manually configure the associated settings. You may prefer a shorter shutter time to better capture moving objects, while a faster shutter reduces light and needs to be compensated by electrical brightness gains.
  • Page 57 VIVOTEK NOTE: • When Iris Priority is selected for the Exposure mode, the tunable aperture size is related to zoom ratio. When using different zoom ratios, the range of aperture sizes can be different. When zoom ratio is 0x, the range of iris sizes is F1.6~F14. When zoom ratio is 20x, the iris size is F3.4. See below for the...
  • Page 58 VIVOTEK ■ Back light compensation: This option is only available when the Auto mode is selected for the Exposure setting. This option enables light compensation for images that are too dark to recognize; for example, for the dark side of objects that is posed against bright sunlight. This option is disabled if you enable the WDR function.
  • Page 59 VIVOTEK Day/Night Settings ■ Turn on external IR illuminator in night mode The camera’s digital output signal can be connected to external IR lights to turn it on when the camera detects low light conditions and enters the night mode.
  • Page 60 VIVOTEK Exposure Profile: (Only available when the IR cut filter is not set to the Auto mode) If you want to configure another sensor and exposure setting for an individual day/night/schedule mode, please click Profile to open the Profile of exposure settings page as shown below.
  • Page 61 VIVOTEK Privacy mask Click Privacy Mask to open the settings page. On this page, you can block out sensitive view areas to address privacy concerns. NOTE: 1. The navigation buttons here also support the continuous move. You can click and hold...
  • Page 62 VIVOTEK NOTE: • The camera supports "3D Privacy Mask." Privacy masks should stay at the same positions regardless of how the camera lens may move. • When the "Enabled privacy mask" checkbox is deselected, no privacy masks will appear on screen.

  • Page 63: Media > Video

    VIVOTEK Media > Video This Network Camera operates with either the Full HD mode or the 720P mode. When in the 720P resolution, the camera can deliver video streams at an exceptional 60fps frame rate. Stream settings This Network Camera supports multiple streams with frame sizes ranging from 176 x 144 to 1920 x 1080 pixels.
  • Page 64 VIVOTEK Click the stream item to display the detailed information. . This Network Camera offers real-time H.264, MPEG-4, and MJPEG compression standards (Multiple Codec) for real-time viewing. If the H.264 / MPEG-4 mode is selected, the video is streamed via RTSP protocol.
  • Page 65 VIVOTEK ■ Frame size You can set up different video resolution for different viewing devices. For example, set a smaller frame size and lower bit rate for remote viewing on mobile phones and a larger video size and a higher bit rate for live viewing on web browsers.

  • Page 66: Media > Audio

    VIVOTEK NOTE: ► Video quality and fixed quality refers to the compression rate, so a lower value will produce higher quality. ► Converting high-quality video may significantly increase the CPU loading, and you may encounter streaming disconnection or video loss while capturing a complicated scene. In the event of occurence, we suggest you customize a lower video resolution or reduce the frame rate to obtain smooth video.
  • Page 67 VIVOTEK IMPORTANT: The network camera does not come with embedded microphone. An external microphone will be necessary especially if you prefer the Audio Detection feature. By default, the Audio setting is muted, and you need to manually uncheck the Mute option.

  • Page 68: Network > General Settings

    Use fixed IP address: Select this option to manually assign a static IP address to the Network Camera. 1. You can make use of VIVOTEK Installation Wizard 2 on the software CD to easily set up the Network Camera on LAN. Please refer to Software Installation on page 24 for details.
  • Page 69 VIVOTEK Primary DNS: The primary domain name server that translates host names into IP addresses. Secondary DNS: Secondary domain name server that backs up the Primary DNS. Primary WINS server: The primary WINS server that maintains the database of computer names and IP addresses.
  • Page 70 VIVOTEK NOTE: ► If the default ports are already used by other devices connected to the same router, the Network Camera will select other ports for the Network Camera. ► If UPnP is not supported by your router, you will see the following message: Error: Router does not support UPnP port forwarding.
  • Page 71 VIVOTEK 4. In the Networking Services dialog box, select Universal Plug and Play and click OK. 5. Click Next in the following window. 6. Click Finish. UPnP is enabled. ► How does UPnP work? UPnP networking technology provides automatic IP configuration and dynamic discovery of devices added to a network.
  • Page 72 VIVOTEK Enable IPv6 Select this option and click Save to enable IPv6 settings. Please note that this only works if your network environment and hardware equipment support IPv6. The ® browser should be Microsoft Internet Explorer 6.5, Mozilla Firefox 3.0 or above.
  • Page 73 VIVOTEK Please follow the steps below to link to an IPv6 address: 1. Open your web browser. 2. Enter the link-global or link-local IPv6 address in the address bar of your web browser. 3. The format should be: http://[2001:0c08:2500:0002:0202:d1ff:fe04:65f4]/ IPv6 address 4.
  • Page 74 VIVOTEK Port HTTPS port: By default, the HTTPS port is set to 443. It can also be assigned to another port number between 1025 and 65535. Two way audio port: By default, the two way audio port is set to 5060. Also, it can also be assigned to another port number between 1025 and 65535.
  • Page 75 To stop talking, click again. FTP port: The FTP server allows the user to save recorded video clips. You can utilize VIVOTEK's Installation Wizard 2 to upgrade the firmware via FTP server. By default, the FTP port is set to 21. It also can be assigned to another port number between 1025 and 65535.

  • Page 76: Network > Streaming Protocols

    VIVOTEK Network > Streaming protocols HTTP streaming To utilize HTTP authentication, make sure that your have set a password for the Network Camera first; please refer to Security > User account on page 86 for details. Authentication: Depending on your network security requirements, the Network Camera provides two types of security settings for an HTTP transaction: basic and digest.
  • Page 77 VIVOTEK URL command -- http://<ip address>:<http port>/<access name for stream 1, 2, 3, 4, or 5> For example, when the Access name for stream 2 is set to video2.mjpg: 1. Launch the Mozilla Firefox browser. 2. Type the above URL command in the address bar. Press Enter.
  • Page 78 VIVOTEK Authentication: Depending on your network security requirements, the Network Camera provides three types of security settings for streaming via RTSP protocol: disable, basic, and digest. basic authentication is selected, the password is sent in plain text format, but there can be potential risks of it being intercepted.
  • Page 79 VIVOTEK Multicast settings for stream 1, 2, 3, and 4: Click the items to display the detailed configuration information. Select the Always multicast option to enable multicast for video streams. Unicast video transmission delivers a stream through point-to-point transmission; multicast, on the other hand, sends a stream to the multicast group address and allows multiple clients to acquire the stream at the same time by requesting a copy from the multicast group address.

  • Page 80: Network > Ddns

    IP address, to have a fixed host and domain name. Express link Express Link is a free service provided by VIVOTEK server, which allows users to register a domain name for a network device. One URL can only be mapped to one MAC address. This service will examine if the host name is valid and automatically open a port on your router.
  • Page 81 DDNS: Dynamic domain name service Enable DDNS: Select this option to enable the DDNS setting. Provider: Select a DDNS provider from the provider drop-down list. VIVOTEK offers Safe100.net, a free dynamic domain name service, to VIVOTEK customers. It is recommended that you register Safe100.net to access VIVOTEK’s Network Cameras from the Internet.
  • Page 82 4. Select Enable DDNS and click Save to enable the setting. ■ CustomSafe100 VIVOTEK offers documents to establish a CustomSafe100 DDNS server for distributors and system integrators. You can use CustomSafe100 to register a dynamic domain name if your distributor or system integrators offer such services.
  • Page 83 VIVOTEK Network > QoS (Quality of Service) Quality of Service refers to a resource reservation control mechanism, which guarantees a certain quality to different services on the network. Quality of service guarantees are important if the network capacity is insufficient, especially for real-time streaming multimedia applications. Quality can be defined as, for instance, a maintained level of bit rate, low latency, no packet dropping, etc.
  • Page 84 VIVOTEK QoS/DSCP (the DiffServ model) DSCP-ECN defines QoS at Layer 3 (Network Layer). The Differentiated Services (DiffServ) model is based on packet marking and router queuing disciplines. The marking is done by adding a field to the IP header, called the DSCP (Differentiated Services Codepoint). This is a 6-bit field that provides 64 different class IDs.

  • Page 85: Network > Snmp (Simple Network Management Protocol)

    VIVOTEK Network > SNMP (Simple Network Management Protocol) This section explains how to use the SNMP on the network camera. The Simple Network Management Protocol is an application layer protocol that facilitates the exchange of management information between network devices. It helps network administrators to remotely manage network devices and find, solve network problems with ease.

  • Page 86: Security > User Account

    VIVOTEK Security > User Account This section explains how to enable password protection and create multiple accounts. Root Password The administrator account name is “root”, which is permanent and can not be deleted. If you want to add more accounts in the Manage User column, please apply the password for the “root” account first.

  • Page 87: Security > Https (Hypertext Transfer Protocol Over Ssl)

    VIVOTEK Security > HTTPS (Hypertext Transfer Protocol over SSL) This section explains how to enable authentication and encrypted communication over SSL (Secure Socket Layer). It helps protect streaming data transmission over the Internet on higher security level. Create and Install Certificate Method Before using HTTPS for communication with the Network Camera, a Certificate must be created first.
  • Page 88 VIVOTEK 5. Click Save to preserve your configuration, and your current session with the camera will change to the encrypted connection. 6. If your web session does not automatically change to an encrypted HTTPS session, click Home to re- turn to the main page. Change the URL address from “http://” to “https://“ in the address bar and press Enter on your keyboard.
  • Page 89 VIVOTEK Create certificate request and install 1. Select the option from the Method pull-down menu. 2. Click Create certificate to proceed. 3. The following information will show up in a pop-up window after clicking Create. Then click Save to generate the certificate request.
  • Page 90 VIVOTEK 5. Look for a trusted certificate authority, such as Symantec’s VeriSign Authentication Services, that issues digital certificates. Sign in and purchase the SSL certification service. Copy the certificate request from your request prompt and paste it in the CA’s signing request window. Proceed with the rest of the process as CA’s instructions on their webpage.
  • Page 91 VIVOTEK 7. Open a new edit, paste the certificate contents, and press ENTER at the end of the contents to add an empty line. 8. Convert file format from DOS to UNIX. Open File menu > Conversions > DOS to Unix.
  • Page 92 VIVOTEK 9. Save the edit using the “.crt” extension, using a file name like “CAcert.crt.” 10. Return to the original firmware session, use the Browse button to locate the crt certificate file, and click Upload to enable the certification. 92 - User's Manual...
  • Page 93 VIVOTEK Note that a 11. When the certifice file is successfully loaded, its status will be stated as Active. certificate must have been created and installed before you can click on the “Save" button for the configuration to take effect.

  • Page 94: Security > Access List

    VIVOTEK Security > Access List This section explains how to control access permission by verifying the client PC’s IP address. General Settings Maximum number of concurrent streaming connection(s) limited to: Simultaneous live viewing for 1~10 clients (including all streams). The default value is 10. If you modify the value and click Save, all current connections will be disconnected and automatically attempt to re-link (IE Explorer or Quick Time Player).
  • Page 95 VIVOTEK ■ Disconnect: If you want to break off the current connections, please select them and click this button. Please note that those checked connections will only be disconnected temporarily and they will automatically retry a connection (IE Explore or Quick Time Player).
  • Page 96 VIVOTEK Network: This rule allows the user to assign a network address and corresponding subnet mask to the Allow/Deny List in the CIDR format, e.g. 192.168.xx.xx/24. For example: IP address 192.168.2.x will be blocked. Range: This rule allows the user to assign a range of IP addresses to the Allow/Deny List.
  • Page 97 Authentication server (usually a RADIUS server): Checks the client certificate and decides whether to accept the end user’s access request. ■ VIVOTEK Network Cameras support two types of EAP methods to perform authentication: EAP-PEAP and EAP-TLS. Please follow the steps below to enable 802.1x settings: 1.
  • Page 98 VIVOTEK 3. When all settings are complete, move the Network Camera to the protected LAN by connecting it to an 802.1x enabled switch. The devices will then start the authentication automatically. NOTE: ► Below is the authentication process for 802.1x: 1.

  • Page 99: Ptz > Ptz Settings

    VIVOTEK PTZ > PTZ settings This section explains how to control the Network Camera’s Pan/Tilt/Zoom operation. The camera comes with built-in PTZ mechanisms. NOTE: The navigation buttons here also support the continuous move. You can click and hold down the button to move across the screen until you release the button.
  • Page 100 VIVOTEK Misc. settings: Use the checkboxes and the pull-down menus for the camera to automatically resume the previous action or return to the home position after the camera has stayed idle for a period of time. PTZ control panel operation mode: This determines how your mouse and PTZ control panel works on a live view window.
  • Page 101 VIVOTEK The Zoom factor display: This option is enabled by default, and zoom ratio is displayed along with the video title on the upper left corner of a view cell. Apply previous action if the camera idles for __(1~999) seconds: You can assign an action to be taken when the camera sits idle for a configurable period time.
  • Page 102 VIVOTEK Auto tracking In this window, you can modify the minimum object size as the triggering factor while performing the Auto Tracking function. You can move the camera view to an area of your interest, estimate, and define the possible size of objects. For example, you can designate the object size such as that of a human trespasser.
  • Page 103 VIVOTEK Auto tracking is configured by designating the minimum object size. Moving objects that entered the current region of view will trigger the tracking action. Auto tracking, if applied, is designed to track an intruder in a place where human traffic is not heavy, such as a warehouse or a load area.

  • Page 104: Event > Event Settings

    VIVOTEK Event > Event settings This section explains how to configure the Network Camera to responds to particular situations (event). A typical application is that when a motion is detected, the Network Camera sends buffered images to an FTP server or e-mail address as notifications. Click on Help, there is an illustration shown in the pop-up window explaining that an event can be triggered by many sources, such as motion detection or external digital input devices.
  • Page 105 VIVOTEK ■ Event name: Enter a name for the event setting. ■ Enable this event: Select this option to enable the event setting. ■ Priority: Select the relative importance of this event (High, Normal, or Low). Events with a higher priority setting will be executed first.
  • Page 106 VIVOTEK ■ Audio detection A preset threshold can be configured with an external microphone as the trigger to system event. The triggering condition can be an input exceeding or falling below a threshold. Audio detection can take place as a complement to motion detection or as a method to detect activities not covered by the camera's view.
  • Page 107 VIVOTEK settings so that the Network Camera will know what action to take (such as which server to send the media files to) when a trigger is activated. NOTE: If you configured a motion detection window as a trigger, the motion detection may become invalid when the camera’s field of view moved away from the detection window.

  • Page 108: Add Server

    VIVOTEK Add server Click Add server to unfold the server setting window. You can specify where the notification messages are sent when a trigger is activated. A total of 5 server settings can be configured. There are four choices of server types available: Email, FTP, HTTP, and Network storage. Select the item to display the detailed configuration options.
  • Page 109 VIVOTEK To verify if the email settings are correctly configured, click Test. The result will be shown in a pop-up window. If successful, you will also receive an email indicating the result. Click Save server to enable the settings, then click Close to exit the Add server page.
  • Page 110 VIVOTEK ■ Passive mode Most firewalls do not accept new connections initiated from external requests. If the FTP server supports passive mode, select this option to enable passive mode FTP and allow data transmission to pass through the firewall. To verify if the FTP settings are correctly configured, click Test. The result will be shown in a pop-up window as shown below.
  • Page 111 VIVOTEK Network storage: Select to send the media files to a network storage location when a trigger is activated. Please refer to NAS server on page 128 for details. Click Save server to enable the settings, then click Close to exit the Add server page.

  • Page 112: Add Media

    VIVOTEK Add media Add media Click to open the media setting window. You can specify the type of media that will be sent and preserved when a trigger is activated. A total of 5 media settings can be configured. There are three choices of media types available: Snapshot, Video Clip, and System log.
  • Page 113 VIVOTEK ■ Add date and time suffix to the file name Select this option to add a date/time suffix to the file name. For example: Snapshot_20110320_100341 File name prefix Date and time suffix The format is: YYYYMMDD_HHMMSS Click Save media to enable the settings, then click Close to exit the Add media page.
  • Page 114 VIVOTEK ■ Maximum duration Specify the maximum recording duration in seconds. Up to 20 seconds can be set. For example, if pre-event recording is set to 5 seconds and the maximum duration is set to 10 seconds, the Network Camera continues to record for another 4 seconds after a trigger is activated.
  • Page 115 VIVOTEK ■ View: Click this button to open a file list window. This function only apllies when an SD card and networked storage are available. If you click View button of SD card, a Local storage page will pop up for you to manage recorded files on SD card.
  • Page 116 VIVOTEK Here is an example of the Event setting: When completed the settings with steps 1~3 to arrange Schedule, Trigger, and Action of an event, click Save event to enable the settings and click Close to exit the page. The following is an example of the Event setting page:...
  • Page 117 Please note that there is a limited number of customized scripts you can upload; if the current amount of customized scripts has reached the limit, an alert message will prompt. If you need more information, please contact VIVOTEK technical support. 2013/03/20...

  • Page 118: Applications > Motion Detection

    VIVOTEK Applications > Motion detection This section explains how to configure the Network Camera to enable motion detection. A total of three motion detection windows can be configured. Motion Detection Setting 1: For normal situations Motion Detection Setting 2: Follow the steps below to enable motion detection:...
  • Page 119 VIVOTEK A green bar indicates that even though motions have been detected, the event has not been triggered because the image variations still fall under the defined threshold. Percentage = 30% If you want to configure other motion detection settings for day/night/schedule mode, please click Profile to open the Motion Detection Profile Settings page as shown below.
  • Page 120 VIVOTEK NOTE: ► How does motion detection work? There are two motion detection parameters: Sensitivity and Percentage. In the illustration above, frame A and frame B are two sequential images. Pixel differences between the two frames are detected and highlighted in gray (frame C) and will be compared with the sensitivity setting. Sensitivity is a value that expresses the sensitivity to moving objects.

  • Page 121: Applications > Di And Do

    VIVOTEK Applications > DI and DO Digital input: Select High or Low to define normal status for the digital input. Connect a digital input from a sensor device to the camera, the Network Camera will report the current signal status. You may then configure the Normal status (non-trigger status) as High or Low.

  • Page 122: Applications > Audio Detection

    VIVOTEK Applications > Audio detection Audio detection, along with video motion detection, is applicable in the following scenarios: 1. Detection of activities not covered by camera view, e.g., a loud input by gun shots or breaking a door/ window. 2. A usually noisy environment, such as a factory, suddenly becomes quiet due to a breakdown of machines.
  • Page 123 VIVOTEK You can use the Profile window to configure a different Audio detection setting. For example, a place can be noisy in the day time and become very quiet in the night. 1. Click on the Enable this profile checkbox. Once the Audio detection window is opened, the current sound input will be interactively indicated by a fluctuating yellow wave diagram.

  • Page 124: Applications > Vadp (Vivotek Application Development Platform)

    VADP requirements. Please contact technical support or the vendor of your 3rd-party module for the parameters contained within. • Users can also run VIVOTEK's VADP packages as a means to access updated functionality instead of replacing the entire firmware. •...
  • Page 125 VIVOTEK To start a module, select the checkcircle in front, and click the Start button. If you should need to remove a module, select the checkcircle in front and then click the Stop button. By then the module status will become OFF, and the X button will appear at the end of the row.

  • Page 126: Recording > Recording Settings

    VIVOTEK Recording > Recording settings This section explains how to configure the recording settings for the Network Camera. Recording Settings Insert your SD card and click here to test NOTE: ► Please remember to format your SD card when using it for the first time. Please refer to page 131 for detailed information.
  • Page 127 VIVOTEK If you enable adaptive recording and enable time-shift cache stream on Camera A, only when an event is triggered on Camera A will the server record video streams in the full frame rate; otherwise, it will only request the I frame data during normal monitoring, thus effectively save lots of bandwidth and storage.
  • Page 128 VIVOTEK 2. Destination You can select the SD card or network attached storage (NAS) for recording video files. NAS server Click Add NAS server to open the server setting window and follow the steps below to set up: 1. Fill in the information for your server.
  • Page 129 VIVOTEK If successful, you will receive a test.txt file on the network storage server. 3. Enter a server name. 4. Click Save to complete the settings and click Close to exit the page. ■ Capacity: You can select either the entire storage space available or specify a reserved space. The recording size limit must be larger than the reserved space for cyclic recording.
  • Page 130 VIVOTEK this page. When the system begins recording, it will send the recorded files to a networked storage or SD card. The new recording name will appear on the recording page as shown below. To remove a recording setting from the list, select it and click Delete.

  • Page 131: Local Storage > Sd Card Management

    VIVOTEK Local storage > SD card management This section explains how to manage the local storage on the Network Camera. Here you can view SD card status, and implement SD card control. SD card status This column shows the status and reserved space of your SD card. Please remember to format the SD card when using for the first time.

  • Page 132: Local Storage > Content Management

    VIVOTEK Local storage > Content management This section explains how to manage the content of recorded videos on the Network Camera. Here you can search and view the records and view the search results. Searching and Viewing the Records This column allows the user to set up search criteria for recorded data. If you do not select any criteria and click Search button, all recorded data will be listed in the Search Results column.
  • Page 133 VIVOTEK ■ View: Click on a search result. The entry will be highlighted in purple as shown above. Click the View button and a media window will pop up to play back the selected file. For example: Click to adjust the image size ■...

  • Page 134: Appendix

    VIVOTEK Appendix URL Commands for the Network Camera 1. Overview For some customers who already have their own web site or web control application, the Network Camera/Video Server can be easily integrated through URL syntax. This section specifies the external HTTP-based application programming interface.

  • Page 135: General Cgi Url Syntax And Parameters

    VIVOTEK 3. General CGI URL Syntax and Parameters CGI parameters are written in lower-case and as one word without any underscores or other separators. When the CGI request includes internal camera parameters, these parameters must be written exactly as they are named in the camera or video server.
  • Page 136 VIVOTEK [&<parameter>…] http://<servername>/cgi-bin/operator/getparam.cgi?[<parameter>] [&<parameter>…] http://<servername>/cgi-bin/admin/getparam.cgi?[<parameter>] [&<parameter>…] Where the <parameter> should be <group>[_<name>] or <group>[.<name>]. If you do not specify any parameters, all the parameters on the server will be returned. If you specify only <group>, the parameters of the related group will be returned.

  • Page 137: Set Server Parameter Values

    (Note: The return page can be a general HTML file (.htm, .html) or a VIVOTEK server script executable (.vspx) file. It cannot be a CGI command or have any extra parameters. This parameter must be placed at the end of the parameter list Return: HTTP/1.0 200 OK\r\n...

  • Page 138: Available Parameters On The Server

    VIVOTEK <parameter>=<value>\r\n [<parameter pair>] Only the parameters that you set and are readable will be returned. Example: Set the IP address of server to 192.168.0.123: Request: http://myserver/cgi-bin/admin/setparam.cgi?network_ipaddress=192.168.0.123 Response: HTTP/1.0 200 OK\r\n Content-Type: text/html\r\n Context-Length: 33\r\n \r\n network.ipaddress=192.168.0.123\r\n 7. Available parameters on the server...
  • Page 139 VIVOTEK everything inside <> A description integer primary key SQLite data type. A 32-bit signed integer. The value is assigned a unique integer by the server. text SQLite data type. The value is a text string, stored using the database encoding (UTF-8, UTF-16BE or UTF-16-LE).
  • Page 140 VIVOTEK address>, value. <blank> timezoneindex -489 ~ 529 Indicate timezone and area. -480: GMT-12:00 Eniwetok, Kwajalein -440: GMT-11:00 Midway Island, Samoa -400: GMT-10:00 Hawaii -360: GMT-09:00 Alaska -320: GMT-08:00 Las Vegas, San_Francisco, Vancouver -280: GMT-07:00 Mountain Time, Denver -281: GMT-07:00 Arizona...
  • Page 141 VIVOTEK Budapest, Bern 02:00 Athens, Helsinki, Istanbul, Riga 81: GMT 02:00 Cairo 82: GMT 02:00 Lebanon, Minsk 83: GMT 02:00 Israel 120: 03:00 Baghdad, Kuwait, Riyadh, Moscow, St. Petersburg, Nairobi 121: GMT 03:00 Iraq 140: GMT 03:30 Tehran 160: GMT 04:00 Abu Dhabi,...
  • Page 142 VIVOTEK Marshall Is. 520: GMT 13:00 Nuku'Alofa daylight_enable <boolean> Enable automatic daylight saving time in time zone. daylight_dstactualmode Check current status daylight saving time. (Used internally) daylight_auto_begintime string[19] NONE Display the current daylight saving start time. daylight_auto_endtime string[19] NONE Display the current daylight saving end time.
  • Page 143 VIVOTEK default values except (ipaddress, subnet, router, dns1, dns2, pppoe). This command can cooperate with other “restoreexceptXYZ” commands. When cooperating with others, system parameters will be restored to the default value except for a union of the combined results. restoreexceptdst...
  • Page 144 VIVOTEK parameters will be restored to the default value except for a union of the combined results. 7.1.1 system.info Subgroup of system_ info (The fields in this group are unchangeable.) NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) modelname string[40] SD8364E Internal model name of the server (eg.
  • Page 145 VIVOTEK 7.2 status Group: status NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) di_i<0~(ndi-1)> <boolean> 0 => Inactive, normal 1 => Active, triggered (capability.ndi > 0) do_i<0~(ndo-1)> <boolean> 0 => Inactive, normal 1 => Active, triggered (capability.ndo > 0) daynight day, night...
  • Page 146 VIVOTEK grounded closed circuit (inactive status) 7.5 security Group: security NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) privilege_do view, operator, operator Indicate which privileges admin above control digital output (capability.ndo > 0) privilege_camctrl view, operator, view Indicate which privileges admin and above can control PTZ (capability.ptzenabled >...
  • Page 147 VIVOTEK To stop service before changing its port settings. It’s recommended to set this parameter when change a service port to the port occupied by another service currently. Otherwise, the service may fail. Stopped service will auto-start after changing port settings.
  • Page 148 VIVOTEK 7.6.1 802.1x Subgroup of network_ieee8021x (capability.protocol.ieee8021x > 0) NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) enable <boolean> Enable/disable IEEE 802.1x eapmethod eap-peap, eap-peap Selected EAP method eap-tls identity_peap String[64] <blank> PEAP identity identity_tls String[64] <blank> TLS identity password String[253] <blank>...
  • Page 149 VIVOTEK management Management channel for CoS eventtunnel Event/Control channel for CoS Subgroup of network_qos_dscp (capability.protocol.qos.dscp > 0) NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) enable <boolean> Enable/disable DSCP video 0~63 Video channel for DSCP audio 0~63 Audio channel for DSCP (capability.naudio > 0)
  • Page 150 VIVOTEK 7.6.5 HTTP Subgroup of network_http NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) port 80, 1025 ~ HTTP port. 65535 alternateport 1025~65535 8080 Alternate HTTP port. authmode basic, basic HTTP authentication mode. digest s0_accessname string[32] video.mjpg HTTP server push access name for stream 1.
  • Page 151 VIVOTEK anonymousviewing <boolean> Enable anoymous streaming viewing. 7.6.6 HTTPS port Subgroup of network_https (capability.protocol.https > 0) NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) port 443, 1025 HTTPS port. 65535 7.6.7 RTSP Subgroup of network_rtsp (capability.protocol.rtsp > 0) NAME VALUE DEFAULT SECURITY...
  • Page 152 VIVOTEK stream4 (capability.protocol.rtsp=1 and capability.nmediastream > 3) S4_accessname string[32] liveany.sdp RTSP access name stream5 (capability.protocol.rtsp=1 and capability.nmediastream > 4) For some models, it is used for anystream. (capability.protocol.rtsp=1 and capability.nanystream = s0_audiotrack <boolean> Enable audio for stream1. s1_audiotrack <boolean> Enable audio for stream2.
  • Page 153 VIVOTEK 7.6.8 SIP port Subgroup of network_sip (capability.protocol.sip> 0) NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) port 1025 ~ 65535 5060 SIP port. 7.6.9 RTP port Subgroup of network_rtp NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) videoport 1025 ~ 65535 5556 Video channel port for RTP.

  • Page 154: Video Input

    VIVOTEK 0 => allow 1 => deny ipv4list_i<0~9> Single address: <blank> IPv4 address list. <ip address> Network address: <ip address network mask> Range address:<start ip address - end ip address> ipv6list_i<0~9> String[43] <blank> IPv6 address list. 7.8 Video input Group: videoin...
  • Page 155 VIVOTEK 1(support) Bit 5 => Support focus operation; 0(not support), 1(support) text string[64] <blank> Enclose caption. imprinttimestamp <boolean> Overlay time stamp on video. enableblc Enable backlight compensation (exposurecontrol => auto with IRCut) 1~12 Set auto gain control to normal (6db~28db) level or MAX level.
  • Page 156 VIVOTEK White balance (2000K 10000K) “manual” – keep current value zoomratiodisplay 0, 1 0: Do not display zoom ratio 1: Display zoom ratio rgain 0~100 Manual set rgain value of gain control setting. bgain 0~100 Manual set bgain value of gain control setting.
  • Page 157 VIVOTEK options quality, framerate quality Video input option: (1) Full HD (MAX1080P 30fps) (product dependent) (2) Exceptional frame rate ( 720P 60fps) enablepreview <boolean> Usage for UI of exposure settings. Preview settings of video profile. s0_codectype mpeg4, mjpeg, h264 Video codec type.
  • Page 158 VIVOTEK 99 is the customized manual input setting. 1 = worst quality, 5 = best quality. 100 is percentage mode. s<0~(m-1)>_mpeg4_qvalue 2~31 Manual video quality level input. (s<0~(m-1)>_mpeg4_quant = 99) s<0~(m-1)>_mpeg4_qperce 1~100 Manual video quality level input. (s<0~(m-1)>_mpeg4_quant = 100) s<0~(m-1)>_mpeg4_bitrate...
  • Page 159 VIVOTEK s2: cbr s3: cbr s<0~(m-1)>_h264_quant 1~5, Quality video when 99, 100 choosing “ratecontrolmode”. 99 is the customized manual input setting. 1 = worst quality, 5 = best quality. 100 is percentage mode. s<0~(m-1)>_h264_qvalue 0~51 Manual video quality level input.
  • Page 160 VIVOTEK image quality first. imagequalit s<0~(m-1)>_mjpeg_maxvb 1000~40000000 40000000 Jpeg max vbr bitrate rbitrate s<0~(m-1)>_mjpeg_ratecon cbr, vbr s0: vbr cbr, constant bitrate trolmode s1: vbr vbr, fix quality s2: vbr s3: vbr s<0~(m-1)>_mjpeg_quant 1~5, Quality of JPEG video. 99, 100 99 is the customized manual input setting.
  • Page 161 VIVOTEK exposurecontrol Select exposure mode. 0 => Auto with IRCut 1 => Shutter priority 2 => Iris priority 3 => Manual mode 4 => Quality mode exposurelevel 0~12 Exposure level 1~12 auto gain control (6db~28db) normal level or MAX level.
  • Page 162 VIVOTEK 7.8.1.1 Alternative video input profiles per channel In addition to the primary setting of video input, there can be alternative profile video input setting for each channel which might be for different scene of light (daytime or nighttime). Group: videoin_c0_profile_i<0~(m-1)> (capability. nvideoinprofile > 0)
  • Page 163 VIVOTEK “outdoor”- 5800k base mode outdoorauto, rbgain, sodium, “outdoorauto” - auto white sodiumauto, balance mode specifically sodiumoutdooauto outdoors. ,widerange, manual “rbgain”- manual rgain/bgain “sodium” - sodium vapor lamps. “Sodiumoutdooauto”-Sodium Vapor Lamp Outdoor Auto “Widerange” - Auto Tracing White balance (2000K 10000K) “manual”...
  • Page 164 VIVOTEK 7.10 IR cut control Group: ircutcontrol (capability.nvideoinprofile > 0) NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) updateinterval 1~10 6/10 Update IR cut status interval daymodebegintime 00:00~23:59 07:00 Day mode begin time daymodeendtime 00:00~23:59 18:00 Day mod end time sensitivity 0~28 Sensitivity of IR cut filter 7.10.1 Alternative IR cut control profiles...
  • Page 165 VIVOTEK reduction dnr_strength 1~100 Adjust noise reduction value of percentage Enable / disable electronic image stabilizer sharpness -3~3,100 Adjust sharpness of image according to mode settings. sharpnesspercent 0~100 Adjust sharpness value of percentage when sharpness=100 saturation -5~5,100 Adjust saturation of image according to mode settings.
  • Page 166 VIVOTEK percentage when sharpness=100 profile_i0_saturation -5~5,100 Adjust saturation of image according to mode settings. profile_i0_saturationpercent 0~100 Adjust saturation value of percentage when saturation =100 profile_i0_hightvline High TV line profile_i0_gammacurve 0~100 Gamma curve 7.12 Image setting for preview Group: imagepreview_c<0~(n-1)> for n channel products...
  • Page 167 VIVOTEK NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) videoin_restoreatwb Restore of adjusting white balance of image according to mode settings videoin_rgain 0~100 Manual set rgain value of gain control setting. videoin_bgain 0~100 Manual set bgain value of gain control setting. 7.13 Audio detection settings Group: audioin_c<0~(n-1)>...

  • Page 168: Motion Detection Settings

    VIVOTEK boostmic 1~100 Gain of build-in mic. <product dependent> s<0~(m-1)>_codectype aac4, g711, g711 Set audio codec type for input. g726 s<0~(m-1)>_aac4_bitrate 16000, 16000 Set AAC4 bitrate in bps. 32000, 48000, 64000, 96000, 128000 s<0~(m-1)>_g726_bitrate 16000, 32000 Set G.726 bitrate in bps.
  • Page 169 VIVOTEK window. win_i<0~2>_height 0 ~ 240 Height motion detection window. win_i<0~2>_objsize 0 ~ 100 Percent motion detection window. win_i<0~2>_sensitivity 0 ~ 100 Sensitivity of motion detection window. Group: motion_c<0~(n-1)> profile for m profile and n channel product (capability.nmotionprofile > 0)
  • Page 170 VIVOTEK window. i<0~(m-1)>_win_i<0~2>_sensitivity 0 ~ 100 Sensitivity motion detection window. 7.17 Tempering detection settings Group: tampering_c<0~(n-1)> for n channel product (capability.tampering > 0) NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) enable <boolean> Enable or disable tamper detection. threshold 0 ~ 255 Threshold of tamper detection.
  • Page 171 VIVOTEK service provider Address.net => non-functional service provider Luna_VC => cybergate ddns Mars_VC => cybergate ddns Planex_VC => cybergate ddns Sun_VC => cybergate ddns Nexus_Control => nexus control DO_JP_FREE => dp-21.net (free) Epolice => epolice.com.tw PCCW => pccw.com MegaChips => megachips.co.jp Dlink =>D-LINK...

  • Page 172: System Log

    VIVOTEK 7.19 Express link Group: expresslink PARAMETER VALUE Default SECURITY DESCRIPTION (get/set) enable <boolean> Enable or disable express link. state onlycheck, badnetwork Camera will check the status of network onlyoffline, environment and express link URL checkonline, badnetwork string[63] NULL The url user define to link to camera 7.20 UPnP presentation...

  • Page 173: Camera Ptz Control

    VIVOTEK serverip <IP address> <blank> Log server IP address. serverport 514, Server port used for log. 1025~65535 level Levels used to distinguish the importance information: 0: LOG_EMERG 1: LOG_ALERT 2: LOG_CRIT 3: LOG_ERR 4: LOG_WARNING 5: LOG_NOTICE 6: LOG_INFO 7: LOG_DEBUG...
  • Page 174 VIVOTEK preset_i<0~(npreset 0 ~ 2445 <blank> Tilt position each preset -1)>_tilt location. preset_i<0~(npreset 0 ~ 16384 <blank> Zoom position at each preset -1)>_zoom location. preset_i<0~(npreset 4096 ~ 49152 <blank> Focus position at each preset -1)>_focus location. preset_i<0~(npreset <blank> Flip side at each preset location.
  • Page 175 VIVOTEK osdzoom <boolean> Show zoom ratio text on video. zoomenhance <boolean> Enable Disable zoom enhancement 7.25 SNMP Group: snmp (capability.snmp > 0) NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) SNMP v2 enabled. 0 for disable, 1 for enable SNMP v3 enabled. 0 for disable, 1...
  • Page 176 Hyperlink of the logo w.vivotek.c logo_powerbyvvtk_hidden <boolean> 0 => display the power by vivotek logo 1 => hide the power by vivotek logo custombutton_manualtrigger_s <boolean> Show or hide manual trigger (VI) button in homepage <product dependent> 0 -> Hidden 1 ->...

  • Page 177: Privacy Mask

    VIVOTEK 7.27 Privacy mask Group: privacymask3d_c<0~(n-1)> for n channel product NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) enable <boolean> Enable the 3D privacy mask color 0~14 Privacy mask color win_i<0~23>_name string[40] <blank> Name of the privacy mask window. win_i<0~23>_pan 0 ~ 7999...
  • Page 178 VIVOTEK Number of virtual inputs <positive (manual trigger) integer> Number of digital outputs. <positive integer> naudioin Number of audio inputs. <positive integer> naudioout Number of audio outputs. <positive integer> nvideoin <positive Number of video inputs. integer> nmediastream <positive Number of media stream integer>...
  • Page 179 VIVOTEK 1(support) => Support tilt operation; 0(not support), 1(support) Bit 4 => Support zoom operation; 0(not support), 1(support) Bit 5 => Support focus operation; 0(not support), 1(support) => Support iris operation; 0(not support), 1(support) => External built-in 0(built-in), 1(external) Bit 8 => Invalidate bit 1 ~...
  • Page 180 VIVOTEK ptz_minpan <positive The lower limit for pan 3.2-1 integer> position. ptz_maxpan <positive 7999 The upper limit for pan 3.2-1 integer> position. ptz_minpanangle < integer> The lower limit for pan 3.2-1 angle. ptz_maxpanangle < integer> The upper limit for pan 3.2-1...
  • Page 181 VIVOTEK scalable support scalable multicast. protocol_rtp_multicast_ <boolean> Indicate whether backchannel support backchannel multicast. protocol_rtp_tcp <boolean> Indicate whether support RTP over TCP. protocol_rtp_http <boolean> Indicate whether support RTP over HTTP. protocol_spush_mjpeg <boolean> Indicate whether support server push MJPEG. protocol_snmp <boolean> Indicate whether support SNMP.
  • Page 182 VIVOTEK videoin_streamcodec 7,7,7,7 A list of This equals <Positive Integer> "capability_videoin_c0_str eamcodec". This kept compatibility. videoin_c<n>_streamcodec 7,7,7,7 A list of Represent supported <Positive Integer> codec types of each stream. This contains a list of positive integers, split by comma. Each one stands...
  • Page 183 VIVOTEK Codec: H264 Codec:  , 5.6  MPEG4 Codec:  , 5.7  MJPEG   * Only available when  [httpversion] >= 0300 videoout_codec <a list <blank> Available codec list. available codec types separated by commas) <product dependent> audio_aec <boolean> Indicate whether support acoustic echo cancellation. audio_extmic <boolean> Indicate whether support external microphone input.
  • Page 184 VIVOTEK camctrl_httptunnelclient <boolean> Indicate whether support httptunnel client. camctrl_privilege <boolean> Indicate whether support “Manage Privilege” of PTZ control in the Security page. support both /cgi-bin/camctrl/camctrl.c /cgi-bin/viewer/camctrl.cg support only /cgi-bin/viewer/camctrl.cg uart_httptunnel <boolean> Indicate whether support HTTP tunnel for UART transfer. transmission_mode...
  • Page 185 VIVOTEK => stream supports ePTZ or not. The rest may be deduced by analogy nanystream 0, <positive number media integer> stream per channel <boolean> Indicate whether support Intelligent Video analysis tampering <boolean> Indicate whether support tampering detection. test_ac <boolean> Indicate whether support test ac key.
  • Page 186 VIVOTEK Group: capability_videoin_c<n>,  n denotes the channel index, with a range from 0 to one less than the value of “capability_nvideoin".    * Only available when the value of [httpversion] is greater than or equal to 0300  Default  SECURITY NAME VALUE DESCRIPTION         (get/set) mode1 <Positive  2  Indicate how many video modes supported by this        Integer> channel.     maxsize <WxH> 1920x1080  0/7 The maximum resolution of all modes in this        channel, the unit is pixel.      * We call this as "Full Scene". mode <Integer>...
  • Page 187 VIVOTEK Default  SECURITY NAME VALUE DESCRIPTION         (get/set) mpeg4_maxf A list of  30,30,30,30, Maximum fps that the device can encoded one    ramerate <Integer> and  30,30,27  stream with MPEG4 on resolutions in current video    "‐" mode.    "‐" means not support.    * One to one mapping to the resolution in  "resolution".  * The element number is defined as "nresolution"  in this group.  * This parameter may be changed when  "videoin_c<n>_cmosfreq"=50 or  "videoin_c<n>_modulation"=pal.  Ex: 30 fps is changed to 25 fps, 60 fps is changed to  50 fps, and so on.  Codec: MPEG4 More details, see 5.6  .  * Only available when 'mpeg4' is listed in   ...
  • Page 188 VIVOTEK Default  SECURITY NAME VALUE DESCRIPTION         (get/set) 50 fps, and so on.  Codec: MJPEG More details, see 5.7  .  * Only available when 'mjpeg' is listed in  "capability_videoin_codec".  mjpeg_maxb <Positive  40000000  Maximum bitrates of MJPEG.    itrate Integer>, ‐ The unit is bps.      "‐" means MJPEG does not support bit rate control.   * Only available when 'mjpeg' is listed in  "capability_videoin_codec".  Codec: MJPEG   * More details, see 5.7  h264_maxfra A list of  30,30,30,30, Maximum fps that the device can encoded one    merate <Positive ...
  • Page 189 VIVOTEK Group: capability_videoin_c<n>_mode<m>,    n denotes the channel index, with a range from 0 to one less than the value of“capability_nvideoin”;    m denotes the stream index, with a range from 0 to one less than the value of  "capability_nmediastream".  Default  SECURITY  NAME VALUE DESCRIPTION         (get/set) effectivepixel <WxH> 1920x1080  The visible area of full scene in this video mode.       The unit is pixel in source.    * This value must <=  "capability_videoin_c<n>_maxsize"  * If  "effectivepixel"<"capability_videoin_c<n>_max size", then the visible area is located at the    center of full scene. outputsize <WxH> 1920x1080  The output size of source, equal to the captured       ...
  • Page 190 VIVOTEK Default  SECURITY  NAME VALUE DESCRIPTION         (get/set)   this parameter to disclose this information. nresolution <Positive  7  How many resolution options in this video      Integer> mode.     resolution A list of  176x144,384x Resolution options in this video mode.      <WxH> 216,640x360, The last one is the maximum resolution in this    1280x720,136 video mode.  0x768,1600x9   04,1920x1080  * The element number is defined as   ...
  • Page 191 VIVOTEK Default  SECURITY  NAME VALUE DESCRIPTION         (get/set) * Only available when 'mpeg4' is listed in    "capability_videoin_codec". maxfps_mjpeg A list of  30,30,30,30,3 Maximum fps which the device can encoded      <Positive  0,30,30  with MJPEG on resolutions in this video mode.  Integer>  "‐" means not support.  and "‐"     * One to one mapping to the resolution in  "resolution".  * The element number is defined as  "nresolution" in this group.  * This parameter records the frame rate when  "videoin_c<n>_cmosfreq"=60 or  "videoin_c<n>_modulation"=ntsc  * Only available when 'mjpeg' is listed in    "capability_videoin_codec". maxfps_h264 A list of ...

  • Page 192: Event Setting

    VIVOTEK 7.29 Customized event script Group: event_customtaskfile_i<0~2> PARAMETER VALUE Default SECURITY DESCRIPTION (get/set) name string[40] <blank> Custom script identification of this entry. date string[4~20] <blank> Date of custom script. time string[4~20] <blank> Time of custom script. 7.30 Event setting Group: event_i<0~2>...
  • Page 193 VIVOTEK 0~15 Indicate the source id of di trigger. This field is required when trigger condition is “di”. One bit represents one digital input. The LSB indicates DI 0. mdwin Indicate the source window id of motion detection. This field is required when trigger condition is “md”.
  • Page 194 VIVOTEK endtime hh:mm 24:00 End time of the weekly schedule. (00:00 ~ 24:00 sets schedule as always on) action_do_i<0~(ndo-1) 0, 1 Enable disable trigger digital >_enable output. action_do_i<0~(ndo-1) 1~999 Duration of the digital output trigger >_duration in seconds. action_goto_enable <Boolean>...
  • Page 195 VIVOTEK action_ patrol _server 0~255 Indicate the target servers to which (only for VS series) the snapshots taken during patrol <product dependent> dwelling time should be sent. One bit represents one application server (server_i0~i4). bit0 (LSB) = server_i0. bit1 = server_i1.
  • Page 196 VIVOTEK email_address string[128] NULL Email server address. email_sslmode 0, 1 Enable support SSL. email_port 0~65535 Port to connect to the server. email_username string[64] NULL Username to log in to the server. email_passwd string[64] NULL Password of the user. email_senderemail string[128] NULL Email address of the sender.
  • Page 197 VIVOTEK snapshot_datesuffix 0, 1 date time suffix filename: 1 = Add date and time suffix. 0 = Do not add. snapshot_preevent 0 ~ 7 Indicates the number of pre-event images. snapshot_postevent 0 ~ 7 The number of post-event images. videoclip_source...
  • Page 198 VIVOTEK source Indicate the source of media stream. 0 means the first stream. 1 means the second stream and so limitsize 0: Entire free space mechanism 1: Limit recording size mechanism cyclic 0: Disable cyclic recording 1: Enable cyclic recording...
  • Page 199 VIVOTEK prefix string[16] <blank> Indicate the prefix of the filename. cyclesize 200~ The maximum size for cycle recording in Kbytes when choosing to limit recording size. reserveamount The reserved amount in Mbytes when choosing cyclic recording mechanism. dest The destination to store the recorded 0,1,2,3,4 data.
  • Page 200 VIVOTEK manual, certificate automatically. install manual => Create self-signed certificate manually. install => Create certificate request and install. status -3 ~ 1 Specify the https status. -3 = Certificate not installed -2 = Invalid public key -1 = Waiting for certificate...
  • Page 201 VIVOTEK 7.36 Object tracking setting Group: sdobjtrack PARAMETER VALUE Default SECURITY DESCRIPTION (get/set) objsize_type -1~2 Type of object size. -1 : customized width and height 0 : object size = 30 x 30 1 : object size = 10 x 20...
  • Page 202 VIVOTEK guid<0~2>_number Number connected seamless streaming with guid<0~2>_id. (Read only) 7.38 VIVOTEK Application Development Platform setting Group: vadp NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) version <string> 1.0.3.3 Indicate the VADP version. resource_total_video <integer> Indicate total video resource number of the system.
  • Page 203 VIVOTEK should be saved to SD card when user want to upload it. If the value is false, save module internal storage space and it will occupy storage size. Group: vadp_module_i<0~(n-1)> n = 10 NAME VALUE DEFAULT SECURITY DESCRIPTION (get/set) enable <boolean>...
  • Page 204 VIVOTEK 8. Useful Functions 8.1 Drive the Digital Output (capability.ndo > 0) Note: This request requires Viewer privileges. Method: GET/POST Syntax: http://<servername>/cgi-bin/dido/setdo.cgi?do1=<state>[&do2=<state>] [&do3=<state>][&do4=<state>] Where state is 0 or 1; “0” means inactive or normal state, while “1” means active or triggered state.
  • Page 205 VIVOTEK Example: Query the status of digital input 1 . Request: http://myserver/cgi-bin/dido/getdi.cgi?di1 Response: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: 7\r\n \r\n di1=1\r\n 8.3 Query Status of the Digital Output (capability.ndo > 0) Note: This request requires Viewer privileges Method: GET/POST Syntax: http://<servername>/cgi-bin/dido/getdo.cgi?[do0][&do1][&do2][&do3]...
  • Page 206 VIVOTEK \r\n do1=1\r\n 8.4 3D Privacy Mask Note: This request requires admin user privilege <SD81X1> You can set privacy mask only at zoom 1x. To go back to zoom 1x directly, please send this cgi command: "/cgi-bin/camctrl/camposition.cgi?setzoom=0" Method: GET/POST Syntax: Fixed in center : http://<servername>/cgi-bin/admin/setpm3d.cgi?method=<value>&name=<value>&[maskheight=<value>&...

  • Page 207: Capture Single Snapshot

    VIVOTEK 8.5 Capture Single Snapshot Note: This request requires Normal User privileges. Method: GET/POST Syntax: http://<servername>/cgi-bin/viewer/video.jpg?[channel=<value>][&resolution=<value>] [&quality=<value>][&streamid=<value>] If the user requests a size larger than all stream settings on the server, this request will fail. PARAMETER VALUE DEFAULT DESCRIPTION channel 0~(n-1) The channel number of the video source.

  • Page 208: Account Management

    VIVOTEK 8.6 Account Management Note: This request requires Administrator privileges. Method: GET/POST Syntax: http://<servername>/cgi-bin/admin/editaccount.cgi? method=<value>&username=<name>[&userpass=<value>][&privilege=<value>] [&privilege=<value>][…][&return=<return page>] PARAMETER VALUE DESCRIPTION method Add an account to the server. When using this method, the “username” field is necessary. It will use the default value of other fields if not specified.

  • Page 209: System Logs

    VIVOTEK 8.7 System Logs Note: This request require Administrator privileges. Method: GET/POST Syntax: http://<servername>/cgi-bin/admin/syslog.cgi Server will return the most up-to-date system log. Return: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: <syslog length>\r\n \r\n <system log information>\r\n 8.8 Upgrade Firmware Note: This request requires Administrator privileges.
  • Page 210 VIVOTEK 8.9 Camera Control (capability.ptzenabled) Note: This request requires Viewer privileges. Method: GET/POST Syntax: http://<servername>/cgi-bin/camctrl/camctrl.cgi?[channel=<value>][&camid=<value>] [&move=<value>] – Move home, up, down, left, right [&focus=<value>] – Focus operation [&iris=<value>] – Iris operation [&auto=<value>] – Auto pan, patrol [&zoom=<value>] – Zoom in, out [&zooming=<value>&zs=<value>] –...
  • Page 211 VIVOTEK speedfocus -5 ~ 5 Set the focus speed. speedapp -5 ~ 5 Set the auto pan/patrol speed. auto Auto pan. patrol Auto patrol. stop Stop camera. zoom wide Zoom larger view with current speed. tele Zoom further with current speed.
  • Page 212 VIVOTEK 8.10 ePTZ Camera Control (capability.eptz > 0) Note: This request requires camctrl privileges. Method: GET/POST Syntax: http://<servername>/cgi-bin/camctrl/eCamCtrl.cgi?channel=<value>&stream=<value> [&move=<value>] – Move home, up, down, left, right [&auto=<value>] – Auto pan, patrol [&zoom=<value>] – Zoom in, out [&zooming=<value>&zs=<value>] – Zoom without stopping, used for joystick [&vx=<value>&vy=<value>&vs=<value>] –...
  • Page 213 VIVOTEK tele Zoom further with current speed. zooming wide or tele Zoom without stopping for larger view or further view with zs speed, used for joystick control. 0 ~ 6 Set the speed of zooming, “0” means stop. <integer> The direction of movement, used for joystick control.
  • Page 214 VIVOTEK 8.11 Recall (capability.ptzenabled) Note: This request requires Viewer privileges. Method: GET Syntax: http://<servername>/cgi-bin/viewer/recall.cgi? recall=<value>[&channel=<value>][&return=<return page>] PARAMETER VALUE DESCRIPTION recall Text string less than 30 One of the present positions to recall. characters channel <0~(n-1)> Channel of the video source.
  • Page 215 VIVOTEK 8.13 Preset Locations (capability.ptzenabled) Note: This request requires Operator privileges. Method: GET/POST Syntax: http://<servername>/cgi-bin/operator/preset.cgi?[channel=<value>] [&addpos=<value>][&delpos=<value>][&return=<return page>] PARAMETER VALUE DESCRIPTION addpos <Text string less than Add one preset location to the preset list. 30 characters> channel <0~(n-1)> Channel of the video source.
  • Page 216 VIVOTEK 8.14 ePTZ Preset Locations (capability.eptz > 0) Note: This request requires Operator privileges. Method: GET/POST Syntax: http://<servername>/cgi-bin/operator/ePreset.cgi?channel=<value>&stream=<value> [&addpos=<value>][&delpos=<value>][&return=<return page>] PARAMETER VALUE DESCRIPTION channel <0~(n-1)> Channel of the video source. stream <0~(m-1)> Stream. addpos <Text string less than Add one preset location to the preset list.
  • Page 217 VIVOTEK delv4 Delete IPv4 address from access list. delv6 Delete IPv6 address from access list. <IP address> Single address: <IP address> Network address: <IP address / network mask> Range address:<start IP address - end IP address> index <value> The start position to add or to delete.

  • Page 218: Technical Specifications

    VIVOTEK PARAMETER VALUE DESCRIPTION channel 0 ~ (n-1) The channel number of UART. 8.17 Event/Control HTTP Tunnel Channel (capability. evctrlchannel > 0) Note: This request requires Administrator privileges. Method: GET and POST Syntax: http://<servername>/cgi-bin/admin/ctrlevent.cgi ------------------------------------------------------------------------- GET /cgi-bin/admin/ctrlevent.cgi x-sessioncookie: string[22] accept: application/x-vvtk-tunnelled...
  • Page 219 VIVOTEK 8.18 Get SDP of Streams Note: This request requires Viewer access privileges. Method: GET/POST Syntax: http://<servername>/<network_rtsp_s<0~m-1>_accessname> “m” is the stream number. “network_accessname_<0~(m-1)>” is the accessname for stream “1” to stream “m”. Please refer to the “subgroup of network: rtsp” for setting the accessname of SDP.
  • Page 220 VIVOTEK 8.20 Senddata (capability.nuart > 0) Note: This request requires Viewer privileges. Method: GET/POST Syntax: http://<servername>/cgi-bin/viewer/senddata.cgi? [com=<value>][&data=<value>][&flush=<value>] [&wait=<value>] [&read=<value>] PARAMETER VALUE DESCRIPTION 1 ~ <max. com port The target COM/RS485 port number. number> data <hex decimal The <hex decimal data> is a series of digits from 0 ~ 9, A ~ F.
  • Page 221 VIVOTEK 8.21 Storage managements (capability.storage.dbenabled > 0) Note: This request requires administrator privileges. Method: GET and POST Syntax: http://<servername>/cgi-bin/admin/lsctrl.cgi?cmd=<cmd_type>[&<parameter>=<value>…] The commands usage and their input arguments are as follows. PARAMETER VALUE DESCRIPTION cmd_type <string> Required. Command to be executed, including search, insert, delete, update, and queryStatus.
  • Page 222 VIVOTEK Indicate if the file is locked or not. 0: file is not locked. 1: file is locked. A locked file would not be removed from UI or cyclic storage. triggerTime <text> Optional. Indicate the event trigger time. (not the file created time) Format is “YYYY-MM-DD HH:MM:SS”...
  • Page 223 VIVOTEK label <integer primary key> Required. Identify the designated record. Ex. label=1 isLocked <boolean> Required. Indicate if the file is locked or not. Ex. Update records whose key numbers are 1 and 5 to be locked status. http://<servername>/cgi-bin/admin/lsctrl.cgi?cmd=update&isLocked=1&label=1&label=5 Ex. Update records whose key numbers are 2 and 3 to be unlocked status.
  • Page 224 VIVOTEK state after duration. it cannot accept new requests. return <return page> Redirect to the page <return page> after the request is completely assigned. The <return page> can be a full URL path or relative path according the current path. If you omit this parameter, it will redirect to an empty page.
  • Page 225 VIVOTEK “m” is the timeshift stream index. For details on timeshift stream, please refer to the “TimeshiftCaching” documents. PARAMETER VALUE DEFAULT DESCRIPTION maxsft <positive Request cached stream at most how many seconds ago. interger> tsmode normal, normal Streaming mode: adaptive normal =>...
  • Page 226 VIVOTEK 8. 24 Open Anystream (capability.nanystream > 0) Note: This request requires Viewer access privileges. Syntax: For HTTP push server (MJPEG): http://<servername>/videoany.mjpg?codectype=mjpeg[&resolution=<value>&mjpeg_quant=<value>& mjpeg_qvalue=<value>&mjpeg_maxframe=<value>] For RTSP (MPEG4), the user needs to input the URL below into an RTSP compatible player. rtsp://<servername>/liveany.sdp?codectype=mpeg4[&resolution=<value>&mpeg4_intraperiod=<value>...
  • Page 227 VIVOTEK mpeg4_ratecontrolmode cbr, vbr cbr: constant bitrate vbr: fix quality mpeg4_quant 0, 1~5 Quality of video when choosing vbr in 99, 1~5 “mpeg4_ratecontrolmode”. <product dependent> 0,99 is the customized manual input setting. 1 = worst quality, 5 = best quality.
  • Page 228 VIVOTEK dependent> 228 - User's Manual...
  • Page 229 AM-118 AM-103 cover Indoor Recessed kit pendant head All speci cations are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved. Distributed by: Ver 1.2 VIVOTEK INC. VIVOTEK USA VIVOTEK Europe 6F, No.192, Lien-Cheng Rd., Chung-Ho,...

  • Page 230: Technology License Notice

    VIVOTEK Technology License Notice MPEG-4 AAC Technology THIS PRODUCT IS LICENSED UNDER THE MPEG-4 AAC AUDIO PATENT LICENSE. THIS PRODUCT MAY NOT BE DECOMPILED, REVERSE-ENGINEERED OR COPIED, EXCEPT WITH REGARD TO PC SOFTWARE, OF WHICH YOU MAY MAKE SINGLE COPIES FOR ARCHIVAL PURPOSES. FOR MORE INFORMATION, PLEASE REFER TO HTTP://WWW.VIALICENSING.COM.

  • Page 231: Electromagnetic Compatibility (Emc)

    取扱説明書に従って正しい取り扱いをして下さい Liability VIVOTEK Inc. cannot be held responsible for any technical or typographical errors and reserves the right to make changes to the product and manuals without prior notice. VIVOTEK Inc. makes no warranty of any kind with regard to the material contained within this document, including, but not limited to, the implied warranties of merchantability and fitness for any particular purpose.

This manual is also suitable for:

Sd8364mSd8364e-m

Table of Contents
