Product Description - HP Pavilion 11 x360 PC Maintenance And Service Manual

1

Product description

Category
Product Name
Processor
Chipset
Graphics
Panel
Memory
Hard drive
Optical drive
Audio and video
Description
HP Pavilion 11 x360 PC
Intel® Pentium N3520 processor (2.17GHz/2.42GHz, 2 MB L2, 1333MHz)
Intel Celeron N2820 processor (2.13GHz/2.39GHz, 1 MB L2, 1066MHz)
Intel Bay Trail-M SoC
Internal graphics:
Intel HD Graphics
Support for DX11
Support for HD playback, streaming, and recording @ 720p 30fps
11.6-in [29.5-cm] (1366×768), high-definition (HD), white light emitting diode (WLED), AntiGlare,
TouchScreen with MultiTouch enabled; 16:9 ultra-wide aspect ratio; typical brightness: 200 nits;
slim (3.6-mm)
Supports low-voltage differential signaling (LVDS) (co-layout with eDP1.3+PSR)
One customer-accessible/upgradable memory module slot
Support for DDR3L-1333-MHz (DDR3L-1600-MHz downgrade to DDR3L-1333-MHz) – for use
with Pentium processors
Support for DDR3L-1066-MHz (DDR3L-1600-MHz downgrade to DDR3L-1066-MHz) – for use
with Celeron processors
Support for 8192-MB of system RAM in the following configurations:
●
8192 MB × 1
●
4096 MB × 1
●
2048 MB × 1
Support for 6.35-cm (2.5-in) hard drives in 7.0-mm (.28-in) thickness
Support for Serial ATA
Support for Accelerometer hard drive protection
Support for the following hard drives:
● 750-GB, 5400-rpm, 7.2-mm
● 500-GB, 5400-rpm, 7.0-mm
● 500-GB, 5400-rpm + 8 GB NAND Hybrid, 7.0-mm
● 320-GB, 5400-rpm, 7.0-mm
Support for external 9.5 mm tray load, SATA, DVD+/-RW DL SuperMulti drive only
Integrated HP TrueVision camera: HD (1280×720 by 30 frames per second), fixed (no tilt), with
activity light
Realtek ALC3227-CG audio codec
Two speakers
1
