1Cisco Nexus 2224TP
Chassis
The Cisco Nexus 2224TP chassis has a height of 1.72 inches (4.37 cm), a width of 17.34 inches (44.04
cm), and a depth of 18.9 inches (48.1 cm). It weighs 18 pounds (8.0 kg). Its one-rack-unit (1 RU) form
factor takes up relatively little space, making it easy to incorporate into rack designs. The FEX is
mounted in a standard 19-inch (48.26-cm) rack. It has front-to-back or back-to-front airflow for cooling.
All switch ports are located at the rear of the unit in close proximity to server ports, and all
user-serviceable components are accessible from the front panel.
Figure 1-23
location of components on the rear of the chassis. For information on what the chassis and component
LEDs indicate, see
Figure 1-23
1
2
Cisco Nexus 2000 Series Hardware Installation Guide
1-28
shows the location of the components on the front of the chassis, and
Table D-1 on page
Front of the Cisco Nexus 2224TP Chassis
1
2
Power supply
Fan tray (1)
Chapter 1 Using a Fabric Extender with a Cisco Nexus 5000 Series Switch
D-2.
3 4
3 Power supply (blank power supply shown)
4
Status (top) and ID (bottom) LEDs
Figure 1-24 shows the
