INSTALLATION AND OPERATION INSTRUCTIONS
MODEL: 6000TRSI-AUC
AUSTRALIAN GAS ASSOCIATION CERTIFIED
CERTIFICATE NUMBER 5668
THIS MANUAL MUST BE USED FOR INSTALLATION AND RETAINED
BY HOMEOWNER FOR OPERATION AND MAINTENANCE.
HEAT & GLO, a brand of Hearth & Home Technologies Inc.
20802 Kensington Boulevard, Lakeville, MN 55044, USA, www.heatnglo.com
THIS PRODUCT MAY BE COVERED BY ONE OR MORE OF THE FOLLOWING PATENTS:
(United States) 4593510, 4686807, 4766876, 4793322, 4811534, 5000162, 5016609, 5076254, 5113843, 5191877, 5218953, 5263471, 5328356, 5341794, 5347983, 5429495, 5452708, 5542407,
5601073, 5613487, 5647340, 5688568, 5762062, 5775408, 5890485, 5931661, 5941237, 5947112, 5996575, 6006743, 6019099, 6048195, 6053165, 6145502, 6170481, 6237588, 6296474,
6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2, 6729551, 6736133, 6748940, 6748942, D320652, D445174, D462436; (Canada) 1297749,
2195264, 2225408; (Australia) 543790;586383; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.
Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06
1

Advertisement

Table of Contents
loading

Related Manuals for Heat & Glo 6000TRSI-AUC

Summary of Contents for Heat & Glo 6000TRSI-AUC

  • Page 1 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2, 6729551, 6736133, 6748940, 6748942, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408; (Australia) 543790;586383; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 2 Heat & Glo, a brand of Hearth & Home Technologies, Inc. Heat & Glo Quality Systems 20802 Kensington Blvd., Lakeville, MN 55044, USA registered by SGS ICS Copyright 2006 • Printed in U.S.A. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 3: Table Of Contents

    B. Removal of Components for Service ............29 C. Parts Replacement ..................29 D. Adjustments and Replacement Parts ............29 E. Troubleshooting ................... 30 4.0 REPLACEMENT PARTS................. 33 Limited Warranty ....................35 Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 4: Installation Instructions

    126.9 41 1043 STANDOFFS GLASS DOOR DATA BADGE & LABELS (BEHIND ACCESS DOOR) GAS CONTROLS GAS LINE AND SWITCHES ELECTRICAL ACCESS ACCESS FIGURE 1.1 Diagram of the 6000 Series Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 5: Locating The Heater

    1 inch 1 inch 2-1/2 inches 1/2 inch 1 inch (25mm) (75mm) (25mm) (25mm) (63.7mm) (13mm) (25mm) For minimum clearances, see the direct flue termination clearance diagrams on page 7. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 6: Framing The Heater

    26-7/8 in. 47-3/4 in. (1070mm) (980mm) (560mm) (684mm) (1060mm) * NOTE: Dimension B taken from finished hearth frame. Dimensions D and E taken from bottom of unit. FIGURE 1.3 Framing Dimensions Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 7 LP Gas cylinder. A flue terminal is considered to be a source of ignition. MINIMUM CLEARANCES REQUIRED FOR BALANCED FLUE TERMINALS OR THE FLUE TERMINALS OF OUTDOOR APPLIANCES FIGURE 1.4 Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 8: Flue System Approvals And Installations

    AROUND THE 8 INCH PIPE. For alternative installations, other than depicted, con- tact your dealer for further information. Refer to Figure 1.4 for required clearances to flue ter- minals. FIGURE 1.6 Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 9 H are listed as beginning MAXIMUM horizontal dimensions. Dimensions H+H and H+H are listed as TOTAL MAXIMUM horizontal dimensions. Dimensions V+V are listed as TOTAL MAXIMUM ver- tical dimensions. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 10 4' MIN. (1.22 M) 6' MAX. (1.83 M) 16' MAX. (4.88 M) 20' MAX. (6.10 M) 6' MAX. (1.83 M) 16' MAX. (4.88 M) FIGURE 1.10 Flueing with Two 90° Elbows Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 11 12' MAX. (3.66 M) 4' MIN. (1.22 M) 16' MAX. (4.88 M) V+H+H = 36' MAX.(10.97 M) +H = 36' MAX.(10.97 M) FIGURE 1.11 Flueing with Two 90° Elbows Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 12 4´ MIN. (1.22 M) 6´ MAX. (1.83 M) 12´ MAX. (3.66 M) 20´ MAX. (6.10 M) 6´ MAX. (1.83 M) 12´ MAX. (3.66 M) FIGURE 1.13 Flueing with three 90° elbows Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 13 3' MIN. (0.91 M) 9' MAX. (2.74 M) 4' MIN. (1.22 M) 12' MAX. (3.66 M) +H +H = 32' MAX. (9.75 M) NOTE: FIGURE 1.14 Flueing with three 90° elbows Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 14 INSULATION SHIELD DISCARD BOTH PIECES and HEAT SHIELD HEAT DISCARD SHIELD INSULATION HEAT SHIELD HERE Cut the seal cap strap and remove white gasket material. Figure 1.15 FIGURE 1.17 Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 15 For elbows that are changing the flue direction, two screws minimum should be put in the outer flue at the joint to prevent the elbow from rotating. Figure 1.18 Figure 1.19 Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 16 • Cut a 10" x 10" (254mm X 254mm) hole through the ceiling, using the firestop pipe opening as a guide. • Frame the hole with framing lumber the same size as the ceiling joists. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 17 • The termination kit should pass through the wall firestops from the exterior of the building. NAILS (4 REQUIRED) RAFTER CEILING CEILING FIRESTOP FIGURE 1.25 Attic Firestop Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 18: Connecting The Gas Supply

    NOT USE AN OPEN FLAME. the appropriate distance above the roof. NOTE: THE GAS SUPPLY LINE SHOULD BE PURGED OF ANY TRAPPED AIR PRIOR TO THE FIRST FIRING OF THE UNIT. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 19: Ignition System Wiring

    IGNITION MODULE (6V) 6VDC GROUND NEUTRAL BATTERY PORT PLUG IN THERMOCOUPLE ON/OFF BLOCK SWITCH (CONNECTED TO BACK OF VALVE) VALVE GAS LINE CONNECTED TO BACK OF VALVE FIGURE 1.29 Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 20 (NEUTRAL) BLUE BLUE heater. Figure 1.30 shows the blower fan, BLUE switches, and blower fan wiring diagram. See Figure 1.31 for wire connection detail. FIGURE 1.31 Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 21: Mantel Clearances

    MATERIAL MUST BE USED. THESE JOINTS ARE NOT REQUIRED TO BE SEALED. ONLY NON- COMBUSTIBLE MATERIAL (USING 150° C. MINIMUM ADHESIVE, IF NEEDED) CAN BE APPLIED AS FACING TO THE FIREPLACE SURROUND. SEE FIGURE 1.33. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 22: Log Placement

    Locate log #1 by placing log notches on the second and fifth grate bars and push log against rear log locators. LOG #2 (SRV2049-701): Locate log #2 on grate with notches. Slide back against tabs. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 23 Place log #4 on 5th grate bar and rest its top into the groove on log #1. LOG #5 (SRV385-723): Position log #5 between the 3rd and 4th grate bar resting on the grooves in log #1 and log #2. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 24: Installer Testing

    This noise is similar to one that a furnace or heat duct may produce and does not affect the operation or longevity of the heater. FIGURE 1.34 Follow TROUBLESHOOTING section for adjusting the appliance to operate properly. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 25: Operating Cautions

    • THE DRESS GUARD MUST BE IN PLACE AND SEALED AND THE FIXED MESH TRIM ASSEM- BLY MUST BE IN PLACE ON THE HEATER BE- FORE THE UNIT CAN BE PLACED INTO SAFE OP- ERATION. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 26: Safety And Lighting Information

    2. Remove power from receiver. Keep burner and control compart- ment clean. See installation and operating instructions accompany- ing appliance. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 27: Power Outage

    You can manually stop the fan by turning the speed control switch to "OFF". See Figure 1.30 for fan wiring diagram. SWITCH IS SHOWN IN "ON" POSITION Figure 2.2 Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 28: Servicing And Maintenance

    To obtain proper operation, it is imperative that the pilot and main burner flame characteristics are steady, not lifting or floating. Typically, the top 3/8 inch of the ther- Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 29: Removal Of Covers For Servicing

    2.0 OPERATING INSTRUCTIONS. A replacement part PILOT BRACKET table is shown in SECTION 4.0 of this manual. RETAINING SCREWS FIGURE 3.3 CAUTION: ALL SCREWS WHICH WERE REMOVED MUST BE REPLACED. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 30 4. Inspect for corrosion or separation. 5. Verify weather stripping, sealing and flashing remains intact. Remote controls 1. Verify operation of remote. 2. Replace batteries in remote transmitters and battery-powered receivers. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 31: Troubleshooting

    Ignitor gap is too large. Verify that spark gap from ignitor to pilot hood is .43 cm. c. Module is not grounded. Verify module is securely grounded to metal chassis of fireplace. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 32 3. Be sure glass is tighened properly on unit, particularly on top corners. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 33: Replacement Parts

    6000TRSI-AUC 4.0 Replacement Parts (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 6-06 Ending Manufacturing Date: ______ Log set assembly Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 34 Mineral Wool 050-721 Glass Latch Assembly 386-122A Exhaust Restrictor 2022-107 Vent Gasket 2025-114 Touch-Up Paint TUP-GBK-12 Accesssories Multi Function Remote Control REM-DLX-CE Conversion Kit NG NGK-6TRSI-AUC Conversion Kit LP LPK-6TRSI-AUC Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...

  • Page 35: Limited Warranty

    HEAT & GLO reserves the right to make changes at any time, without notice, in design, material, specifications and prices. It also reserves the right to discontinue styles and products. Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
  • Page 36 Melbourne Jetmaster 444 Swan Street Richmond 3121 (03) 9429-5573 Perth Fireplace Corner 277 Lord Street East Perth 6000 (08) 9228-2600 Sydney Jetmaster 10 Martin Avenue Arncliff 2205 (02) 9597-7222 Heat & Glo • 6000TRSI-AUC • 2078-900 Rev. G • 12/06...
