NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
PARTS LIST
DRAWING
DESCRIPTION
NUMBER
1
TOP GRILLE
2
CARRYING HANDLE
3
TOP PLATE(RMC-95C6)
3-1
TOP PLATE(RMC-95C6B)
4
BURNER ASS'Y
5
WICK COVER
6
REAR GRILLE
7
CABINET BASE(RMC-95C6)
7-1
CABINET BASE(RMC-95C6B)
8
WIND COVER
9
WICK ADJUSTER ASS'Y
(COMPLETE)
10
WICK
11
WICK ADJUSTER GASKET
12
SAFETY SHUT OFF DEVICE
13
DRIP TRAY ASS'Y(RMC-95C6)
13-1
DRIP TRAY ASS'Y(RMC-95C6B)
14
FUEL CAP GASKET
15
FUEL CAP ASS'Y
16
WICK ADJUSTER KNOB(RMC-95C6)
16-1
WICK ADJUSTER KNOB(RMC-95C6B)
17
BATTERY CASE ASS'Y(RMC-95C6)
17-1
BATTERY CASE ASS'Y(RMC-95C6B)
18
FRONT GRILLE
19
CABINET(RMC-95C6)
19-1
CABINET(RMC-95C6B)
20
MICA WINDOW
21
DOOR(RMC-95C6)
21-1
DOOR(RMC-95C6B)
22
FUEL GAUGE
23
FUEL GAUGE GASKET
24
TANK ASS'Y(RMC-95C6)
24-1
TANK ASS'Y(RMC-95C6B)
25
IGNITER ASS'Y
26
WICK SLEEVE
SPECIFICATIONS
Model No.
Type of Heater
Heat Output
Fuel Tank
Tank Capacity
Continuous Combustion Time
Max. Fuel Consumption
Ignition Method
Dimensions
Wick Height
Replacement Wick Number
EXPLODED PARTS DRAWING
NOTE :
SPECIFY MODEL NUMBER AND
PART
PART NUMBER WHEN ORDERING PARTS.
NUMBER
PS-CV01
WS-CV02R
WS-CV03
WS-CV03B
WS-CV04
WS-CV25
PS-CV060
WS-CV12
WS-CV12B
3, 3-1
WS-CV17
2113-0032-00
See Below
6
PS-CV19R
See 9
PS-CV32R1
PS-CV32R1B
19, 19-1
WS-CV30
WS-CV29
21, 21-1
WS-CV14
WS-CV14B
17
WS-CV27R1
7
WS-CV27R1B
PS-CV061
PS-CV08R
PS-CV08RB
WS-CV09
WS-CV34
WS-CV34B
WS-CV21
WS-CV22
PS-CV23R3
PS-CV23R3B
PS-CV24R1
PS-CV35
Height
Width
Depth
16, 16-1
RMC-95C6 / RMC-95C6B
Convection
Max. 23,000 BTU/hr
Integral
1.9 U.S. gallons
Approx. 8-12 hr
0.167 U.S. gallons/hr.
Battery-C Cell x2, Igniter Type "B"
27 inches
17.5 inches
17.5 inches
25/64 IN. (10mm)
Kero-World 32225, Dura Heat DH-145, Glowick 30856
15
24, 24-1
22
13, 13-1
