Dyna-Glo KFA50H User's Manual And Operating Instructions

Indoor/outdoor products kerosene portable forced air heaters
Hide thumbs Also See for KFA50H:
Table of Contents

Advertisement

Quick Links

INDOOR/OUTDOOR PRODUCTS
KEROSENE PORTABLE
FORCED AIR HEATERS
"USER'S MANUAL AND

OPERATING INSTRUCTIONS"

COMPLIES WITH UL733 AND
ANSI A10.10-1998
CAN/CSA/B140.0-03 AND CSA
B140.8-1967
MODEL : KFA50H, KFA75H, KFA125H, KFA210H2
Before the first use of this heater, please read this USER'S MANUAL very
carefully. This USER'S MANUAL has been designed to instruct you as to
the proper manner in which to assemble, maintain, store, and most
importantly, how to operate the heater in a safe and efficient manner.
Please keep this manual for future reference.
CONSUMER : Retain this manual for future reference.
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768 8:30 a.m. - 4:30 pm CST, Monday - Friday.
or email us at customerservice@ghpgroupinc.com

Advertisement

Table of Contents
loading

Related Manuals for Dyna-Glo KFA50H

Summary of Contents for Dyna-Glo KFA50H

  • Page 1: Operating Instructions

    ANSI A10.10-1998 CAN/CSA/B140.0-03 AND CSA B140.8-1967 MODEL : KFA50H, KFA75H, KFA125H, KFA210H2 Before the first use of this heater, please read this USER’S MANUAL very carefully. This USER’S MANUAL has been designed to instruct you as to the proper manner in which to assemble, maintain, store, and most importantly, how to operate the heater in a safe and efficient manner.
  • Page 2 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! DANGER: IMPROPER USE OF THIS HEATER CAN RESULT IN SERIOUS INJURY OR DEATH FROM BURNS, FIRE, EXPLOSION, ELECTRICAL SHOCK AND/OR CARBON MONOXIDE POISONING. WARNINGS: 1. RISK OF INDOOR AIR POLLUTION! • Use this heater only in well ventilated areas. Provide at least a three-square foot (2,800 sq. cm.) opening of fresh outside air for each 100,000 BTU/hr.
  • Page 3 Cord Wrap Side Cover (75H Model Only) Pressure Gauge Lamp (75H Model Only) Fuel Gauge Thermostot Knob (75H Model Only) Fuel Cap LED Power/Reset Switch (75H Model Only) Power Cord (Piggy Back,75H Model Only) Figure 1. KFA50H / KFA75H MODELS...
  • Page 4 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Front Handle Upper Shell Rear Handle Hot Air Outlet Shell Lower Cord Wrap Fuel Gauge Fuel Cap Side Cover Pressure Gauge Lamp Fan Guard Thermostat Knob Room Temp. Display Power Cord LED Power/Reset Switch (Piggy Back) 10”...

  • Page 5: Unpacking And Assembly

    Wheel Threaded Axle Front Handle Rear Handle Handle Cord Wrap Hardware kit : HW-KFA1001 Hardware kit : HW-KFA1016 Figure 4. KFA50H / KFA75H MODELS Cord Wraps Hardware Kit Handle (KFA75H Model Only) HW-KFA1001 Figure 5. KFA125H/KFA210H2 MODELS Screws Flange Screws...
  • Page 6 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 2. ASSEMBLY Screw Frong Guard Handle For KFA50H/75H Models only Tools Required Wedged Portion • Medium Phillips Screwdriver. Slit Hole 1. Assembling Handle & Cord Wrap 1) Lift front guard for arrow direction and make sure that guard’s wedged portion fits into the slit...
  • Page 7 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Front Handle Screw Cap Nut S Rear Handle Hot Air Outlet Cord Wrap Flange Screw Fuel Tank Flange Air Inlet Wheel Support Frame Threaded Axle Wheel Bushing Wheel Cap Nut L Figure 7. Assembling Handle, Wheel and Cord wrap CAUTION : DO NOT OPERATE heater without support frame assembled to tank.
  • Page 8 If this device activates and turns your heater off it may require service. Internal Shut-Off Temp. Reset Temperature MODELS Plus/Minus 10 Degrees Plus/Minus 10 Degrees KFA50H/75H 176˚F/80˚C 122˚F/50˚C KFA125H 230˚F/110˚C 194˚F/90˚C KFA210H2 194˚F/90˚C...

  • Page 9: Fueling Your Heater

    Room Temp. Display BTU Control Switch Lamp Push to “HIGH” Lamp Push to “LOW” Thermostat LED Power Thermostat LED Power Control Knob Switch Control Knob Switch (75H Model Only) KFA50H/75H Models KFA125H/210H2 Models Fan Guard Figure 8. Controls for All Models...

  • Page 10: Long Term Storage Of Your Heater

    IMPORTANT : Do not store kerosene over summer months for use during next heating season. Using old fuel could damage heater. 4. Reinstall fuel cap. Properly dispose of old and dirty fuel. (For KFA50H/75H Models Only) 5. Reinstall Fuel Drain Bolt to Fuel tank and tighten firmly using 3/4” socket or adjustable wrench.

  • Page 11: Maintenance

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 9. MAINTENANCE WARNING!! : NEVER SERVICE HEATER WHILE IT IS PLUGGED IN OR WHILE HOT! USE ORIGINAL EQUIPMENT REPLACEMENT PARTS. Use of third party or other alternate components will void warranty and may cause unsafe operating conditions.
  • Page 12 E.) NOZZLE REMOVE DIRT IN NOZZLE AS NEEDED (SEE PAGE 16). Combustion Chamber Screw (For KFA50H/75H/125H Models Only) - Remove upper shell (See page 10). Ignitor Wire - Remove fan blade (See page 10). - Remove fuel and air line hoses from nozzle adaptor.
  • Page 13 F.) SPARK PLUG Screw CLEAN AND REGAP EVERY 600 HOURS OPERATION OR REPLACE AS NEEDED. (For KFA50H/75H/125H Models Only) - Remove upper shell (See page 10). Spark Plug - Remove fan (See page 10). - Remove ignitor wire from spark plug.

  • Page 14: Pump Pressure Adjustment

    - Pull fuel line off fuel filter neck. - Turn fuel filter 90˚ to counter clockwise and pull to remove. (KFA50H/75H Models only) - Turn fuel filter 90˚ to clockwise and pull to remove (KFA125H/210H2 Models only) - Wash fuel filter with clean fuel and replace in tank.

  • Page 15: Replacing Fuse

    6. Replace switch wires to power switch. Fuse Holder 7. Replace side cover. Fuse NOTE : Specified fuse rating : AC 125/8A KFA75H/125H/210H2 Models Screw Side Cover Power Switch Fuse Switch Wire Fuse Holder KFA50H Model Figure 21. Replacing Fuse...

  • Page 16: Troubleshooting Guide

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 11. TROUBLE SHOOTING GUIDE TROUBLE POSSIBLE CAUSE CORRECTIVE ACTION Heater ignites but MAIN PCB 1. Wrong pump pressure 1. See Pump Pressure Adjustment, assembly shuts heater off after Page 13. a short period of time. 2.

  • Page 17: Wiring Diagram

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 12. WIRING DIAGRAM A) WIRING DIAGRAM (KFA50H Model) 15uF/230VAC B) WIRING DIAGRAM (KFA75H/125H Models) 1/G WIRE MODEL CAPACITOR COLOR BLACK 15uF/230VAC BLACK 125H 20uF/350VAC WHITE C) WIRING DIAGRAM (KFA210H2 Model) 20uF/350VAC...

  • Page 18: Specifications

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 13. SPECIFICATIONS 32.0"(813mm) 11.7"(297mm) KFA50H / KFA75H Models KFA125H KFA210H2 44.6"(1,132 ) 38.4"(976 ) 21.5"(547 ) 23.1"(587 ) 36.6"(929 ) 35.5"(902 ) KFA125H / KFA210H2 Models MODEL KFA50H KFA75H KFA125H KFA210H2 HIGH 50,000...
  • Page 19 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 14. EXPLODED PARTS DRAWING (KFA50H/75H/125H Models Only) NOTE : SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS. 23-3 23-8 23-5 23-7 23-2 23-1 23-4 23-6 23 24 26-2 26-5 26-6 26-7 26-9...
  • Page 20 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (KFA50H/75H/125H Models Only) PART NO. Quantity KEY NO. DESCRIPTION KFA50H KFA75H KFA125H Fuel Tank Assmebly 2151-0026-00 2151-0027-00 2151-0028-00 Fuel Drain-Bolt 4329-0072-00 Fuel Gauge 2156-0047-00 2156-0049-00 2156-0050-00 Fuel Filter Assmbly 2155-0005-00...

  • Page 21: Parts List

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (KFA50H/75H/125H Models Only) PART NO. Quantity KEY NO. DESCRIPTION KFA50H KFA75H KFA125H 26-8 Rotor See SP-KFA1000 See SP-KFA1000 See SP-KFA1000 26-9 Blade See SP-KFA1000 See SP-KFA1000 See SP-KFA1000 26-10 Insert...
  • Page 22 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 14. EXPLODED PARTS DRAWING (KFA 210H2 Model Only) NOTE : SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS. 21-8 21-3 21-7 21-1 21-5 21-2 21-4 21-6 23 13 24-2 24-5 24-6 24-7 24-9 24-8 24-11...
  • Page 23 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (KFA210H2 Model Only) PART NO. Quantity KEY NO. DESCRIPTION KFA210H2 Fuel Tank Assmebly 2151-0029-00 Fuel Drain-Bolt 4329-0072-00 Fuel Gauge 2156-0052-00 Fuel Filter Assmbly 2155-0001-00 Fuel Cap 2151-0003-00 Cord Bushing 3712-0013-00 Power Cord 3980-0179-00 Thermistor...
  • Page 24 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (KFA210H2 Model Only) PART NO. Quantity KEY NO. DESCRIPTION KFA210H2 24-12 Elbow 3231-0181-00 24-13 Lint Filter See SP-KFA1005 24-14 Bolt Flange 4329-0016-00 24-15 Output Filter See SP-KFA1005 24-16 End Filter Cover 3221-0076-00 24-17 Ball...
  • Page 25 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (WHEELS AND HANDLE) 1) KFA50H /KFA75H MODELS PART NO. Quantity KEY NO. DESCRIPTION KFA50H KFA75H Handle 3231-0073-00 3231-0073-00 Cord Wrap 3221-0041-00 Hardware Kit HW-KFA1001 HW-KFA1001 2) KFA125H / KFA210H2 MODELS PART NO.

This manual is also suitable for:

Kfa75hKfa125hKfa210h2
