Welcome!
What you're holding is not ordinary owner's manual. We've tried to make the instructions in this owner's
manual clear and easy to follow. If you take a few minutes to look through it, you'll learn how to use all of
the features on your new Jensen car stereo for maximum enjoyment.
Warranty Service
If your Jensen stereo should ever require service, you will need to have the original dated receipt. If you
ever need to return the unit for any reason, always include the receipt with the product.
Operation
Power / Volume / Loudness
Press PWR to turn
unit on or off.
Volume
Adjust volume by
pressing
or
.
VOL
VOL
0 = minimum
46 = maximum
Bass
1
Press SEL two times.
VOL
SEL
VOL
Treble
1
Press SEL three times.
VOL
SEL
VOL

Set the Clock

Press DISP to go to clock mode.
1
DISP
2
VOL
SEL
VOL
H
M
Detachable Security Panel
Reinstall faceplate.
2
Slip left edge into radio.
Press into place.
®
Power
PWR
VOL
SEL
VOL
- 6 = minimum
+6 = maximum
Adjust Bass
2
up or down.
- 6 = minimum
+6 = maximum
Adjust Treble
2
up or down.
1. Press DISP button for
three seconds until
colon flashes, then
release.
2. Press << to change
hours, >> to change
minutes.
CD315X
Operation
®
CD315X
AM/FM/CD RECEIVER
RPT
1
2
3
SCN
RPT
A-B
Balance
Press SEL four times.
1
Fader
1
Press SEL five times.
LOUD
CH
COMPACT
DIGITAL AUDIO
30W X 4
MEM
4
5
6
RDM
PGM
CLR
Press LOUD to increase
appears in the display.
R12 = Right speakers only
C00 = Equal sound right and left
L12 = Left speakers only
VOL
SEL
Adjust Balance
2
VOL
F12 = Front speakers only
C00 = Equal sound right and left
R12 = Rear speakers only
VOL
SEL
2
VOL
Remove faceplate.
1
Press RELEASE button
and gently pull on right
side of front panel
RELEASE
to remove.
BND
RELEASE
DISP
Loudness
bass output. LOUD
left or right.
Adjust Fader
front or rear.
