Zeiss LSM 700 Specifications

Specifications LSM 700
Microscopes
Stands
Z drive
XY stage (option)
Objectives
Accessories
Scanning module
Scanner
Scanning resolution
Scanning speed
Scanning zoom
Scanning rotation
Scanning field
Pinhole
Detection
Data depth
Laser inserts
Laser inserts (VIS, V)
Electronics module
Control computer
User PC
26
Upright: Axio Imager.Z1m, M1m and Axio Scope mot for LSM
Inverted: Axio Observer.Z1m SP (side port)
Axio Imager: Step motor, smallest increment 10 or 25 nm
Axio Observer: DC motor with opto-electronic coding, smallest increment 10 nm
Motorized XY scanning stage with Mark & Find (XYZ) and Tile Scan (Mosaic Scan) functions
More than 40 reflected-light objectives: EC Epiplans, EC Epiplan-Neofluars, EC Epiplan-Neofluars,
EC Epiplan-Apochromats, LD Epiplans, LD EC Epiplan-Neofluars
High-resolution AxioCam microscope camera
Two independent galvanometric scanning mirrors with ultra-short line and frame flyback
4 x 1 to 2048 x 2048 pixels, continuously adjustable
13 x 2 speed stages, Up to 5 frames/s with 512 x 512 pixels (max. 154 frames/s with 512 x 16 pixels)
0.5 x to 40 x, variable in increments of 0.1
Freely rotatable around 360°, variable in increments of 0.1°
Field diagonal of 18 mm (max.) in the intermediate image plane, homogeneous illumination
of image field
Motorized master pinhole, diameter continuously adjustable
One or two confocal channels (reflection/fluorescence), one optional external transmitted-light
channel with DIC capability, each with high-sensitivity PMT detector, spectral increment 1 nm
Selectable between 8 bit, 12 bit or 16 bit
Pigtail-coupled solid-state laser with polarization-preserving single-mode fiber; up to 4 V/VIS
laser directly connectable to the scanning module; laser lines 405 nm 5 mW or 445 nm 5 mW;
488 nm 10 mW; 555 nm 10 mW; 639 nm 5 mW (at fiber end)
Fast (pixel-exact) customized and variable intensity adjustment of all laser lines (direct modulation)
Automatic shutdown of laser when not in use
Real-time electronics integrated in PC; communication with user PC via PCI express; Control of
microscope, lasers, scanning module and additional accessories, data acquisition and synchronization;
Over sampling acquisition for best sensitivity and doubled SNR; possibility of online data-analysis
during acquisition
High-end PC with ample RAM and hard disk storage capacity; ergonomic high-resolution
16:10 LCD-TFT flat-panel display, Windows VISTA operating system with multi-user capability
Ethernet connection to local network
