- Page 1 Installation Requirements ZEISS LSM 900 Laser Scanning Microscope...
- Page 2 Effective from: 07/2020 © 2020 Without the prior written consent of ZEISS, this document or any part of it must neither be translated nor reproduced or transmitted in any form or by any means - including electronic or mechanic methods, by photocopying, recording or by any in- formation or filing system.
-
Page 3: Table Of Contents
2.7.1 Weight and Sizes of the Transported Goods ..........17 2.7.2 Weight and Sizes..................18 3 Applicable Standards and Regulations ..............19 4 Responsibility Checklist ..................20 4.1 Responsibility Checklist .................... 21 Installation Requirements ZEISS LSM 900 | en-US | Rev. 2 | 349500-8183-000... -
Page 4: About These Installation Requirements
Local and national health and safety regulations should be adhered to for the site and the use of health and safety the system. Please consult with your ZEISS Sales & Service Partner in the event of these regulations regulations conflicting with the installation requirements of the Microscope System. -
Page 5: Requirements
A site survey can be requested from your local ZEISS service representative prior to the installation. 2.1.1 Acoustic Noise It is recommended that the microscope system is installed and operated in a quiet room. Sound waves, e.g. -
Page 6: Electromagnetic Compatibility
The system can cause minimal electrical and radio interference as detailed by its classification as a CISPR 11 / DIN EN 55011 / class A system according to DIN EN 61326-1. Installation Requirements ZEISS LSM 900 | en-US | Rev. 2 | 349500-8183-000... -
Page 7: Vibration
Min. 0.5 m around the Microscope System Min. 0.9 m clearance from the table edge on the side of the laser module Customer arranged computer workspace Min. 0.8 m x 1.2 m x 0.76 m Installation Requirements ZEISS LSM 900 | en-US | Rev. 2 | 349500-8183-000... - Page 8 The following layouts are recommended for optimal accessibility, airflow and stability, depending on the options purchased with the system. For possible changes in preferential layout, please dis- cuss with your ZEISS representative. The placing of the user table can vary depending on available space and cable lengths.
-
Page 9: Mains Connection
§ Do not extend or modify the supplied power cords. § Do not connect electrical systems that are not authorised by ZEISS on the supplied power sup- ply cords. Value Nominal AC voltage 1/N/PE 120 or 230 VAC (+/-10%) 2 standard local power points are required. -
Page 10: Overvoltage Category
Category II Category III (VAC) 1500 1500 2500 1500 2500 4000 2500 4000 6000 1000 4000 6000 8000 Tab. 1: IEC Definitions of tolerated Transient Voltages for each Overvoltage Category Installation Requirements ZEISS LSM 900 | en-US | Rev. 2 | 349500-8183-000... - Page 11 Used at the origin of the installation. Examples: Electricity meters and primary overcurrent protection equip- ment. Installation Requirements ZEISS LSM 900 | en-US | Rev. 2 | 349500-8183-000...
-
Page 12: Ups Requirements
Fig. 5: Block diagram of offline UPS 2.4 Network Connectivity In order to provide remote diagnostics, ZEISS recommends connecting the computer to the inter- net in a safe and secured method. As a guideline, ask the ZEISS service representative about recommendations for data security pol- icy on ZEISS Systems. -
Page 13: Zeiss Predictive Service
2 Requirements | 2.4 Network Connectivity 2.4.1 ZEISS Predictive Service ZEISS Predictive Service is used for condition monitoring by systematic retrieval of relevant instru- ment health information and its server based processing. The goal is to detect deviations in the in- strument performance before they impair the user’s result or even result in unplanned downtime. -
Page 14: Safety And Radiation Information
The Microscope System is classified as laser class 3B / IIIB. However, there is one exception: The 1-Channel MAT version of the LSM 900 is a laser class 2 / II instrument due to its system con- figuration. (The laser module itself is still a laser class 3 module.) The operator of the laser equipment is responsible for conformance with protective measures and safety requirements. -
Page 15: Biosafety Level Of The Laboratory
2.5.2 Biosafety Level of the Laboratory The customer should inform ZEISS of the biosafety level of the installation site. Access to the sys- tem, safety training, correct safety dress code and use of tools and test equipment needs to be clarified for specified laboratories (World Health Organisation Laboratory Biosafety Manual 3). -
Page 16: Compressed Air
Active damping tables require compressed air to isolate the system from floor vibrations. The nec- essary compressed air can be either generated by a compressor (please ask your ZEISS sales and service representative) or taken from a gas cylinder or from an in-house supply system. -
Page 17: Transport And Storage
Max. 100 Accessories box 2 1200 1300/900 Max. 100 System table, small (depending on 1120 1120 1030 the configuration) System table, medium (depending 1720 1100 1080 on the configuration) Installation Requirements ZEISS LSM 900 | en-US | Rev. 2 | 349500-8183-000... -
Page 18: Weight And Sizes
Fiber optic cable, VIS(ible) Cables Info The table for the system computer is provided by the customer. ZEISS recommends a table with the dimensions 1200 x 800 x 750 mm. Installation Requirements ZEISS LSM 900 | en-US | Rev. 2 | 349500-8183-000... -
Page 19: Applicable Standards And Regulations
The product was developed, tested and produced in accordance with the valid regulations and guidelines for environmental law of the European Union. ZEISS introduced a procedure for the return and recycling of the instruments within the member states of the European Union which ensures suitable recycling procedures conforming to the EU directives. -
Page 20: Responsibility Checklist
The customer should internally evaluate the proposed site to verify its compatibility with all the requirements presented in this document. A ZEISS service representative can assist with the checklist to evaluate which requirements are already met, and which requirements are yet to be completed. -
Page 21: Responsibility Checklist
Responsibility Checklist Company name: Address: Contact person: Requirements Fulfillment Comments Partially (Checked (Partially (Checked (not fulfilled) but not applicable) complete) fulfilled) Environmental Requirements Acoustic noise Air Quality Electromagnetic Compatibility Magnetic Field Vibration Location Requirements Installation Plan Space Requirements Air Conditioning Earthing Mains Connection Network Connectivity... - Page 22 Carl Zeiss Microscopy GmbH Carl-Zeiss-Promenade 10 phone: +49 1803 33 63 34 07745 Jena fax: +49 3641 64 3439 Germany info.microscopy.de@zeiss.com www.zeiss.com/microscopy...
