SELECTRONIC™
Proximity Faucets
Certified to comply with ASME A112.18.1M
© 2005 American Standard
M 9 6 8 8 0 9 R e v . 1 . 2
NOTE TO INSTALLER: Please give this manual to the customer after installation.
To learn more about American Standard Faucets visit our website at: www.us.amstd.com or U.S.
customer's e-mail us at: faucetsupport@amstd.com
For Parts, Service, Warranty or other Assistance,
1-800-442-1902 (In Canada: 1-800-387-0369)
please call
(In Toronto Area only: 1-905-3061093)
(In Toronto Area only: 1-905-3061093)
Cast Spout and two
Goose Neck Sizes
Product No.'s & Options
Specifications
How to Install
Electrical Hook-up
FAQ,s
Replacement Parts
1
2
2-3
4-6
7-8
9
10
Advertisement
Table of Contents
Related Manuals for American Standard Selectronic Proximity Faucet
Summary of Contents for American Standard Selectronic Proximity Faucet
- Page 1 M 9 6 8 8 0 9 R e v . 1 . 2 NOTE TO INSTALLER: Please give this manual to the customer after installation. To learn more about American Standard Faucets visit our website at: www.us.amstd.com or U.S. customer's e-mail us at: faucetsupport@amstd.com...
- Page 2 6057.102 605P400 605P800 605XTMV All American Standard Faucets Are Water Tested At Our Factory. Some Residual Water May Remain In The Faucet During Shipping. 5c. 10 ft. Extension Wire (for 6057 series) 6. Circuit board 7. 4" Deck plate ( optional must be ordered separately) 8.
-
Page 3: General Description
Fig. 1 Roughing-in Dimensions 131mm 141mm (5-1/8) (5-1/2) 49mm 32mm (1-1/4) 81mm (3-3/16) 125mm (4-7/8) 114mm (4-1/2) 381mm (15) 500mm (20") 3/8" COMP. TOOLS REQUIRED; Fig. 2 1 Channel Locks 2 Adjustable Wrench 3 Plumbers' Putty or Caulking 4 Phillips Screwdriver 5 Flat Blade Screwdriver 6 Electric Drill &... - Page 4 MOUNT ENCLOSURE; Fig. 2 1. Determine location of ENCLOSURE (1). It must be located with-in the 14" (356mm) by 21" (533mm) shaded area shown in Figure 2 in order for electrical connections from the spout assembly to be made. NOTE: ENCLOSURE SUPPLY HOSE is 20". Distance between wall supply and ENCLOSURE (1) must be taken into consideration.
- Page 9 HOW TO CLEAN FILTER; Fig. 4 Before opening ENCLOSURE CAUTION disconnect AC power supply. 1. Remove ENCLOSURE COVER. 2. Close SUPPLY STOP (5) with 4mm Hex wrench. Note: Keep water flowing out of faucet while shutting off. 3. Pull off Red (1) and Black (2) CONNECTORS from SOLENOID VALVE (3).
- Page 10 GENERAL CLEANING; Fig. 7 1. For general cleaning use a damp, soft cloth to clean the spout and the sensor. 2. For cleaning dirt use a soft cloth with diluted dish washing detergent. Wipe the area using a wet cloth and dry using a soft cloth.
- Page 11 Cast Spout A923672-0070A FAUCET SUPPLY HOSE A950223-007L0A SENSOR M962411-0070A MOUNTING KIT M962387-0070A MOUNTING SCREW KIT A913202-0070A WASHER A924162-0070A SUPPLY HOSE 605P400 605P800 044912-0070A MOUNTING NUT Replace the "YYY" with appropriate finish code CHROME HOT LINE FOR HELP For toll-free information and answers to your questions, call: 1 (800) 442-1902 Weekdays 8:00 a.m.
- Page 12 M 9 6 8 8 0 9 R e v . 1 . 2...
