Sony HCD-D60 Service Manual page 27

MD BOARD
CAPSTAN MOTOR
1 Break the soldering of
motor lead.
1 connector
(CN651)
4 four screws
(BTP 2.6 4)
5 MD board
4 Removal the capstan motor
to direction of the arrow.
3 claw
– 27 –
2 two rivets
3 Break the soldering of two
flexible flat cables.
2 two screws
(BTP 2.6 8)
5 Hang the
two belts.
