Lochinvar Shield SNR150-100 Installation & Service Manual page 37

5
System piping
Figure 5-3 Multiple Units
Please note that these illustrations are meant to show system piping concept only, the installer is responsible
NOTICE
for all equipment and detailing required by local codes.
(continued)
MIXING VALVE
(IF REQUIRED, SEE PG. 35)
TM Installation & Service Manual
37
