- Page 1 KYE Systems Corporation User’s Guide ColorPage-Vivid 4 USB Scanner All trademarks and brand names mentioned in this publication are property of their respective owners. 2001..KYE Systems Corp. All rights reserved. No portion of this document may be reproduced without permission.
-
Page 2: Table Of Contents
UIDE ........................2 ONVENTIONS OF THIS UIDE ...........................3 OTE ABOUT CONS ..........................4 YSTEM EQUIREMENTS .............................5 ACKAGE ONTENTS CHAPTER I. INSTALLING GENIUS COLORPAGE-VIVID 4 USB SCANNER ........6 ..........................7 OFTWARE EQUIREMENTS .........................7 ARDWARE EQUIREMENTS ....................7 NSTALLING AND ETTING UP THE CANNER ...........................10 OFTWARE NSTALLATION ......................11... -
Page 3: Introduction
Center. Please feel free to contact us or visit GeniusLife Homepage (http://www.geniusnet.com.tw/) for getting better service. Thank you for choosing Genius Product. We hope you will continue to turn to us for additional quality products as your computing needs and interests grow. -
Page 4: How To Use This Guide
Genius Service Center directly at one of the locations listed on the last page of this manual. Chapter I, Setting Up Your New Genius ColorPage-Vivid 4 USB Scanner, describes how to install scanner’s programs and connect the scanner to your computer. -
Page 5: A Note About Icons
A procedure that must be followed carefully to prevent injury, or accidents. Danger Caution Caution: Information that, if not followed, may result in data loss or damage to the product. Pay Special Attention: Instructions that are important to remember and may prevent mistakes. Attention Genius ColorPage-Vivid 4 USB Scanner... -
Page 6: System Requirements
CD-ROM Drive 64 MB RAM (128 MB Recommended) 160 Free Hard Disk Space (260 MB Recommended) USB Port Microsoft™ Windows XP / Me / 2000 / 98 Video card that supports 16-bit color or greater Genius ColorPage-Vivid 4 USB Scanner... -
Page 7: Package Contents
Genius TWAIN Program NewSoft PageManager Program NewSoft ImageFolio (Imaging Editing Software) NewSoft Mr. Photo (Photo Management Software) BridgeWell Page abc (Web Editing Software) ABBYY FineReader Sprint 4.0 (Text Recognition Software) This User’s Guide (Electronic Version) Genius ColorPage-Vivid 4 USB Scanner... -
Page 8: Chapter I. Installing Genius Colorpage-Vivid 4 Usb Scanner
Chapter I. Installing Genius ColorPage-Vivid 4 USB Scanner Genius ColorPage-Vivid 4 USB Scanner... -
Page 9: Software Requirements
5 of this guide. Software Requirements Genius ColorPage-Vivid 4 USB comes with scanner body, scanner’s install driver, Genius TWAIN program, NewSoft PageManager program, NewSoft ImageFolio image-editing software, NewSoft Mr. Photo photo management software, ABBYY FineReader Sprint 4.0 OCR software, BridgeWell Page abc web editing software. - Page 10 Please take a moment to study Figure 4. Figure 4. Installing the ColorPage-Vivid 4 USB Scanner Plug the power adapter into the scanner’s power receptor which can be identified by the symbol on its top (see Figure 4, Step1). Plug the other end of the power adapter into a standard AC power outlet (see Figure 4, Step Plug the square end (Type B connector) of the included USB cable to the USB port at the rear of the scanner (see Figure 4, Step 3).
- Page 11 USB cable provided with your scanner. If you wish to use a different USB cable, make sure that it is a fully rated twisted- Attention pair USB cable and has a Type A connector at one end and a Type B plug on the other. Genius ColorPage-Vivid 4 USB Scanner...
-
Page 12: Software Installation
Next, please insert the Setup/Application CD-ROM, included with your scanner, into your CD- ROM drive. Click the CD-ROM DRIVE box once, causing a check to appear in it as shown above and then click on the NEXT button again. The following window will appear: Genius ColorPage-Vivid 4 USB Scanner... -
Page 13: Installing Additional Software
3. A window will pop up, asking you to confirm the deletion of the selected application and all of its components. Click OK and the UninstallShield program will run automatically and delete the scanner software driver. Genius ColorPage-Vivid 4 USB Scanner... - Page 14 Once completed, restart Windows. Genius ColorPage-Vivid 4 USB Scanner...
-
Page 15: Chapter Ii. Usage And Maintenance
Chapter II. Usage and Maintenance Genius ColorPage-Vivid 4 USB Scanner... -
Page 16: Scanner Utility Program
The Scanner Utility program does NOT affect the quality of scanned images. It is only used to establish a connection with the scanner. Settings that affect the scanned image (i.e., color, size, readability, clarity, etc.) can be found in the scanner software programs and especially the TWAIN interface. Genius ColorPage-Vivid 4 USB Scanner... -
Page 17: Connection Status
Secondly, determine the status of your USB hardware and software configuration. To do this, please run the Scanner Utility program as described below: Click on the START button, then choose PROGRAMS, ColorPage-Vivid 4 USB and then SCANNER UTILITY. Once the Scanner Utility window is open, locate and click on the USB button shown below: This will check the status of your USB hardware and software configuration. - Page 18 To do this, click on the Windows START button and choose PROGRAMS, ColorPage-Vivid 4 USB, SCANNER UTILITY. In the window that opens, find the Lamp Control section shown below: Click on the On/Off switch at the far right of the section to immediately turn the scanning lamp on or off.
-
Page 19: Scanning
If an image appears on your screen, your scanner is working properly. If the image doesn’t appear to your liking, don’t worry. You only need to adjust some settings in the Genius TWAIN window. To learn how to adjust scanner settings, please refer to the Genius Help by clicking on the Help button in the Genius TWAIN window. - Page 20 Figure 9. Genius TWAIN Interface Genius ColorPage-Vivid 4 USB Scanner...
-
Page 21: Chapter Iii. How To Use Quick Function Buttons
Chapter III. How to Use Quick Function Buttons Genius ColorPage-Vivid 4 USB Scanner... -
Page 22: Function Buttons Setting
1. Open the “Scan Manager Setting” window by double-clicking the ICON of “KYE Scan” from system tray. Or click on mouse RIGHT button and enter “Setting” 2. Click on the “Scan” ICON in the “Scan Manager Setting” window. 3. Choose “NewSoft PageManager” as the application Program in drag-down menu. Genius ColorPage-Vivid 4 USB Scanner... -
Page 23: Email/Web" Button
2. To use “Email button”, please make your “Email program” as the default application before you using the Email button. 3. To use “Web button”, please make “BRIDGEWELL Page abc” as the default application before you using the Web button. Genius ColorPage-Vivid 4 USB Scanner... - Page 24 To use Email/Web Button for “Scan to Web” function Place a document or picture face down on the scanning glass. Press the “Email/Web” Button Automatically scanning Automatically saving image file and transfer image file into “Page abc” Web Editing software. Genius ColorPage-Vivid 4 USB Scanner...
-
Page 25: Text/Ocr" Button
Press the “Text/OCR” Button Scanner starting to automatically scanning Choose “Yes” or “No” for Next Page to do OCR. Word processing software will be launched and recognized Text will be transfer to default word processing software. Genius ColorPage-Vivid 4 USB Scanner... -
Page 26: Print/Copy" Button
Click “Close” to exit Scan Manager Setting To use “Print/Copy” Button Place a document or picture face down on the scanning glass. Press the Print/Copy Button Scanner starting to automatically scan Choose “Yes” or “No” for Next Page to Copier Copying Genius ColorPage-Vivid 4 USB Scanner... -
Page 27: File/Fax" Button
Press the “File/Fax” Button Scanner starting to automatically scan Choose “Yes” or “No” for Next Page to Fax Copying Fax Application Window Open Following the screen instruction to proceed fax transmission. To set up File software Genius ColorPage-Vivid 4 USB Scanner... - Page 28 Place a document or picture face down on the scanning glass. Press the “File/Fax” Button Scanner starting to automatically scan Choose “Yes” or “No” for Next Page to scan. “PageManager” Window Open. Scanned Image will be filed into the default folder of “PageManager”. Genius ColorPage-Vivid 4 USB Scanner...
-
Page 29: Maintenance
Then, wipe the glass thoroughly with the cloth. DO NOT SPRAY CLEANER DIRECTLY ONTO THE SCANNER GLASS. Excess liquid residue may fog or damage the scanner. Your scanner operates best in temperatures between 10 C to 40 C (50 F to 104 F). Genius ColorPage-Vivid 4 USB Scanner... -
Page 30: Appendix A: Specifications
TWAIN Full TWAIN Compliance Connection: USB Port Lamp type: Cold Cathode Lamp Power adapter: Power Output DC 24V, 550mA (Load) Operation – 13.2 watts maximum Power Consumption: Idle – 6 watts EMI: FCC Class B Genius ColorPage-Vivid 4 USB Scanner... -
Page 31: Appendix B: Customer Service And Warranty
We are continuously enhancing the performance of our product drivers. To check for the updated device driver you may visit our Web Site. (Please refer to the section of “Contacting Genius” on the last page of this manual.) Attention Genius ColorPage-Vivid 4 USB Scanner... -
Page 32: Statement Of Limited Warranty
If this product is an optional feature, this Limited Warranty applies only when the feature is used in a machine for which it was designed. If you have any questions about your Limited Warranty, contact Genius. THIS LIMITED WARRANTY REPLACES ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABLITY AND FITNESS FOR A PARTICULAR PURPOSE. -
Page 33: Fcc Radio Frequency Statement
Consult the dealer or an experienced radio/TV technician for help if the conditions persist. Changes or modifications not expressly approved by the manufacturer or authorized service center could void the users authority to operate this equipment. Genius ColorPage-Vivid 4 USB Scanner... -
Page 34: Contacting Genius
Hsien 241, Taiwan, R.O.C. Bandar Kinrara, 6 1/2 Miles,Jalan Puchong, Tel： (886) 2 2995-6645 58200 Kuala Lumpur, Malaysia Fax：(886) 2 2995-6649 Tel： (603) 575 1355 Web site: http://www.geniusnet.com.tw Fax：(603) 575 6362 / 6962 Web site: sales_kye@kye-systems.com.my Genius ColorPage-Vivid 4 USB Scanner...
