Remote Control, cont'd
Figure 4-4 — System Settings screen
2. Make changes to the IP Settings, Date/Time settings, etc.,
as necessary.
3. Click the Submit button to enter the changes, or click the
Cancel button to revert to the previous settings.
Be aware that changing the IP address, Subnet
CAUTION
mask, or other IP Settings could affect your ability
to contact the RCP unit.
4-6 RCP 2000 • Remote Control

Firmware upgrade

Also available on the Configuration tab is the Firmware
Upgrade screen. This screen is used to check and, if necessary,
upgrade the firmware for the RCP unit. To check and/or
upgrade the firmware, follow these steps:
1. From the Configuration tab, click on Firmware Upgrade
from the menu column on the left side of the screen. The
Firmware Upgrade screen (figure 4-5) is opened.
Figure 4-5 — Firmware Upgrade screen
2. Use the Browse button to access Extron's Website
(www.extron.com), and select the product category for
your RCP unit.
Review the available firmware versions and compare them
3.
to the Current Firmware Version shown on the Firmware
Upgrade screen.
4. If a newer firmware version is available, select and
highlight the file (it must have the file extension .S19),
then click Upload. The new firmware is uploaded to your
RCP unit.
Be aware that uploading the incorrect file may
CAUTION
cause your RCP unit to stop functioning.
The original factory-installed firmware is permanently
available on the RCP 2000. If the attempted upload of
new firmware fails for any reason, the RCP 2000 reverts
to the factory-installed firmware.
RCP 2000 • Remote Control
4-7
